4xem 4X-IP7160 Specifications

Indoor/Outdoor 2.0 Megapixel
PoE Network Camera
4X-IP7160
The 4XEM 4X-IP7160 is a cost-effective 2.0 Megapixel Network Camera ideal for loca-
tions and situations requiring accurate identification such as banks and airports.
With high-definition 2-megapixel (1600 x 1200) resolution, the 4X-IP7160 can de-
liver extremely clear and detailed images and provide coverage 6 times larger than
a standard VGA camera. The ePTZ function enables users to quickly move to a target
area for close-up live video without physically moving the camera. In addition, mul-
tiple video streams can be delivered simultaneously in different resolutions, frame
rates and image qualities for viewing on different platforms, so as to meet different
needs or bandwidth constraints. You can watch and record on a PC at one frame
rate and resolution, while also watching on a 3G enabled device like a cell phone
or PDA at a different frame rate and resolution.
The 4X-IP7160 supports tamper detection, which detects data loss from camera
tampering in real-time. When the camera is blocked, redirected, or spray-painted,
it can provide immediate alerts in accordance with camera settings. In order to
make more efficient use of bandwidth by reducing transmission of unnecessary
data, the 4X-IP7160 features an SD/SDHC card slot for on-board storage, which also
prevents data loss due to network disconnection. The integrated 802.3af compliant
PoE function reduces cabling requirements, making the 4X-IP7160 a cost-effective
surveillance solution.
The 4X-IP7160 includes other advanced features such as simultaneous multiple
streams, two-way audio via SIP protocol, and HTTPS encrypted data transmission.
This camera can be used in conjunction with any of our other cameras in our free
32 Channel Central Management Software, a comprehensive professional level
surveillance application.
Features:
• 2.0 Megapixel CMOS Image Sensor
• Auto-iris Lens (Optional)
• Real-time MPEG-4 and MJPEG Compression (Dual Codec)
• Multiple Streams Simultaneously
• ePTZ for Data Efficiency
• Time-shift Streaming for Recording Pre- and Post-event Video
• Detects Tampering from Blockage, Redirection or Spray-painting
• 3GPP Mobile Surveillance
• Built-in 802.3af Compliant PoE
• Two-way Audio via SIP Protocol
• Built-in SD/SDHC Card Slot for On-board Storage
• Includes Free Standard 32-CH ST7501 CentraManagement Software
Mounting Bracket
4.2mm Fixed Focus Lens
Power Supply
32 Camera Software CD
2-way T a m p e r
Audio Detection
F R E E
Supports
32 Camera
Monitoring & Recording
3GPP
S o f t w a r e
2 YEAR
Megapixel
Warranty
Built-in
PoE
INCLUDES:
