- Page 1 SAS iba Industrial Computer Manual Issue 1.4...
- Page 2 Required corrections are contained in the following regulations or can be downloaded on the Internet. The current version is available for download on our web site http://www.iba-ag.com. Protection note Windows® is a label and registered trademark of the Microsoft Corporation. Other pro- duct and company names mentioned in this manual can be labels or registered trade- marks of the corresponding owners.
-
Page 3: Table Of Contents
5.3.2 Notes....................... 14 5.3.3 Basic procedure ....................14 5.3.4 Installing special graphic card ................. 14 Installing operating system and iba software..........16 Installing Windows XP with the Recovery DVD ..........16 6.1.1 First Steps ....................... 16 6.1.2 Selecting drive ....................16 6.1.3... - Page 4 Manual ibaOfficeline SAS Support and contact ..................28 Issue 1.4...
-
Page 5: About This Manual
SAS Manual About this manual This manual describes operation of the industrial PC ibaOfficeline SAS. Target group This manual addresses in particular the qualified professionals who are familiar with han- dling electrical and electronic modules as well as communication and measurement tech- nology. -
Page 6: Symbols Used
- By an electric shock! - Due to the improper handling of iba software products which are coupled to input and out- put procedures with control function! If you do not observe the safety instructions regarding the process and the system or ma-... -
Page 7: Scope Of Delivery
SAS Manual Scope of delivery After unpacking check the completeness and intactness of the delivery. The scope of delivery includes: Industrial PC ibaOfficeline SAS PS2 keyboard Mouse (USB/PS2), optical Mains cable Documentation For installed special graphic card there is an additional DVI/VGA adapter cable ... -
Page 8: Safety Instructions
Manual ibaOfficeline SAS Safety instructions Designated use The device may be used only for the following applications: Machine test and commissioning of industrial systems Measurement data logging and analysis Applications of ibaSoftware products (ibaPDA, ibaLogic etc.) Proper installation The device can be installed only according to manufacturer's specifications: ... -
Page 9: Description
SAS Manual Description Front view 1 Optical drive with integrated writing function 2 Plug-in slots for hard disks 3 Indication of hard disk access/ready for operation (LEDs) 4 Multi-card reader with USB interface 5 Power button 6 Reset button 7 Fan unit (2 x Ø... -
Page 10: Side View
Manual ibaOfficeline SAS Side view 1 Door lock 2 Connections, external devices Note The FireWire connection is not assigned. Rear view 1 Power supply 2 Connections, external devices 3 Fan Ø 12 cm 4 Hard disk controller 5 Slots for cards... -
Page 11: Internal View
SAS Manual Internal view 1 Optical drive with integrated writing function 2 Plug-in slots for hard disks 3 Fan Ø 12 cm 4 Fan Ø 12 cm 5 Power supply 6 Fan Ø 12 cm 7 Fan /CPU fan... -
Page 12: Setup
Manual ibaOfficeline SAS Setup Installation Place the device only in the location which has the following properties: - Stationary - Shock-free - In the protected room, for example switch cabinet - Dust-free and dry environment - Even and non-slip support Note If you embed the device, observe the minimum bending radii of the cables and lines. -
Page 13: Connection
SAS Manual Connection Electric Shock! Never use the device with a damaged mains cable! Connect the device to one supply voltage only according to specifications on the built- in power supply unit! Always use a socket equipped with earthing contact! Use a terminal strip with over-... -
Page 14: Notes
If you want to use the 2nd monitor, it is necessary to install an additional special graphic card. The special graphic card has the iba order number 43.900.511. The DVI/VGA adapter cable is included into the graphic card scope of delivery. - Page 15 SAS Manual Special graphic card Chip set: NVIDIA Quadro NVS 290 x1 nView Enabled: Bus Interface: PCI Express x1 Max Displays/Board: Power: 21 W Monitor port: DMS-59 DVI adapter cable VGA adapter cable Issue 1.4...
-
Page 16: Installing Operating System And Iba Software
Manual ibaOfficeline SAS Installing operating system and iba software The delivery includes the Recovery DVD for the operating system stated in your order. If you want to install Windows XP continue with chapter 6.1, if you want to install Windows 7 or Windows 2008 Server continue with chapter 6.2. -
Page 17: Selecting Partitions
2 partitions are possible: System: system partition with Windows Data Files: empty data partition To distinguish the system data from the measurement data logically, iba recom- mends you to select both partitions. 3. Close the dialog using <Next>. 4. Select in the „Selection Destination Partition or Unallocated Space“ dialog the des- tination partition or the hard disk. -
Page 18: Specifying Settings
Manual ibaOfficeline SAS 6. If you have installed a new unformatted hard disk, select it and click <Next>. If the hard disk is larger than the partition which you want to recover, the "Resize Option" dialog will be displayed. 7. Select the "Leave remaining unused space" option. -
Page 19: Select The Language
SAS Manual Note No liability is assumed for the loss of data due to incorrect handling. Always make sure, that you select the correct drives and partitions. 6.2.2 Select the language When the installation has started, you can select the sytem language to be installed. When using Windows 7 or Windows 2008 Server the language can be changed subsequently. -
Page 20: Partitioning
Manual ibaOfficeline SAS Confirm with <No>. 6.2.4 Partitioning There are several possibilities to set up partitions: Set up a new drive completey as system drive Set up partitions on a new drive Install an operating system on a drive already used (Windows 7 or Windows 2008 Server) ... - Page 21 SAS Manual Possibility 2: Partitioning the new drive You use a new drive and want to set up partitions. 1. Click <Drive Options (advanced)> 2. Click <New> 3. Enter the partition size 4. Confirm with <Apply> 5. Mark the partition, where the operating system should be installed 6.
- Page 22 Manual ibaOfficeline SAS 3. Click <Format> 4. Confirm with <OK> 5. Mark the primary partition (normally the smaller one) 6. Click <Format> 7. Confirm with <OK> 8. Click <Next> and continue with chapter 6.2.5 „Completing installation“. Possibility 4: Recovery Windows 2008 Server The drive is already in use and you want to install the operating system.
- Page 23 SAS Manual Possibility 5: Substitute Windows 7 with Windows 2008 The drive is already in use and you want to replace the operating system. 1. Click <Drive Options (advanced)> 2. Mark the system partition 3. Click <Delete> 4. Confirm with <OK>...
-
Page 24: Completing Installation
Manual ibaOfficeline SAS The drive is already in use and you want to replace the operating system. 1. Click <Drive Options (advanced)> 2. Mark the primary partition (normally the smaller one) 3. Click <Delete> 4. Confirm with <OK> 5. Mark the unpartitioned space 6. -
Page 25: Device And Installation Dimensions
SAS Manual Device and installation dimensions Device dimensions (Dimensions in mm) Installation dimensions (Dimensions in mm) Issue 1.4... -
Page 26: Technical Data
Manual ibaOfficeline SAS Technical data Main data Manufacturer iba AG, Germany ° ° Working temperature range C to 55 ° ° Storage temperature range C to 70 ° ° Transport temperature range C to 70 Cooling Fan cooling Fan current... -
Page 27: Order Numbers
SAS Manual Order numbers ibaOfficeline SAS industrial PC Order number ibaOfficeline SAS, Core 2 Quad 3 GHz 40.004101 Issue 1.4... - Page 28 Koenigswarterstr. 44 90762 Fuerth Germany Phone: +49 911 97282-0 Fax: +49 911 97282-33 E-Mail: iba@iba-ag.com Contact: Mr. Harald Opel Regional and Worldwide For contact data of your regional iba office or representative please refer to our web site www.iba-ag.com. Issue 1.4...
