SHADOW
Quick Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHADOW and is the answer not in the manual?

Questions and answers

Related Manuals for BitFenix SHADOW

Summary of Contents for BitFenix SHADOW

  • Page 1 SHADOW Quick Installation Guide...

  • Page 2: Box Contents

    Box Contents • Shadow Case • Shadow Quick Installation Guide Accessories: Power supply bracket: x 1 Screws: 6-32 Long screws for front fans : x 4 6-32 Flat screws for MB and HDD (black): x 28 6-32 Hex screws for power supply/PCI bracket (black): x 6 M3 Round screws for ODD/SSD (black): x 12 Motherboard standoffs for mATX motherboards (brass): x 2...

  • Page 3: Basic Installation

    Basic Installation Removing side panels Remove thumbscrews Remove side panels Front Side Back...
  • Page 4 Installing 5.25" drives a. Remove ODD bay cover b. Turn counterclockwise and pull drive-locking mechanism c. Slide drive into drive bay d. Replace drive-locking mechanism...
  • Page 5 Installing 3.5" drives a. Turn counterclockwise and pull b. Install drive by sliding into place drive-locking mechanism c. Replace drive-locking mechanism...
  • Page 6 Installing 2.5" drives b. Install device with screws a. Slide 2.5" drive into place M3 Round screws...

  • Page 7: Replacing Side Panels

    Replacing side panels Install side panels Replace thumbscrews...
  • Page 8 Headphone Microphone USB 3.0 USB 2.0 LED color change button LED on/off button Power button Reset button...
  • Page 9 Front Fan Installation Remove front panel Install fans Secure with screws Replace front panel (6-32 Long screws)

  • Page 13: Dust Filters

    Dust Filters a. Remove front filter by pressing down b. Remove front filter by gently pulling out the two top corners c. Remove bottom filter by pulling out...
  • Page 14 3F-10, No.79, Sec. 1, Xin Tai 5th Rd., Xi Zhi District, New Taipei City, Taiwan, R.O.C. For the most updated information, please visit our official website: http://www.bitfenix.com © 2013 BITFENIX Co., Ltd. All Rights Reserved. All trademarks are registered to their respective owners. Ver 1.0 : 2013/08...
