Maytag MHW5630Hw Quick Reference Manual

NOTE: See your Use and Care Guide for more information.
Not all settings and options are available on each cycle.
Fire Hazard
Never place items in the washer that
are dampened with gasoline or other
flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any
type of oil on it (including cooking oils).
Doing so can result in death, explosion,
or fire.
Cycle Cycle Status
Settings Display
Options
W11219946A
/ ©2018 All rights reserved.
® TM
W11219996A - SP
Used under license in Canada.
Quick Reference Guide
Using Your Front-Loading Washer
1
TOUCH POWER TO
TURN ON WASHER
BEFORE FIRST USE:
2
SET UP OPTIMAL DISPENSER
(on some models)
Your washer comes equipped with an
Optimal Dispenser, which allows you to fill
detergent once and skip refills for multiple
loads. Use HE liquid detergent only.
To Fill Optimal Dispener:
Open the dispenser drawer, gently pull
up on the dispenser lid tab, and fill to the
"MAX" line.
IMPORTANT: Do not use chlorine bleach
or powdered detergent in the Optimal
Dispenser.
3
RUN WASH CYCLE WITHOUT
LAUNDRY
Before washing clothes for the first time,
choose the Quick Wash cycle and run it
without clothes. This initial wash cycle
serves to ensure the interior is clean
before washing clothes.
Power
DOING LAUNDRY:
Button
4
ADD LAUNDRY PRODUCTS,
IF DESIRED
Oxi-type boosters, color-safe bleach, or
scented crystals can be added to the drum
prior to adding laundry.
Start
Button
5
LOAD LAUNDRY
Place a load of sorted
items loosely in the
washer.
IMPORTANT: Push
load fully into the
washer. Make sure no
items are resting on the
rubber seal to avoid trapping them between
the seal and the door window.
6
ADD HE DETERGENT
(on some models)
For Single Load Dispenser models, add
detergent to the appropriate compartment
at this time.
7
ADD LIQUID FABRIC SOFTENER
AND CHLORINE BLEACH TO
DISPENSER, IF DESIRED
8
SELECT A CYCLE
9
SELECT ANY ADDITIONAL OPTIONS,
IF DESIRED
Press the knob to select Extra Power.
Additional options available:
• Cycle Signal • Fresh Hold
• Extra Rinse • Delay Start
• Steam
Refer to the User & Care guide for details
about these additional options.
10
TOUCH AND HOLD START
TO BEGIN WASH CYCLE
Touch and hold START for 3
seconds to start the wash cycle.
To add 1-2 additional garments,
pause the cycle by Touching
START once to add garments;
then touch and hold START
again to continue the cycle. To
cancel a cycle, touch and hold
POWER.
MAINTENANCE
• Run Clean Washer cycle every 30 loads.
• Leave door open for ventilation when
machine is not in use.
• Check door seal between cycles. Clean
out small items and/or debris if present.
SET UP REMOTE ENABLE
(on some models)
First, connect your washer to your home
Wi-Fi network using the WiFi Connect
button (refer to maytag.com/connect or
download the Maytag app for more details).
Then touch REMOTE ENABLE each time
you want to remotely control your washer.
Note that opening the door cancels
Remote Enable.
08/18
