Rear Panel I/O
• 1x PS/2 Keyboard connector
• 1x PS/2 Mouse connector
• ABIT Silent OTES
• 1x OPT-IN1 connector
• 1x OPT-OUT1 connector
• 1x eSATA1 connector (AB9 Pro)
• 1x AUDIO1 Connector (Surround-Left / Surround-Right, Rear-Left / Rear-Right,
Center/Subwoofer, Mic-In, Line-In, Line-Out)
• 4x USB 2.0 connectors
• 2x RJ-45 Gigabit LAN connectors (AB9 Pro)
• 1x RJ-45 Gigabit LAN connector (AB9)
Serial ATA
• 6x SATA 3Gb/s offered by Intel ICH8R supports Intel Matrix Storage Tech (AHCI &
RAID 0/1/5/10) (AB9 Pro)
• 4x SATA 3Gb/s offered by Intel ICH8 (AB9)
• 2x SATA 3Gb/s offered by JMicron JMB363 supports up to 0, 1, JBOD RAID function
• 2x SATA 3Gb/s offered by Silicon Image 3132 (AB9 Pro)
ABIT Engineered
• ABIT SoftMenu
• ABIT uGuru
• ABIT Silent OTES
RoHS Compliancy
• 100% Lead-free process and RoHS compliancy
Miscellaneous
• ATX form factor (305mm x 245mm)
※ Specifications and information contained herein are subject to change without
notice.
1-2
