DOUBLE UP 2 MAN LADDER STAND
CAUTION-Never have more
than one person on the
ladder at a time. Maximum
weight capacity on ladder is
300 pounds.
Maximum Weight Capacity (User and
Equipment)- 500 pounds (226 kg)
Every year people are injured from hunting related falls. Most of these injuries could have been prevented by
following the instructions and warnings provided with the treestand and safety harness. Tree stands are used
at height and falls can result in serious injury or death. Your own safety, and the safety of any user of this
product, should be your first priority. In order to reduce your risk of injury, you MUST read and thoroughly
understand all of the safety warnings, usage instructions and other information contained within the written
and safety video instructions and warnings provided with this product, and any other hunting equipment
used. Retain the instructional and warning materials and review them periodically (at least once a year and
always with any new user). Failure to follow all instructions and warnings may lead to serious injury or
death. DO NOT USE THIS PRODUCT UNTIL AND UNLESS YOU HAVE READ AND THOROUGHLY
UNDERSTAND ALL INSTRUCTIONS, SAFETY WARNINGS AND OTHER MATERIALS. If you have any
questions, do not use the product until you have contacted the manufacturer at 949-262-3416 or email
customerservice@innopower.biz.
Monday through Friday, 8:00 am to 5:00 pm ET. If you are unable to speak with a
representative, please leave a voicemail with your contact information and your
For Customer Service, please call 949-262-3416 or
Instruction Manual
ITEM:163790
Business Hours:
call will be returned within one (1) business day.
E-mail: customerservice@innopower.biz
(Made In China)
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Game Winner DOUBLE UP
Summary of Contents for Game Winner DOUBLE UP
- Page 1 Instruction Manual DOUBLE UP 2 MAN LADDER STAND ITEM:163790 CAUTION-Never have more than one person on the ladder at a time. Maximum weight capacity on ladder is 300 pounds. Maximum Weight Capacity (User and Equipment)- 500 pounds (226 kg) Every year people are injured from hunting related falls. Most of these injuries could have been prevented by following the instructions and warnings provided with the treestand and safety harness.
-
Page 2: Table Of Contents
Table of Contents Page Warnings ……………………………………………………………………… 3-7 Tools Required ........…………………………………………… 7 Parts List ………………………………………………………………………. 8-12 Hardware ………………………………………………………………… 13-14 Product Diagram ……………………………………………………………… 15 Assembly Instructions ……………………………………………………….. 16-23 Installation Instructions ……………………………………………………… 24-30 Usage …..…………………………………………………………………….. 31-32 Removal Instructions …………………………………………………………… 33 Care and Maintenance ………………………………………………………. 34 Warranty Information …………………………………………………………... -
Page 3: Warnings
Game Winner product(s) without direct adult supervision. WARNING! Prior to attempting to use this or any Game Winner product(s), you must take a moment and become familiar with its assembly, setup, installation and removal. You must practice setting-up using and removing the product(s) at ground level prior to attempting to use it at heights above ground-level. - Page 4 Warnings WARNING! When hunting from a treestand falls can occur any time after leaving the ground causing injury or death. Always wear your full-body fall arrest system (FAS) comprising a full-body harness, tether, tree belt and Suspension Relief Device at all times after leaving the ground. When using a ladder stand, you must connect to the tree as soon as possible and prior to stepping on the platform of the treestand.
- Page 5 Failure to follow these instructions may result in serious injury or death! WARNING! DO NOT use this or any other Game Winner product(s) if you have a history of heart problems, back problems, impaired vision, joints that lock-up, spinal fusions, equilibrium problems, high blood pressure, are not well-rested and/or any other physical impairment that may limit your ability to use and/or operate this product(s) in the safe manner outlined in this instruction manual.
- Page 6 Warnings SPECIAL CONSIDERATIONS FOR LADDER TREESTAND USAGE WARNING! You must use at least three (3) adults to install and/or take down this ladder treestand. Failure to follow these instructions may result in serious injury or death! WARNING! You must install and attach the crisscross straps and the described stabilization devices as described in this manual prior to attempting to climb this treestand.
-
Page 7: Tools Required
Warnings FULL-BODY FALL ARREST HARNESS SYSTEM (FAS) Two (2) full-body fall arrest harnesses have been included with this product for your use. These full-body fall arrest harnesses have been designed to keep you from experiencing a fall. Remember, the most important part of your hunt is returning home to your family safe and sound. READ THE FULL-BODY FALL ARREST HARNESS MANUAL CAREFULLY AND FOLLOW ALL THE INSTRUCTIONS! YOUR NEW FULL-BODY FALL ARREST HARNESS IS DESIGNED FOR A MAXIMUM CAPACITY OF 300 POUNDS (136kg). -
Page 8: Parts List
Parts List four Seating holes Platform side Standing Platform hole side Arm Rest Seating & Standing Platform Support Back Rest Frame Back Rest Cushion... - Page 9 Parts List Seat Cushion Tree Brace Ladder Brace Seating & Standing Platform Connect Bar Shooting Rail Support Bar Shooting Rail Adjustable Tree Brace...
