  • Page 1 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com M.D. Micro Detectors CAT8ELS1250901 1/34...

  • Page 2: Table Of Contents

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com CONTENTS ABOUT THIS DOCUMENT ......................3 Function of this document ........................ 3 Symbols used in this document ......................

  • Page 3: Installation And Operation Manual English

    For presence detection, with safety light curtains in a horizontal position, resolutions of between 50 and 116mm are to be used, the height off the ground is calculated in relation to these values. For this function the LS2 series features models with resolutions of 50 and 90mm. Hand detection This symbol marks devices designed to detect a hand entering a protected area.

  • Page 4: With Reference To Safety

    LS2 safety light curtains must be used only in accordance with Chapter 2.2 “Fields of use of the device”. If the device is used for other purposes or if it is modified, even in the phase of mounting or installation, this invalidates all warranty rights with M. D. Micro Detectors. M.D. Micro Detectors...

  • Page 5: General Safety Instructions And Measures Of Protection

    3.1 Brief description The LS2 series curtains are multiple light beam safety devices, built in compliance with the IEC 61496-1 and 2 standards, are Type 2 and therefore applicable for the protection of the operators of systems or dangerous machines.

  • Page 6: Coding System

    For an overview of the main features of the models ready for delivery or available on request, see Tab.:2 and 3 in this chapter. For a complete and detailed list of the actually coded models and their related features, see Chapter 9. Directly contact M. D. Micro Detectors for any explanation. LS2 SERIES CONSTRUCTION OF MODEL CODES...

  • Page 7: Availability Of Models With Ip65 + Ip67 Protection

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 3.3 Availability of models with IP65 + IP67 protection Tab: 2 and 3 give the actually available models with reference to the optical parameters.

  • Page 8: Possibility Of Interconnection Of The Available Models

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual Manual www.microdetectors.com www.microdetectors.com ENGLISH info@microdetectors.com 3.5 Possibility of interconnection of the available models...

  • Page 9: Instructions For Positioning The Safety Light Curtains

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 4.0 INSTRUCTIONS FOR POSITIONING THE SAFETY LIGHT CURTAINS 4.1 Respecting the safety distance...

  • Page 10: How To Calculate The Safety Distance S In Conformity With En Iso 13855 And En Iso 13857

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 4.2 How to calculate the safety distance S in conformity with EN ISO 13855 and EN ISO 13857 Here we give the general procedures for calculating the minimum safety distance S, these instructions must be followed if there is not a specific standard of type C for the machine to make safe.
  • Page 11 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com ● Calculate S with the following procedure for applications of protection with safety light curtains over which it is possible to climb.
  • Page 12 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com ● Calculate S with the following procedure for finger or hand protection applications, with vertical curtains (90°...

  • Page 13: Minimum Distance From Reflecting Surfaces

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 5.0 MINIMUM DISTANCE FROM REFLECTING SURFACES The optical beams of the Emitter, having a beam angle that is not null, can partly be diverted by reflective surfaces located near to the curtains.

  • Page 14: Commissioning

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 6.0 COMMISSIONING 6.1 Mechanical mounting This device is suited to work in protected environments, not outdoors.

  • Page 15: Electrical Installation

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 6.3 Electrical installation. Before proceeding carefully read the data of Tab.:1; Chap.:7 in the sections: Supply, Outputs and Connections.
  • Page 16 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SERIES LS2 CONNECTOR EXIT WITH FIVE POLES...
  • Page 17 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com CONNECTOR AND CABLE EXIT WITH FIVE POLES SERIE LS2 Standard and Master models: LS2E/**-***;...
  • Page 18 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com LS2 SERIES CONNECTORS FOR INTERCONNECTION OF MASTER/SLAVE/FINAL...

  • Page 19: Technical Specifications

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 7.0 TECHNICAL SPECIFICATIONS. LS2 SERIES TECHNICAL SPECIFICATIONS PARAMETERS Min.

  • Page 20: Panel And Diagnostics Indications

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 8.0 PANEL AND DIAGNOSTICS INDICATIONS 8.1 Symbols used to indicate the LED indicators modes Indication of LED lit steadily Indication of LED lit intermittently with periodical blinking.

  • Page 21: Interpretation Of Error Codes

    NOTE: In all these cases, if the failure persists, send to M. D. Micro Detectors for repair In all these cases, if the failure persists, send to M. D. Micro Detectors for repair Tab.:6; Chap.:9 RECEIVER MODELS ERROR CODES...

  • Page 22: Lists Of Available Models And Main Characteristics

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 9.0 LISTS OF AVAILABLE MODELS AND MAIN CHARACTERISTICS...
  • Page 23 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SAFETY LIGHT CURTAIN FOR HAND PROTECTION WITH RESOLUTION 40mm...
  • Page 24 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SAFETY LIGHT CURTAIN FOR LIMB PROTECTION WITH RESOLUTION 50mm...
  • Page 25 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SAFETY LIGHT CURTAIN FOR LIMB PROTECTION WITH RESOLUTION 90mm...
  • Page 26 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com ACCESS PROTECTION MULTI-BEAM LIGHT GRID WITH 2, 3, 4 BEAMS...
  • Page 27 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SAFETY LIGHT CURTAINS IN IP69K TRANSPARENT HOUSING...
  • Page 28 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com SAFETY BARRIER IN IP69K TRANSPARENT HOUSING LS2 SERIES...

  • Page 29: Mechanical Dimensions, Barriers And Standard Accessories

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 10.0 MECHANICAL DIMENSIONS, BARRIERS AND STANDARD ACCESSORIES 10.1...
  • Page 30 M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com ST 204 *S FASTENER ACCESSORIES SUPPLIED AS STANDARD...

  • Page 31: Ip69K Models

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 10.2 IP69K models DIMENSIONS OF THE IP69K MODELS Fig.:6;...

  • Page 32: List Of Accessories Applicable To This Product

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 11.0 LIST OF ACCESSORIES APPLICABLE TO THIS PRODUCT...

  • Page 33: Checking The System

    M.D. Micro Detectors LS2 SERIES Strada S. Caterina, 235 LANGUAGE 41122 Modena Italy SAFETY LIGHT CURTAIN TYPE 2 Tel. +39 059 420411 Fax +39 059 253973 Installation and Operation Manual www.microdetectors.com ENGLISH info@microdetectors.com 13.0 CHECKING THE SYSTEM 13.1 Purpose of the checks.

  • Page 34: Guarantee

    15.0 GUARANTEE All new LS2 systems are guaranteed by M.D. Micro Detectors for e period of 24 (twenty-four) months under normal working conditions, against defects due to faulty materials and workmanship. During the aforesaid period, M.D. Micro Detectors promises to replace faulty parts free of charge.
