  • Page 1 COMPOUND MITRE SAW 210MM BMS2101 223748...

  • Page 2: Table Of Contents

    CONTENTS GENERAL POWER TOOL SAFETY WARNINGS COMPONENT LIST ACCESSORIES TECHNICAL DATA SYMBOLS NOISE INFORMATION OPERATING INSTRUCTIONS MAINTENANCE ENVIRONMENTAL PROTECTION PLUG REPLACEMENT (ONLY FOR REWIRABLE PLUG OF UK & IRELAND) DECLARATION OF CONFORMITY...

  • Page 3: General Power Tool Safety Warnings

    ORIGINAL INSTRUCTION GENERAL POWER TOOL SAFETY WARNINGS WARNING: Read all safety warnings, 3) Personal safety instructions, illustrations and specifications a) Stay alert, watch what you are doing and use provided with this power tool. Failure to follow all common sense when operating a power tool. instructions listed below may result in electric shock, fire Do not use a power tool while you are tired or under and/or serious injury.
  • Page 4 and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
  • Page 5 j) Ensure the mitre saw is mounted or placed on a level, firm work surface before use. A level and firm work surface reduces the risk of the mitre saw becoming unstable. k) Plan your work. Every time you change the bevel or mitre angle setting, make sure the adjustable fence is set correctly to support the workpiece and will not interfere with the blade or the guarding system.

  • Page 6: Component List

    COMPONENT LIST...

  • Page 7: Accessories

    Operating handle Work clamp Lower blade lock lever Bevel lock knob Upper fixed guard Release knob Blade bolt cover Dust extraction port Lower rotating guard Dust bag Brace Carry handle Fence On/off switch Rotating mitre table Mitre table lock knob Mitre table adjusting handle Work clamp lock knob Mounting hole (x4)

  • Page 8: Symbols

    SYMBOLS To reduce the risk of injury, read all of this instruction manual Warning Wear ear protection Wear eye protection Wear dust mask Double insulated Waste electrical products must not be disposed of with household waste. Please recycle where facilities exist. Check with your local authorities or retailer for recycling advice.

  • Page 9: Noise Information

    NOISE INFORMATION A weighted sound pressure : 97 dB(A) A weighted sound power : 110 dB(A) & K 3.0 dB(A) Wear ear protection. The declared noise emission value has been measured in accordance with a standard test method and may be used for comparing one tool with another.

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. Intended Use The machine is intended as a stationary machine for making straight lengthways and crossways cuts in wood. Horizontal mitre angles of 0° to +45° as well as vertical bevel angles of 0° to +45° are possible. ASSEMBLY WARNING: To prevent the accidental starting that could cause possible serious personal injury, ALWAYS assemble all parts to your saw BEFORE connecting it to the power supply.
  • Page 11 Fig. B1 Fig. B2 Fig. B3 Fig. B4 Fig. B5 Fig. B6...
  • Page 12 3. WORK CLAMP (SEE FIG. C) When cutting workpieces, they should always be clamped with a work clamp. The work clamp can be fitted on either side of the saw and is fully adjustable to suit the size of the workpiece. To install the work clamp, just insert it into the hole located at rear of the fence on either side of the base plate.
  • Page 13 BEFORE OPERATION 1. RELEASE KNOB (SEE FIG. E1-E3) The release knob is provided for holding the saw head down while transporting or storing the mitre saw. When boxed, during storage or transportation, ensure the saw head is locked in the down position. To release the head ready for operation, apply downward pressure on the operating handle, pull out the release knob and allow the head to rise to the upper position.
  • Page 14 2. MITRE TABLE LOCK (SEE FIG. F1, F2) The mitre saw cuts from 0° to 45° only in the left side (the saw blade is facing to the operator). To adjust the mitre angle, first loosen the mitre table lock knob by turning it anti-clockwise. Then hold the rotating mitre table handle and move the handle to the left in order to adjust the rotating mitre table to a desired angle.
  • Page 15 Fig. G3 Fig. G4 4. SPINDLE LOCK BUTTON (SEE FIG. H) Fig. H The spindle lock button prevents the blade in the saw from rotating. Depress and hold the spindle lock button while installing, changing, or removing the blade. OPERATION Fig.
  • Page 16 2. CROSS CUT (SEE FIG. J) A crosscut is made by cutting across the grain of the workpiece. A 90° crosscut is made with the mitre table set at 0°. 1) Connect the machine to power outlet ensure that the mains cable is clear of the blade and base plate. 2) Position the material to be cut on the rotating mitre table with one edge securely against the fence, ensure it is firmly clamped with the work clamp so that it will not move during cutting.
  • Page 17 Fig. J Fig. K Fig. L Fig. M...

  • Page 18: Maintenance

    MAINTENANCE Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of dust.
  • Page 19 2. CHANGING THE SAW BLADE (SEE FIG. O1-O4) Fig.O1 WARNING: To prevent personal injury, always disconnect the plug from power source before assembling parts, making adjustments or changing blades. 1) Unplug the saw from the power supply. 2) Release and raise the saw head to its fully raised position.

  • Page 20: Environmental Protection

    ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. PLUG REPLACEMENT (ONLY FOR REWIRABLE PLUG OF UK & IRELAND) If you need to replace the fitted plug then follow the instructions below. IMPORTANT The wires in the mains lead are colored in accordance with the following code: Blue = Neutral...

  • Page 21: Declaration Of Conformity

    DECLARATION OF CONFORMITY Wickes Building Supplies Limited Declare that this product: COMPOUND MITRE SAW Description and SKU code: 223748 Complies with the following Directives and Regulations: 2006/42/EC, Machinery Directive 2014/30/EU, Electromagnetic Compatibility Directive 2011/65/EU & (EU)2015/863 (RoHS), Restriction of Hazardous Substances Directive...
