INSTALLATION CERTIFICATE
The undersigned qualified installer, attests having personally fitted
the GPS system on the vehicle specified below, following the
manufacturer's instructions.
By :
P roduct type :
Sold on :
.............
7892 MyMINI
Vehicle :
INSTALLATION AND
Signature
..........................................................................................
USE MANUAL
Homologation number: AI-00 0112
UK
GEMINI Technologies S.r.l.
Via Luigi Galvani 12 - 21020 Bodio Lomnago (VA) - Italia
Tel. +39 0332 943211 - Fax +39 0332 948080
www.gemini-alarm.com
ISO 9001 Certified Company
AC 2690UK Rev.10 - 01/17
Made in Italy
