3Com Router Safety, Regulatory, and Compliance Information

Interface Card Installation and Removal

Note:
When plugging the interface card , the operator should not push it too hard, otherwise the pins on
the backplane may be distorted.
The board should be inserted along the slot guide. Try to avoid contact between he circuit sides
of the board and other boards, which will result in short-circuit or scratch.
When holding a board in hand, do not touch the board circuit, components, connectors, and
connection slots.

Routing of Signal Lines

Note:
Signal lines should be routed separately from high current lines or high voltage line. The spacing
of the binding should be 150mm at minimum.
22
