Operators Manual
24V MAX* Li-Ion Cordless Sweeper
EN p. 2
CLBL2406
** Maximum initial battery workload voltage (measured without a workload) is 24 volts.
Nominal voltage is 21.6 volts
CLBL2406_V1
Read all safety rules and instructions carefully before operating this tool.
Distributed By Cleva North America 601 Regent Park Court Greenville, SC 29607 (866)-384-8432
