PYRO 1394 PCI Card Hardware Installation
Step 1
Power down your computer and discon-
nect the power cord. Be sure to remove
the power cord completely from your
computer as shown in the picture to the
left.
Step 2
Remove the screws that hold the
panel/shell of your computer (located
on the back of the computer). Be sure
to put the screws you removed in a
safe place, as you will need them
again when replacing the shell on your
computer.
Step 3
Carefully remove the panel/shell from
your computer.
Step 4
With the power cable disconnected
from your computer, touch the metal
part of the case to ground yourself.
This will discharge any static electricity
from your body which can damage your
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Pyro Industries API-1394PCI
- Page 1 PYRO 1394 PCI Card Hardware Installation Step 1 Power down your computer and discon- nect the power cord. Be sure to remove the power cord completely from your computer as shown in the picture to the left. Step 2 Remove the screws that hold the panel/shell of your computer (located on the back of the computer).
- Page 2 Step 5 Locate an available PCI expansion slot (usually white/beige in color). This will be in the area of your computer where other cards that look similar to the PYRO PCI card are installed. Step 6 Visually confirm that the PYRO 1394 PCI Card will fit into the available slot you have chosen.
- Page 3 Step 9 (optional) Connect the molex power supply to the PYRO card power connector. Step 10 Mount the PYRO 1394 PCI Card in place with a screw. Make sure the screw is firmly tightened so the PYRO 1394 PCI Card does not slide out of its seated position.
