- Page 1 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual OM-DF356FST-001-A...
- Page 2 THIS PAGE IS INTENTIONALLY LEFT BLANK.
-
Page 3: Table Of Contents
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual CONTENTS SAFETY INFORMATION ..................4 1.1 GENERAL INFORMATION ................5 1.2 INSTALLATION OF EQUIPMENT ..............6 1.3 INSTALLATION OF WIRE ROPE ..............8 2.1 OPERATING THE WINCH ................ -
Page 4: Safety Information
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual SAFETY INFORMATION CAUTION Prior to installing and operating the winch, please read this manual thoroughly and carefully. Keep this manual and all other instructions accessible at all times. The Occupational Safety and Health Act of 1970 states that it is the employer’s responsibility to provide a workplace free of hazard. -
Page 5: General Information
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 1.1 GENERAL INFORMATION EVERYTHING YOU NEED FROM THE DF-356 FASST WINDER WINCH Features & Specifications • Hot-dipped Galvanized coating. • Patented high load release dog with secondary anti-backlash drag brake that is activated automatically with the release of the dog. -
Page 6: Installation Of Equipment
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 1.2 INSTALLATION OF EQUIPMENT NOTICE It is the responsibility of the customer, not the winch manufacturer, to properly locate and install the winch with regard to the safety of those operating the machinery. - Page 7 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 1.2.4.1 If the direction of the wire rope is not indicated on the winch, determine as follows: Engage the locking pawl and disengage the brake system. Rotate the winch drum using either the handwheel or hand ratchet.
-
Page 8: Installation Of Wire Rope
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 1.3 INSTALLATION OF WIRE ROPE 1.3.1 To install wire rope, rotate the drum of the winch so that the U-bolt nuts are easily accessed through the round cut out located on the side of the winch (see fig. 3a). - Page 9 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 1.3.6 Wind the wire rope onto the drum by operating the winch. Maintain tension on the wire rope to insure that the first coil lays snugly against the drum flange and each successive coil is snug against the previous coil.
-
Page 10: Operating The Winch
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 2.1 OPERATING THE WINCH The DF-356 Upfit Winch with FASST Winder is operated by using either the hand wheel or FASST Winder System. The winch is also equipped with a disc braking system, locking dog and anti-backlash friction band. - Page 11 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 2.1.2 FASST Winder Operation 2.1.2.1 The winch is equipped with a FASST Winder system for use when additional wire rope tightening is needed. The FASST Winder should be placed in rest position when not being used (see fig.
- Page 12 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual FIGURE #5 - FASST WINDER Rest Position FIGURE #6 - FASST WINDER Forward Position OM-DF356FST-001-A...
- Page 13 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 2.1.3 Locking Pawl and Anti-Backlash Friction Band Operation The manual winch uses a combination locking pawl and anti-backlash friction band assembly to secure the wire rope that is either being loaded or unloaded under tension. The locking pawl prevents the load from releasing while tension is being applied to the wire rope.
- Page 14 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 2.1.4 Disc Brake Operation The winch uses a multi-disc braking system to secure the loads placed on it. The brake system is designed to hold loads equal to that of the winch capacity.
-
Page 15: Equipment Inspection
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 3.1 EQUIPMENT INSPECTION NOTICE An inspection program should be started as soon as any equipment is put into service. A qualified person should be appointed the responsibility of regularly inspecting the equipment. Written records of inspections are recommended by the manufacturer. - Page 16 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 3.1.3 Wire Rope Inspection 3.1.3.1 Wire rope inspection should be conducted according to the manufacturer’s recommendations or accepted industry standards. CAUTION Remember to always wear the proper protective equipment when handling the wire rope.
-
Page 17: Equipment Lubrication
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 3.2 EQUIPMENT LUBRICATION 3.2.1 All grease fittings and external gearing should be lubricated using NABRICO’s suggested lubricants or similar. 3.2.2 Drive shaft and drum shaft grease fittings should be lubricated at least once a month under normal conditions and at least once a day under adverse conditions. -
Page 18: Cleaning And Storage
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual 3.3 CLEANING AND STORAGE 3.3.1 Cleaning the Equipment 3.3.1.1 The equipment should be regularly cleaned to remove dirt and to help prevent rust and corrosion. 3.3.1.2 When cleaning, be sure to leave a light film of oil on all surfaces to protect them against the elements of nature. -
Page 19: Dimensional
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual A.1 DIMENSIONAL OM-DF356FST-001-A... -
Page 20: Base Bar Comparison
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual A.2 BASE BAR COMPARISON OM-DF356FST-001-A... - Page 21 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual OM-DF356FST-001-A...
-
Page 22: Parts Breakdown
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual A.3 PARTS BREAKDOWN 14614 14614 101667 101643 101666 69949 101649 101668 70599 69930 101666 101669 101670 69923 101669 64127 101671 73911 14613 11746 64113 101640 79901 DISC BRAKE DETAIL 83321 SCALE: 2" = 1'-0"... -
Page 23: Parts List
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual A.4 PARTS LIST DF‐356‐UF‐40 FASST Winder™ Winch Parts List Additional Parts List PART DESCRIPTION QTY PART #'S FASTENERS & ETC QTY PART #'S 22" Handwheel Assembly (Galv'd) 40 Ton Winch 062732N Hex Lock Nut (304 SS) 1/2" ‐ 13 UNC, Nylon Inser 4 000313N Hand Grab Assembly, DF‐356 062739N Hex Head Bolt (304 SS) 1/2"‐13 UNC x 2‐1/2", Fu 000419N Foot Grab Assembly, DF‐356 062740N Hex Head Nut (316 SS) 3/4"‐10 UNC 000421N Speed Handle Assembly, DF‐629 062952N HEX NUT (316 SS) 1/2"‐13 UNC 000428N Base Bar, DF‐156‐UpFit 064104N Flat Washer (304 SS) 16mm [5/8"] 000453N Front Guard Assembly, 40T‐UpFit Winch... -
Page 24: Fleet Angle
NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual A.5 FLEET ANGLE Fleet Angle: In order to insure proper wrapping on the drum and no undue wear of the wire rope, the fleet angle should be kept as small as practical. This is important to consider during the planning of a winch installation. -
Page 25: Product Warranty
NABRICO shall have no obligation or responsibility to repair or replace any defective NABRICO product if a notice of defect is not reported in writing to NABRICO within 180 days from the date of shipment of any NABRICO Winch Products and 90 days from the date of shipment of any other NABRICO Products (such 180 day and 90 day periods are hereinafter referred to as “Warranty Period”). - Page 26 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual OM-DF356FST-001-A...
- Page 27 NABRICO DF-356 Upfit Winch with FASST Winder Owner’s Manual OM-DF356FST-001-A...
- Page 28 NABRICO 1250 GATEWAY DRIVE GALLATIN, TN 37066 615.442.1300 615.442.1313 fax www.nabrico-marine.com WINCHES HATCHES BITTS ELECTRIC WATERTIGHT DOUBLE BITT HYDRAULIC TWIST LOCK SINGLE BITT MANUAL QUICK ACTING THRU-DECK BITT CAPSTANS DOORS KEVELS HYDRAULIC 6 DOG MANUAL KEVEL CHOCK ELECTRIC QUICK ACTING...
