Introduction

Chapter 1. Introduction

1-1. Features & Specifications
1. LGA775 CPU Socket
•
Designed for Intel
•
Compatible with Intel
•
Supports Intel
2. Express Chipset
®
•
Intel 925X / Intel
3. Flexible Memory
•
Four 240-pin DIMM sockets (Un-buffered Non-ECC DIMM)
•
Supports Dual channel DDR2-533/400 (Max. 4GB), up to 8.5GB/s bandwidth
4. PCI Express x16 graphics
•
Delivers up to 8GB/s per direction for 3.5 times more bandwidth than AGP8X at 2.1GB/s
5. PCI Express x1 I/O
•
Offers 500MB/s concurrently, over 3.5 times more bandwidth than PCI at 133MB/s
6. SATA Matrix RAID 150
®
•
Intel Matrix Storage Technology on 4 Serial ATA ports. RAID 0/RAID 1 delivers higher
performance and data protection
•
Supports SATA AHCI, providing native command queuing and native hot plug
7. High Definition Audio
•
Onboard Theater-class 7.1 Channels Intel
•
Professional digital audio interface supports auto jack sensing and optical S/PDIF In/Out
8. IEEE 1394
•
Supports 3 Ports IEEE 1394 at 100/200/400 Mb/s transfer rate
9. Gigabit LAN
•
Onboard Gigabit LAN controller supports 10/100/1000M Ethernet
10. ABIT Engineered
•
ABIT uGuru
•
ABIT CPU ThermalGuard
11. Internal I/O Connectors
•
1x PCI Express x16 slot
•
3x PCI Express x1 slots
•
2x PCI slots
®
90nm Pentium 4/Celeron D LGA775 processors with 800/533 MHz FSB
®
04B and 04A processors
®
Hyper-Threading Technology
®
ICH6R Express Chipset
™
Technology (ABIT OC Guru/ABIT EQ/ABIT Flash Menu/ABIT Black Box)
™
Technology
®
High Definition Audio
1-1
User's Manual
