What's in the Box

1. TruWITNESS Sensory

2. TruWITNESS Power/Communications/Storage Pack (PCS)

3. Mounting Hardware

4. 'L' and 'T' Cables (L - normal use, T - using a USB charging source.)
5. Wearer's Quick Guide (this document)
1. TruWITNESS SENSORY

2. TruWITNESS PCS

(Power/Communications/Storage Unit)
3. Mounting Hardware
Safety Glasses
Collar/Cap
Attaching Sensory to Mount
1. Plug the cable into the Sensory.
2. Slide the sensory into the mount with
the bottom toward the release clip (1)
3. Push until there is a click
Note: When mounted, the cable cannot be detached from the sensory unless removed from the mount
TruWITNESS Wearer's Quick Guide
Vest/Epaulette
1/4" - 20 Fixed
The mounts use a universal mounting clip, making
the process the same for all types.
The Wearable Sensory includes:
·
Hi-Res Camera
·
User controls
·
User and Ambient Microphones
·
Speaker
·
Gyroscope, Accelerometer
·
Optional attachment hardware, giving flexible wearer options.

Sensory Controls

ALARM
FLIR Logo Button
(Long Press)
The Power/Communications/Storage Unit shows:
·
Status Display (OLED)
The PCS display shows the User the unit's key status indicators
- Battery level, Communications status,
On-board Recording status
·
Battery Condition
- when below 20% the user will also get a 'low battery' message
·
Communications Status
- shows 3G/4G status
·
(Reserved for future use)
·
Recording status
- The PCS records continuously (even when in Live mode),
except when the user sets it to 'Privacy'
·
Text Message
- The default message shows the User Name.
Other Status messages listed overleaf.
FLIR Logo Button
Privacy On/OFF
Top/Bottom
together

4. 'L' and 'T' Cables

Detaching Sensory from Mount
1. Pull the release clip out, away from the
sensory (1)
2. Push the sensory from the bottom in
the direction of the lens
EVENT
(Short Press)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TruWITNESS Wearer and is the answer not in the manual?

Questions and answers

Summary of Contents for FLIR TruWITNESS Wearer

  • Page 1 TruWITNESS Wearer's Quick Guide What's in the Box 1. TruWITNESS Sensory 2. TruWITNESS Power/Communications/Storage Pack (PCS) 3. Mounting Hardware 4. 'L' and 'T' Cables (L - normal use, T - using a USB charging source.) 5. Wearer's Quick Guide (this document) 1.
  • Page 2 3. Where activated by the system, each user will get an email for each Alarm or Event containing the related recordings, so that they can be reviewed. pr oduct.enter pr is e.s uppor t@flir .com FLIR Sys tem s , Inc.
  • Page 3 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 Canada, Industry Canada (IC) Notices This device complies with Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Canada, avis d'Industry Canada (IC) Cet appareil est conforme avec Industrie Canada exemptes de licence RSS standard(s).
