Summary of Contents for Ask Proxima Impact 24

  • Page 1: User Guide

    USER GUIDE IMPACT 24 Not actual front page 801.100B USG/024/AE-B 14.06.95...
  • Page 2 USER GUIDE IMPACT 24...
  • Page 3 USER GUIDE LCD PANEL...
  • Page 4: Table Of Contents

    USER GUIDE TABLE OF CONTENTS INTRODUCTION ... 5 MAIN FEATURES ... 5 SUPPLIED MATERIAL... 6 OPTIONAL MATERIAL ... 6 SETTING UP THE LCD PANEL ... 7 COMPUTER... 8 MOUSE... 9 AUDIO AND VIDEO... 10 USING THE LCD PANEL ... 11 REMOTE CONTROL...
  • Page 5 USER GUIDE LCD PANEL This publication is printed on recycled paper. The information contained in this user guide is preliminary, and the products described herein are subject to change without prior notice..
  • Page 6: Introduction

    USER GUIDE INTRODUCTION The LCD panel is a state of the art projection device that can be connected to most computer and video sources. The ability to display a multitude of colors simultaneously, makes it the ideal choice for presenting computer generated text and graphics, as well as displaying live video.
  • Page 7: Supplied Material

    USER GUIDE SUPPLIED MATERIAL A complete set includes the following components : 1. LCD Panel 2. AV Cable 3. VGA Cable 4. Cable-Adapt. MACII mon 5. Cable-Adapt. MACII comp. 6. Mouse Cable 7. Mouse Adapter seriell OPTIONAL MATERIAL Optional cables and adapters are available for special computer sources. 8.
  • Page 8: Setting Up The Lcd Panel

    USER GUIDE LCD PANEL SETTING UP THE LCD PANEL Switch off all equipment before connecting the components. Be aware of static electricity that may build up, especially in the dry season and when operating on synthetic carpets. Discharge any static electricity by touching a metallic surface before you start.
  • Page 9: Computer

    USER GUIDE COMPUTER Connect the LCD panel, computer, monitor and power supply as shown in the rear foldout. Connect cable (4) between the LCD panel and the computer. Use the Y- split on the computer end to connect the monitor. If you have a Macintosh, EGA, CGA or NEC computer, insert applicable adapters (7) and (8) as described in the table below.
  • Page 10: Mouse

    USER GUIDE MOUSE See the rear foldout when setting up. Connect the mouse to the LCD panel using the appropriate adapter (9) as described in the table below. Then connect the adapter (9) to the mouse cable at the computer end. Finally, connect the mouse cable to the LCD panel (5).
  • Page 11: Audio And Video

    USER GUIDE AUDIO AND VIDEO Connect the LCD panel to a video source as shown in the rear foldout. Use a TV set as a local video monitor if desired (the data monitor may not be used as a video monitor). Connect the AV cable (3) to the AUDIO and VIDEO connectors on the LCD panel.
  • Page 12: Using The Lcd Panel

    USER GUIDE LCD PANEL USING THE LCD PANEL The LCD panel has a set of connectors and controls that you need to know in order to operate the device correctly. REMOTE CONTROL The infrared remote control (RC) is the main user interface to the device. The RC is used to set the LCD panel correctly (to get the best possible viewing conditions) and to control the presentation.
  • Page 13 USER GUIDE REMOTE CONTROL KEYS: CONTROL FUNCTION CONTR Contrast (ratio between light and dark colors) BRIGHT Brightness (whiteness) VOLUME Sound volume control ON/OFF Turns the panel on/off RESET Defaults to standard settings BLACK Blackens the screen PROG This key may be programmed to one of the menu controls MUTE Switches sound on and off...
  • Page 14: Front Panel

    USER GUIDE FRONT PANEL The front panel keyboard consists of a subset of the remote control keys. ON/OFF CONTROL FUNCTION TUNE Adjusts the stability of the image BRIGHT Adjusts the brightness (whiteness) of the image RESET Defaults to factory settings ON/OFF LED activity indicator CONNECTORS...
  • Page 15: Features

    USER GUIDE LCD PANEL FEATURES The LCD panel has a variety of different features implemented. This chapter explains each feature in detail. INTELLIGENT SAFECOOL SYSTEM The fan operation is controlled by the overhead projector light (OHP). This safety feature ensures that the fan is always operating as long as the OHP is turned on.
  • Page 16 USER GUIDE LCD PANEL VGA TEXT VGA text is compressed correctly from 720x400 to 640x400 mode when the image is positioned correctly. The characters maintain their shape, as every ninth pixel is dropped horizontally between each character. Selecting MCGA in the menu will deactivate the text compression. BUILT IN SPEAKER A small monitor speaker is built into the LCD panel.
  • Page 17 USER GUIDE LCD PANEL release the object. DRAG is automatically released 5 seconds after the last key is pressed. POINTER The pointer is a red spot applied to the projected image, and can be moved freely around using the cursor keys. Activating POINTER will deactivate the MOUSE function (as the same cursor keys are used).
  • Page 18 USER GUIDE LCD PANEL to the 'soft' feeling of a low contrast image. Low contrast is recommended for long term viewing, while high contrast is used to enhance details. Use the CONTR keys on the remote control (RC) to adjust the contrast. Also see Brightness.
  • Page 19 USER GUIDE LCD PANEL This switch controls the operation of the panel. When switched on, all functions are active. When switched off, the automatic fan control is still operating, but the image is turned white. The ON/OFF switch is a toggle key.
  • Page 20: Menu System

