Status Word — B Format
C.2.8
Bit 0
C.2.9

Valid Command Response

NOTE This is embedded in the header for the DATA and PARAMETER type transfers.
Byte # Data (hex)
1 0x06
C.2.10 Data Acquisition Complete (Returned in Both Free-Run and Triggered
Modes)
Byte # Data (hex)
1 0x04
NOTE 1) Returned data is in 8-bit binary format.
2) Check sum is a 16-bit sum of all data and header information sent per packet.
C.3 Multiplicity Counter Communications Protocol and Commands
Ver. VI (Six Acquisition Modes)
C.3.1

BAUD Rate and Format

• 9600, 14.4K, 19.2K, 38.4K, 57.6K, 115.2K BAUD
• (BAUD Sw = 6, 3, 5, 4, 1, 0 respectively)
• 1 start bit
Bit 1 Bit 2 Bit 3
Description
CTRL+'F' character sent when a valid command is recognized.
Description
CTRL+'D' character sent at the end of the acquisition cycle.
APPENDIX C. FIRMWARE COMMANDS
Bit 4 Bit 5 Bit 6 Bit 7
