- Page 1 Quick Installation Guide...
-
Page 2: Box Contents
Box Contents • Phenom Micro-ATX Case • Phenom Micro-ATX Quick Installation Guide o Accessories: USB 3.0 to 2.0 Apdater HDD Anti-vibration Washers x 4 Motherboard Standoff grip tool: x 1 (For loosening/tightening MB standoffs) Cable Ties: x 6 5.25" Drive Bay Adapter o Screws: Standard Screw M3*5mm Round: x 25 (For 2.5"... -
Page 3: Basic Installation
Front Back Side Basic Installation Removing side panels Remove thumbscrews Remove side panels... - Page 4 Installing 3.5" drives a. Remove hard disk tray b. Install drives using 6*6mm c. Secure hard disk tray Round screws with screws a. Put drives into place Install drives using 6*6mm Round screws (install heat shield if necessary)
- Page 5 Installing 2.5" drives a. Remove hard disk tray by removing b. Install drives screws c. Secure with screws d. Install tray into place (M3*5mm Round screws)
- Page 6 Installing 2.5" drives a. Slide drives into place b. Secure with screws (M3*5mm Round)
-
Page 7: Microphone Jack
A. SuperSpeed USB3.0 ports B. Headphone jack C. Microphone jack D. Reset button E. Power button... - Page 8 Top Fan Installation (120mm) Remove top filter Install fans Secure with screws Replace top filter...
- Page 9 Bottom Fan Installation (120mm) b. Secure with screws (Remove a. Install fans heat shield if installed) Bottom Fan Installation (230mm) a. Install fan b. Secure with screws (Remove heat shield if installed)
- Page 10 Rear Fan Installation Install fan Secure with screws...
- Page 11 PSU Installation Remove thumbscrew Remove PSU bracket Standard Secure PSU with screws ( Secure with thumbscrew screw 6-32 hex...
- Page 12 Installing 5.25" drive bay adapter Install device using M3*5mm Round b. Use A or B depending on device screws Slide tray into place d. Secure with screws Thumbscrews M3...
- Page 13 Magnetic heat shield (Use when HDDs are installed on the bottom) Magnetic heat shield...
- Page 14 3F, No.79, Sec. 1, Xintai 5th Rd., Xi Zhi District, New Taipei City, Taiwan, R.O.C. For the most updated information, please visit our official website: http://www.bitfenix.com © 2013 BITFENIX Co., Ltd. All Rights Reserved. All trademarks are registered to their respective owners. Ver 1.0 : 2013/09...
