Page 2: General Assembly Guidelines
A Phillips head screwdriver is required for the assembly of this product. VII. Power tools should not be used to assemble this product. VIII. Drill may be needed for securing product to wall. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. - Page 5 Insert wooden dowel (A) into part (7), then secure cam bolt (B) into part (1) with Philips head screwdriver as per diagram.
- Page 6 Step 2 Secure cam bolt (B) into parts (8,9,10) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 7 Step 3 Insert wooden dowel (A) into parts (5,6), then secure cam bolt (B) into parts (5,6) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 8 Step 4 Insert wooden dowel (A) into parts (3,4,12) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 9 Step 5 Using cam lock(C) secure part (9) into parts (5,6) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved.
- Page 10 Step 6 Using cam lock(C) secure part (10) into parts (4) ,part (8) into part (3) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.10...
- Page 11 Step 7 Finished edge Using cam lock(C) secure part (5) into parts (12) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.11...
- Page 12 Step 8 Using cam lock(C) secure part (6) into parts (12) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.12...
- Page 13 Using cam lock(C) attach parts (8,10) into part (7) with Philips head screwdriver as per diagram.
- Page 14 Step 10 Using screw (D) attach part (2) into parts (5,6) with hex key (E) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.14...
- Page 15 Step 11 Secure part (18) into part (2),then using screw (D) attach part (2) into parts (3,4) with hex key (E) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.15...
- Page 16 Step 12 Using bolt (F) attach connector (M) to parts (14,15,16) with hex key (E) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.16...
- Page 17 Step 13 Using bolt (F) attach connector (L) to parts (14,15,16) with hex key (E) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.17...
- Page 18 Using bolt (F) attach connector (M) to part (2) with hex key (E) as per diagram.
- Page 19 Step 15 Put part (13) as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.19...
- Page 20 Step 16 Using cam lock(C) secure part (1) to parts (3,4,5,6,7) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.20...
- Page 21 Step 17 Using screw (S) secure plastic wedge (N) to part (13) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.21...
- Page 22 Place sticker (P) cover the holes as per diagram .
- Page 23 (G) in the same level. So the shelf is not titled .Put part (11) into unit as per diagram. Tilt and rest the adjustable shelf(11) onto the shelf support pins . © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.23...
- Page 24 Step 20 Using bolt (R) secure pulley (K) into part (17) ,then using screw (J) attach plate (Q) into part (17) with Philips head screwdriver as per diagram. © Copyright 2019, by Walker Edison Furniture Co., LLC. All rights reserved. P.24...
- Page 25 Place plate (Q) on door into groove.
- Page 26 Hang pulley (K) to part (7), then press down to hold the door.
- Page 27 if necessary, adjust the pre-attached Floor Levelers at the bottom to level the unit.
