Starting Eunhasu
Eunhasu
Eunhasu is Web-based GUI to control network music players which was made on Linux OS. It has easy
and simple to use functions via a Web GUI. Eunhasu can be used with PCs or various apps in smart
devices.
Eunhasu features
Web GUI
Easy system configuration
Selectable music player applications
Selectable and configurable USB audio devices
Network share folder and USB storage device setting
Roon Ready
Roon Server
sMS-1000SQ
MinimServer
sMS-1000SQ
DLNA audio renderer, OpenHome support
MPD (Music Player Daemon)
LMS (Logitech Media Server)
Squeezelite
HQPlayer Network Audio Adapter
Shairport
LibreSpot
Multi-zone network playback
Models available with Eunhasu
sMS-200
sMS-200ultra
sMS-1000SQ
Services
Please click a link to show a description of each service.
sMS-200 and sMS-200ultra services
Roon Ready
Squeezelite / Logitech Media Server
MPD / DLNA renderer
SOtM docs - http://docs.sotm-audio.com/
feature
feature
1/20
Starting Eunhasu
Advertisement
Table of Contents
Related Manuals for SOtM sMS-200
Summary of Contents for SOtM sMS-200
- Page 1 Multi-zone network playback Models available with Eunhasu sMS-200 sMS-200ultra sMS-1000SQ Services Please click a link to show a description of each service. sMS-200 and sMS-200ultra services Roon Ready Squeezelite / Logitech Media Server MPD / DLNA renderer SOtM docs - http://docs.sotm-audio.com/...
- Page 2 Eunhasu Web GUI, check the router setup to find out the IP address of your device . And then enter your device's IP address like (e.g. sMS-200 or sMS-1000SQ) http://xxx.xxx.xxx.xxx directly into the browser to connect to the Eunhasu Web GUI. If you still can’t access the Eunhasu Web GUI, you will need to check that your network status or power connection is okay.
-
Page 3: Select Functions
To select a function on the Web GUI, mouse over the desired icon and action buttons( ) will appear. On smart devices, touch the desired player icon and then the action buttons will appear like when using a mouse. SOtM docs - http://docs.sotm-audio.com/... - Page 4 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start For example, in the case of the Roon Ready service, you can change states to 'Active' by icon click. 'Active' states. Not only Roon Ready service but other services have a similar screen. http://docs.sotm-audio.com/...
-
Page 5: System Setup
Change general config Host name: The name of the sMS-200 which appears on the network. If you use multiple Eunhasu-enabled device on the network, you will need to use a different host name for each... - Page 6 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start device. English only and no spaces are allowed for the name. Workgroup: A workgroup name for shared folders on the network, normally “WORKGOUP” is used, but can change if required. English only and no spaces are allowed for the name.
-
Page 7: Library Setup
2020/08/18 19:36 7/20 Starting Eunhasu Wifi setup Please refer to how_to_use_wifi_in_eunhasu page. Library setup Set up the path for the network library and enable the USB storage device to use. SOtM docs - http://docs.sotm-audio.com/... - Page 8 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start NAME: A library folder name appearing on Logitech Media Server or MPD. Only English, no spaces or numbers. PATH: A network sharing folder path. The path should be formatted like the screen shot. ID: Enter an ID if it is required to access the network sharing folder.
- Page 9 You can access the Eunhasu share folder to manage music files. Select 'EUNHASU' in the 'Network' part of Explorer. If you have serveral Eunhasu-enabled devices, please change system name because it could cause conflict in the network. You can access by the direct path, \\EUNHASU\mwdata\music SOtM docs - http://docs.sotm-audio.com/...
- Page 10 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start The image below shows the screen after you enter 'mwdata'. ;mwdata' is a name of share folder in Eunhasu. If you want to copy files into the sMS-1000SQ music directory, drag and drop files to the path, \\EUNHASU\mwdata\music, like the screen shot below: http://docs.sotm-audio.com/...
- Page 11 If you want to check the music files in the external USB storage drive connected into sMS-1000SQ, please check the path, \\EUNHASU\mwdata\music\USB1 Mac OS You can access Eunhasu share folder by Finder. Please connect as 'Guest' id to access. SOtM docs - http://docs.sotm-audio.com/...
-
Page 12: System Upgrade
Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start System upgrade Upgrade your system. Upgrade now: It stops all services and upgrade the software. Cancel: Go back to the home screen. The upgrade may require a long time, the power should be on while upgrading. You have to http://docs.sotm-audio.com/... - Page 13 The progress bar of the upgrading would be shown when the upgrade starts. If an upgrade is available, the yellow icon shows up at right of “System Setup”. If there is a mandatory upgrade, Eunhasu shows a pop-up window to notify. SOtM docs - http://docs.sotm-audio.com/...
- Page 14 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start Reboot and power off Reboot and power off system. Reboot will take 2~3 mins. It depends on device settings like connection storage or other accessories. http://docs.sotm-audio.com/ Printed on 2020/08/18 19:36...
- Page 15 'power off' will not work immediately. It takes a few seconds. If you unplug the power cord, your storage device might be damaged. Please use the 'power off' function when you need to power off the device. SOtM docs - http://docs.sotm-audio.com/...
-
Page 16: Precautionary Statement
Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start Precautionary statement Eunhasu-enabled devices (e.g. sMS-200 or sMS-1000SQ) and control devices such as PC or smart device must be connected to the same local network. Check the USB connection before using the unit. When using an external storage device, we recommend using an external hard drive which is powered separately and up to 4TB capacity. -
Page 17: Additional Information
Engineered Electronics Stereo Playback Interface 0x20b1, 0x300f Eastern El. MiniMax Tube DAC Supreme 0x20b1, 0x3021 Aune X1S 32BIT/384 DSD DAC 0x20b1, 0x3023 Unison Research Unico CD Due 0x20b1, 0x302d Holo Springs Level 3 R2R DAC 0x20b1, 0x3036 Soekris dac1101 0x20b1, 0x3073 SOtM docs - http://docs.sotm-audio.com/... - Page 18 Last update: 2020/01/07 15:51 en:eunhasu:start http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start Model USB ID Singxer F-1 converter board 0x20b1, 0x3086 CH Precision C1 DAC 0x20b1, 0x307b OPPO HA-2 0x22d9, 0x0426 HDTA Serenade DSD 0x22e1, 0xca01 PS Audio NuWave DAC 0x2616, 0x0106 Audiolab M-DAC+ 0x2622, 0x0041...
- Page 19 2020/08/18 19:36 19/20 Starting Eunhasu Check the USB ID of the DAC that is connected to the Eunhasu device at DAC Information page. SOtM docs - http://docs.sotm-audio.com/...
- Page 20 If there is no matching USB ID in Supported Native DSD DAC list, please email us the request with the DAC information page. After checking the DAC information, we will make the Native DSD playback available on Eunhasu. From: http://docs.sotm-audio.com/ - SOtM docs Permanent link: http://docs.sotm-audio.com/doku.php?id=en:eunhasu:start Last update: 2020/01/07 15:51 http://docs.sotm-audio.com/...
