PIG Waste Compactor Manual
DRM655
Air Operated Spark-Resistant Waste Compactor
New Pig
One Pork Avenue
Tipton, PA 16684-0304
newpig.com
North America: 1-800-468-4647
Europe: +31 (0)76 596 92 50
China: +86-21-400 921 5178
PIG, PIG logo are registered trademarks in USA and other countries. See tm.newpig.com
UK: 0800 919 900
Outside North America: +1-814-684-0101
502826 / 359236
Advertisement
Table of Contents
Related Manuals for Pig DRM655
Summary of Contents for Pig DRM655
- Page 1 UK: 0800 919 900 Europe: +31 (0)76 596 92 50 Outside North America: +1-814-684-0101 One Pork Avenue China: +86-21-400 921 5178 Tipton, PA 16684-0304 PIG, PIG logo are registered trademarks in USA and other countries. See tm.newpig.com 502826 / 359236...
-
Page 2: Table Of Contents
Exploded View for DRM655 ........ -
Page 3: Introduction
To determine just how much money a PIG Waste Compactor could save you, we conducted a research study. Our results found that 100% of users significantly reduced the number of drums they sent out for disposal. Compaction ratios ranged from a high of 6:1 to a low of 2:1. -
Page 4: Pig Waste Compactor
PIG Waste Compactor 1 Setup Instructions Remove PIG Waste Compactor from pallet and place on floor. Mount the compactor to the floor using the predrilled holes in the base. Up to ½" floor anchors can be used. Floor anchoring not required for operation (anchors not included). -
Page 5: Operating Instructions
2 Operating Instructions Always wear the proper safety equipment when operating this unit. 1. Open safety cover. 2. Tilt unit back with drum in place to 3. Return to upright locked position and facilitate loading. close safety cover. 4. Move directional lever on air hydraulic 5. -
Page 6: Product Data Sheets
APPLICATIONS To assist in waste minimization, the PIG Waste Compactor allows the user to fit more soft waste in each disposal drum. **IMPORTANT: It is the user’s responsibility to ensure waste entered into drum will not generate a spark by itself, or by coming in... -
Page 7: Exploded View For Drm655
4 Exploded View PIG Waste Compactor — DRM655... -
Page 8: Parts List For Compactor
5 Parts List PIG Waste Compactor — DRM655 Item No. PART No. DESCRIPTION QUANTITY 150122 CENTER SUPPORT 150123 BASE PLATE 150125 A-FRAME 150133 MICRO SWITCH MOUNT 150134 BOTTOM STOP PLATE 150135 PUMP MOUNT BRACKET 150137 TOP STOP PLATE 150138 LATCH COVER... - Page 9 Item No. PART No. DESCRIPTION QUANTITY F1039 #8-32X1/2 RD HD SL MACH SCREW F1048 #10-32X3/8 BUTTON HD SCREW F1049 #10X1.0 HEX WASHER HEAD AB SCW F1054 #10 FLAT WASHER .640X.203X.060 F1065 #10-24X5/8 RD HD SL MACH SCW F1152 1/4-20 CENTER HEX LOCK NUT F1158 1/4-20X1/2 SOCKET SET SCREW F1159...
-
Page 10: Air Schematics
Item No. PART No. DESCRIPTION QUANTITY I360 DRM655/656 PRODUCT DECAL N11-417B 1/4OD P.E. TUBE - BLACK P1015 HYDRAULIC CYLINDER P1032 NYLON WIRE TIES P1087 RING TERMINAL P1090 TAPPED BEAM CLAMP P1091 WIRE TERM LUG P1092 STRND CU WIRE GREEN 6.6667... -
Page 11: Preventive Maintenance
7 Preventive Maintenance 1. Clean Bowl Filter — Keep air dry 2. Add a small amount of air tool oil or lightweight machine oil to air line. Note: An automatic filter/lubricator/oiler may be added to the air line on the unit, but do not over-oil. 3. -
Page 12: Pump Kit For Pig Waste Compactor
Pump Kit for PIG Waste Compactor Waste Pump Assembly Item# DRM345 1 Optional Waste Pump... -
Page 13: Parts List For Optional Waste Pump
5 Parts List Waste Pump Parts List – DRM345 Item No. Part No. Description DRM652 Quantity 150123 Base Plate 150140 Rear Pivot 150150 Pump Guard P1239 Diaphragm Pump 150146 Hose F1938 ⁄ " x 1 ⁄ " Pipe Nipple A116-6 ⁄... - Page 14 Corporation within one (1) year (the “Warranty Period”) of the original retail purchase. This LIMITED WARRANTY only applies to the following enumerated products. New Pig Corporation shall, at its sole discretion, repair the product or replace it with a product of comparable value.