    USER GUIDE LCD PANEL MENU SYSTEM The menu system was developed to gain access to functions not often used, as opposed to frequently used features that are directly available through the RC. Press the MENU key on the RC to invoke the menu system. When the menu is active, the cursor keys are used to navigate between options (and can therefore not be used for mouse control etc.
  • Page 21 USER GUIDE THE SETUP MENU SELECTIONS: SETUP SOUND TUNE POSITION INVERSE FREQUENCY MAC LC LANGUAGE > OSD HIDE ABOUT TUNE This feature is used to stabilize the image. An untuned image can be seen as sideways instability or ‘ swimming’ . The TUNE function has no effect in VIDEO mode.
  • Page 22 USER GUIDE LCD PANEL MAC LC The MACII series of computers are equipped with slightly different graphic interfaces that need manual setup on the RC to work correctly. Default is the MACII standard interface of 640 x 480 resolution. Pressing the MAC key toggles between the MACII LC 640 x 480 mode and the standard mode.
  • Page 23 USER GUIDE THE SOUND SELECTIONS : SETUP SOUND SOURCE > MONO TREBLE BASS BALANCE SOURCE This controls how AUDIO follows the source. This setting is not memorized (power up defaults to ALL). This setting enables sound regardless of source displayed. VIDEO This function enables sound only when VIDEO is displayed.
  • Page 24 USER GUIDE THE PICTURE SELECTIONS : SETUP SOUND PALETTE Usually, the palette is set to display the maximum number of colors available, regardless of application. Some uses may however be better off with a reduced set of colors, or if special effects like 512 colors on live video is desired.
  • Page 25: Practical Hints And Tips

    USER GUIDE PRACTICAL HINTS AND TIPS This is a list of what to do when things go wrong. Check the symptoms carefully if you experience any problem. The cure may be at your hands! Always press the RESET key and observe that the LED on the LCD panel is flashing.
  • Page 26 USER GUIDE Text is not displayed correctly - Try to position the image horizontally - Check the MCGA setting in the menu The remote control is not working - Check if the batteries need replacement - Be sure to point at the projection screen or directly at the IR eye in the front of the LCD panel - You may be too far away from the panel (max.
  • Page 27: Maintenance

    USER GUIDE LCD PANEL 10 MAINTENANCE From time to time, the housing and protection glasses may be cleaned with a damped, non abrasive cloth, possibly using a mild detergent to remove spots. The upper protection glass is not removable, as it only needs cleaning from the outside (the inside is sealed to the LCD module).
  • Page 28: Technical Data

    USER GUIDE 12 TECHNICAL DATA The technical data may change without prior notice in order to improve the product performance. The apparatus is designed for indoor use and should not be operated outside the general environmental limits, as this may lead to permanent damage and violation of any warranties.
  • Page 29 USER GUIDE DISPLAY UNIT Full color (RGB) unit connecting directly to external video sources. SIZE WEIGHT POWER LCD CELL COLOR RESOLUTION RESPONSE TIME CONTRAST RATIO PIXEL RESOLUTION SCREEN DIAGONAL MOUSE COMPATIBILITY VIDEO FREQUENCY HORIZONTAL SYNC VERTICAL SYNC NTSC SYSTEM PAL SYSTEM SECAM SYSTEM COMPUTER INPUT VIDEO INPUT...
  • Page 30 USER GUIDE POWER SUPPLY Primary switched universal type AC to DC converter. INPUT VOLTAGE OUTPUT VOLTAGES CONNECTOR APPROVALS REMOTE CONTROL Infrared wireless remote control. BATTERIES RANGE COMPATIBILITY The unit is predefined for the following interfaces. In addition, the user can configure the panel for other interfaces with a total maximum of 40 definitions altogether (predefined and user defined).
  • Page 31: Connectors

    USER GUIDE 13 CONNECTORS The pinouts of all external connectors are described. POWER This connector feeds regulated DC power to the panel. MOUSE This connector is used for mouse control. COMPUTER This connector relays all sync and data signals from the computer to the panel and back again to the CRT monitor.
  • Page 32 USER GUIDE S-VIDEO This connector is used as S-VHS video input. VIDEO This connector is used as composite video input. PHONO / RCA FEMALE (FRONT VIEW) AUDIO This connector is used for stereo sound line input. 3.5 mm STEREO JACK (FRONT VIEW) MICROPHONE This connector is used for mono microphone input.
  • Page 33: Fcc Statement

    USER GUIDE 14 FCC STATEMENT This equipment has been certified to comply with the limits for a Class A computing device, pursuant to Subpart J of Part 15 of FCC rules. Only peripherals (computer input/output devices, terminals, printers, etc.) certified to comply with the Class A limits may be attached to a computer that complies with Class A limits.
  • Page 34: Environmental Statement

    USER GUIDE 15 ENVIRONMENTAL STATEMENT This product is manufactured to minimize the stress and pollution of the surroundings. Where possible, recyclable materials are used. ITEM PACKAGING MECHANICS ELECTRONICS LCD MODULE RECYCLING / HANDLING Only recyclable materials are used Only recyclable plastics and metal is used. Recycling codes are moulded in the plastic.
  • Page 35: Service Information

    USER GUIDE 16 SERVICE INFORMATION In cases where a problem cannot be solved by the assistance of your dealer, please call the following number to get an RMA (Return Authorization Number) : +47 69 34 01 55 (Norway) To return the defective unit, package well (preferably using the original packaging material), enclose a copy of your sales receipt and a description of the problem you experience, and ship prepaid to : Customer Service Department...
  • Page 36: Connection Layout

    USER GUIDE LCD PANEL 17 CONNECTION LAYOUT The foldout shows how to connect the LCD panel to the different audio, video and computer sources.
