4xem 4X-IP7161 Specifications

Day/Night 2.0 Megapixel
PoE Network Camera
4X-IP7161
The 4XEM 4X-IP7161 is a high performance 2.0 Megapixel Network Camera with
true day and night functions ideally suited for wide, open spaces such as building
entrances and airports, or applications requiring accurate identification of individuals,
objects, and vehicle license plates.
With high-definition 2-megapixel (1600 x 1200) resolution, the IP7161 can deliver
extremely clear and detailed images and provide coverage six times larger than a
standard VGA camera. The ePTZ function enables users to quickly move to a target
area for close-up live video without physically moving the camera. In addition,
multiple video streams can be delivered simultaneously in different resolutions,
frame rates and image qualities for viewing on different platforms, so as to meet
different needs or bandwidth constraints. You can watch and record on a PC at one
frame rate and resolution, while also watching on a 3G enabled device like a cell
phone or PDA at a different frame rate and resolution.
To consistently maintain superior image quality during 24-hour surveillance, the 4X-
IP7161 comes with a built-in removable IR-cut filter and an auto-iris lens to adapt to
frequent light changes. For safe and secure monitoring, the 4X-IP7161 also supports
tamper detection providing immediate alerts if the camera is blocked, redirected, has
a change in focus, or is spray-painted. The exceptional activity adaptive streaming
can optimize bandwidth usage by allowing for a low frame rate in normal monitoring
and a high frame rate during event-triggered recording.
The 4X-IP7161 includes other advanced features such as a C/CS-mount adjustment
ring, SD/SDHC card on-board storage, 802.3af compliant PoE, two-way audio via SIP
protocol, and HTTPS encrypted data transmission.
This camera can be used in conjunction with any of our other cameras in our free
32 Channel Central Management Software, a comprehensive professional level
surveillance application.
Features:
• 2.0 megapixel CMOS Image Sensor
• 4.5 ~ 10 mm Vari-focal, Auto-iris Lens
• Removable IR-cut Filter for Day and Night Function
• Real-time MPEG-4 and MJPEG Compression (Dual Codec)
• Multiple Streams Simultaneously
• ePTZ for Data Efficiency
• Activity Adaptive Streaming for Dynamic Frame Rate Control
• Tamper Detection for Unauthorized Changes
• Built-in 802.3af Compliant PoE
• Two-way Audio via SIP Protocol
• Built-in SD/SDHC Card Slot for On-board Storage
• CS- or C-mount Adjustment Ring for Flexible Lens Installation
• 32-Channel Professional Monitoring and Recording Software
4.5-10.0mm Variable Focus CS Mount Auto Iris Lens
2-way
Audio
DAY
NIGHT
Supports
3GPP
Megapixel
INCLUDES:
Mounting Bracket
Power Supply
32 Camera Software CD
T a m p e r
Detection
F R E E
32 Camera
Monitoring & Recording
S o f t w a r e
2 YEAR
Warranty
Built-in
PoE
