Summary of Contents for JVC TH-S320B
- Page 1 TH-S320B Audio Home Theater System 2.0 CH Soundbar...
- Page 2 être installé et exploité à une distance minimale de 20 cm entre le radiateur et votre corps. IC: 26551-51H320420B Supplier’s Declaration of Conformity Model No. TH-S320B Trade Name: JVC Responsible Party: Russell Distribution Company Address: 7801 Hayvenhurst Avenue, Van Nuys, Ca 91406 USA Telephone No.
-
Page 3: Important Safety Instruction
Important Safety Instruction Thank you for purchasing the TH-S320B Soundbar. Please read this user manual carefully and keep for future reference. Warning Caution: To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus to rain or moisture. -
Page 4: Important Safety Instructions
Bluetooth SIG, Inc. and any use of such marks by AJS Electronics Limited is under license. Other trademarks and trade names are those of their respective owners. by E & S International Enterprises, Inc. “JVC” is the trademark of JVCKENWOOD Corporation, used by such company under license."... - Page 5 •Place your Sound bar on a level surface such as a table, desk or shelf, conveniently nearby an AC outlet, out of direct sunlight, and away from sources of excess heat, dirt, dust, moisture, humidity or vibration. •Unwind the Line cord connecting the AC adapter and extend it to its full length. Protect Your Furniture This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you operate the controls.
- Page 6 Product Diagram DISPLAY HDMI(ARC) OPTICAL DC IN VOL- POWER/STANDBY VOL+ INPUT...
- Page 7 REMOTE CONTROL 2. Pair button: Press pair button more than 2 seconds to conect and disconect last device. 3. VOL+: to increase the volume. Previous button: Skip to the previous track in USB & BT mode. 5. VOL-: to decrease the volume. 7.
-
Page 8: Operating Range Of The Remote Control
CAUTION Risk of explosion if the battery is replaced by an incorrect type Handling the battery • Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause fire, personal injury or damage to property. • Only use the battery type indicated in this manual. •... -
Page 9: Positioning The Sound Bar
Positioning the Sound Bar Table Placement • Place the sound bar horizontally on a solid surface such as a TV unit or shelves and align it centrally with the TV screen. • For best sound output and good airflow around the soundbar, place your soundbar and subwoofer as shown on the right. - Page 10 backing paper EVA foam (with holes) included Bracket width 0.75 IN EVA foam (without holes) included Mount the unit on a wall When mounting the soundbar on a wall, all installation musted be performed in right way. The customer must never attempt to install it without authorization.
-
Page 11: Auto Standby
" on the sound bar will flicker in the bluetooth pairing mode with a double deep sound. 2. Turn on Bluetooth of your device, search for " TH-S320B " on your Bluetooth list, and then select Bluetooth connection. 3. When successfully paired, you will hear a tone and the "... - Page 12 Notes: 1. In Bluetooth mode, the remote can control music play/pause or select previous or next track. PREV/NEXT/ PLAY & PAUSE button only work in Bluetooth and USB mode; they have no function in other modes. 2. The above pairing procedure doesn’t need to be repeated with the same connected device once paired. 3.
-
Page 13: Optical Mode
Optical Mode -Remove the cap of optical cable (keep the cap for the future use); check the direction of the plug. Connect the sound bar and TV with the optical cable. -Use this mode to play music from a TV with optical digital output on the sound bar. In TV sound settings, select the sound bar optical connection (output for audio). - Page 14 PROBLE/TROUBLE POSSIBLE CAUSE SOLUTION Another input source is selected. Select an appropriate input source. Cancel the mute function. The mute function is activated. The volume of sound bar or TV/other device Increase the volume level on sound bar or is adjusted too low. by remote control or on TV.
- Page 15 PROBLE/TROUBLE POSSIBLE CAUSE SOLUTION Sound quality of audio Move the device closer to the sound bar, play from a connected or remove any obstacle between the device and The Bluetooth reception is poor. Bluetooth device is the sound bar. poor and connection is not stable.
-
Page 16: Package Contents
Remote Control X 1 Wall Mounting Line in to RCA Cable X 1 User Manual X 1 Remote control battery Bracket Sets X 1 Specifications Model TH-S320B Technology BT/USB/AUX/HDMI(ARC)/OPT Drivers 2.5"*2 Audio Output Power 150W Peak Power Frequency Response 70Hz-20KHz... - Page 17 This product is manufactured, distributed, serviced and warranted exclusively by E & S International Enterprises, Inc. “JVC” is the trademark of JVCKENWOOD Corporation, used by such company under license. To obtain a warranty service, please call 1 (888) 582-8870 or send an email to...
- Page 18 Claims and Dispute Resolution RUSSELL DISTRIBUTION COMPANY, LLC AND YOU AGREE THAT ALL CLAIMS OR DISPUTES ARISING IN ANY WAY FROM THIS LIMITED WARRANTY OR THE SALE, CONDITION OR PERFORMANCE OF THE PRODUCT, WHETH- ER BASED IN CONTRACT, TORT, STATUTORY, FRAUD, MISREPRESENTATION OR ANY OTHER LEGAL THEORY, AND ALL CLAIMS THAT ARE SUBJECT OFA PURPORTED CLASS ACTION LITIGATION THAT YOU ARE NOT A MEMBER OF THE CERTIFIED CLASS, SHALL BE RESOLVED THROUGH ARBITRATION AS PROVIDED FOR HEREIN, OR IN SMALL CLAIMS COURT, AND NOT BY A...
- Page 19 Audio Home Theater System 2.0 CH Soundbar TH-S320B Use our Customer Service to assist you in setting up your new product. Visit: or Call: Notre personnel d'assistance expérimenté est là pour vous aider! nouveau produit Visitez: or Appelez:...
