INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
Fits for most 26-55 inches Plasma, LCD and LED TVs .
Weight capacity: 30 kg (66 LBS) .
Thanks for your purchase! We strive to provide products and services of exceptional quality.
We sincerely invite you to write a review with a good rating. If you wouldn't rate any part of your
experience with five star, please contact us immediately by customerservice@mountingdream.com,
so that we may resolve the issue for you.
Max VESA:400X400 mm
MODEL MD2377
(A0)
Advertisement
Table of Contents
Related Manuals for Mounting Dream MD2377
Summary of Contents for Mounting Dream MD2377
- Page 1 INSTALLATION INSTRUCTION Max VESA:400X400 mm MODEL MD2377 Please read this instruction carefully before installation . Fits for most 26-55 inches Plasma, LCD and LED TVs . Weight capacity: 30 kg (66 LBS) . Thanks for your purchase! We strive to provide products and services of exceptional quality.
- Page 2 Thank you for choosing Mounting Dream TV mount. For safe application of model MD2377, and preventing yourself or others from danger or property loss, please read through this manual before use. If you do not understand these instructions or have any doubt over safety of installation, please contact qualified contractor or Mounting Dream customer service.
- Page 3 Si vous ne pouvez pas comprendre ADVERTENCIA! Kongzhongshijie, para garantizar el uso en seguro del modelo MD2377, evitar al usuario y otras personas contratista calificado o Centro de servicio al cliente, Antes de asemblar, verifique cuidadosamente para asegurarse de que no encuentre la falta de piezas o piezas defectuosos , nuestros representantes deservicio al , la asamblea incorrecta o uso incorrecto.
-
Page 4: Installation Tools
For parts shortage or damage, please contact us directly by customerservice@mountingdream.com. Attention: New delivery will be timely arranged to replace missed or defective parts. Installation tools: Installation tools: Spanner Spanner Band tape Band tape Screwdriver Stud finder Pencil Pencil 17-19mm 17-19mm (3/8") (5/32") -
Page 5: Installation Hardware
Installation hardware I--Anchor H--Lag bolt 4pcs 4pcs J--4mm Allen key Hardware for TV installation b--M5X12 bolt c--M6X12 bolt d--M8X16 bolt a--M4X12 bolt 4pcs 4pcs 4pcs 4pcs f--M5X30 bolt g--M6X30 bolt h--M8X40 bolt e--M4X30 bolt 4pcs 4pcs 4pcs 4pcs i--M5/M6 spacer l--M6 washer j--M8 spacer k--M5/M4 washer... -
Page 6: Installation Instruction
Installation instruction Step 3 Step 1 Step 2 (3/8") Put 4 anchors(I) into drilled holes, Concrete wall and tap each anchor flush with Level the wall plate and use wall Use 3/8" diameter drill bit to drill 4 the wall by using a hammer. plate as a template and pencil to holes at marked positions to a Then put 4 lag bolts(H) into the... - Page 7 Select the TV hardware diameter and length Your TV type will help you determine which hardware configuration to use. Hand thread bolts (a, b, c, d, e, f, g, h) into the threaded inserts on the back of your TV to determine the correct bolt diameter (M4, M5, M6 or M8) and length.
- Page 8 Step 4 Attach Brackets to the back of TV For the TV with flat back, mount the wall plate with bolt/washer combination of a+k, b+k, c+l, d. M4 Diameter Bolt M5 Diameter Bolt Attention: Make sure the end of TV bracket (B) with round holes is facing upward.
- Page 9 For TV with irregular back, mount the wall plate with bolt/washer/spacer combination of e+k+i, f+k+i, g+l+i, h+j/m. Attention: Because of the TV with irregular back spacers(i,j) which makes the VESA holes recessed, you might need spacers to fill the gap. Vertical view M4 Diameter Bolt M5 Diameter Bolt...
- Page 10 Step 5 Hang the pre-assembled TV unit on the wall plate unit,then fasten the safety bolt 1 with screwdriver. Attention: Cables are highly recommended to plug in before hanging the TV on the wall plate. Two people are recommended to hold and position the TV.
-
Page 11: Product Dimensions
Step 6 Loosen bolts to adjust the TV plate, and fasten TV plate by bolts with Allen key (J) after adjustment. (figure 1) Pull TV to your desired angle then fasten the two bolts 3 with Allen key (J). (figure 2) Figure 1 Figure 2 Product dimensions:...