- Page 10 Parts List 14 Adjustable Tree Brace Mount 15 #4 Ladder Section 16 #3 Ladder Section 17 #2 Ladder Section 18 #1 Ladder Section 19 U-Bracket 20 Accessory Hook...
- Page 11 Parts List Mesh Shelf 22 Shelf Support Tube 23 Stabilizer Strap Ratchet Strap w/1 Hook Cam Buckle Strap...
- Page 12 Parts List Yellow Tension Strap Full-Body Fall Arrest Harness with Instruction Manual...
-
Page 13: Hardware
Hardware Step M8X60 (with 2 steel washers and 1 locknut) Step M8X85 (with 2 steel washers and 1 locknut) Step M8X60 (with 2 steel washers and 1 locknut) Step M8X55 (with 2 steel washers an d 1 locknut) Step M6X35 (with 2 steel washers and 1 locknut) Step... - Page 14 Hardware Step M8X25 Handwheel Bolt with Steel Bushing Step M6X30 (with 2 steel washers and 1 locknut) Step M6X40 (with 2 steel washers and 1 locknut) Step M6X55 (with 2 steel washers and 1 locknut) Step M6X40 (with 2 steel washers and 1 locknut) Step M6X60(with 3...
-
Page 15: Product Diagram
Product Diagram #4 Ladder Section Product Identification Mark for Customer Service #3 Ladder Section #2 Ladder Section #1 Ladder Section... -
Page 16: Assembly Instructions
Assembly Instructions Step 1: Locate the Seating Platform (#1). Install the Seating Platform (#1) onto the Seating & Standing Platform Supports (#4) using four (4) M8x60 Bolts, eight (8) Steel Washers and four (4) Locknuts as shown in Figure 1. Figure 1 Install Seating Platform Step 2:... - Page 17 Assembly Instructions Step 3: Insert the Mesh Shelf (#21) to the two tubes as shown in Figure 3. Figure 3 Insert the Mesh Shelf to the two tubes Step 4: Locate the Tree Brace (#8). Install the Tree Brace (#8) onto the Seating &...
- Page 18 Assembly Instructions Step 5: Locate two Seating & Standing Platform Connect Bars (#10) and two Accessory Hooks (#20). A: Install the Seating & Standing Platform Connect Bars (#10) onto the Seating & Standing Platform (#1,#2) using six (6) M8x55 Bolts, tweleve (12) Steel Washers and six (6) Locknuts as shown in Figure 5.
- Page 19 Assembly Instructions Step 7: Locate Back Rest Frame (#5). Install the Back Rest Frame (#5) onto the Arm Rest (#3) using four (4) M6x50 Bolts, eight (8) Steel Washers and four (4) Locknuts as shown in Figure 7. Figure 7 Install Back Rest Frame Step 8: Locate two Shooting Rail...
- Page 20 Assembly Instructions Step 9: Locate Shooting Rail (#12). Install the Shooting Rail (#12) onto the Shooting Rail Support Bars (#11) using two (2) M6x30 Bolts, four (4) Steel Washers and two (2) Locknuts as shown in Figure 9. Figure 9 Install Shooting Rail Step10: Locate #4 Ladder Section (#15)
- Page 21 Assembly Instructions Step 11: Locate two Ladder Braces (#9). Install two Ladder Braces (#9) onto the Seating & Standing Platform Supports (#4) and #4 Ladder Section (#15) using four (4) M6x55 Bolts, eight (8) Steel Washers and four(4) Locknuts as shown in Figure 11. Figure 11 Install Ladder Brace Step 12:...
- Page 22 Assembly Instructions Step 13: Locate six U-Brackets (#19). Secure 3 Ladder Sections with the U-Brackets (#19) using four (4) Right Side M6x40 Bolts, eight (8) Steel Washers and four (4) Locknuts per each Ladder Section as shown in Figure 13. Left Side WARNING: U-Brackets are required and must be...
- Page 23 Assembly Instructions Step 15: Locate Adjustable Tree Brace (#13). Slip the Adjustable Tree Brace (#13) into the Adjustable Tree Brace Mount (#14) and secure them using one (1) M6x45 Bolts, two (2) Nylon Washers and one (1) Wing Nut as shown in Figure 15. Figure 15 Install Adjustable Tree Brace Step 16:...
-
Page 24: Installation Instructions
Installation Instructions SELECTING A SAFE TREE: TREESTAND MINIMUM AND MAXIMUM TREE SIZE: 9 – 24” DIAMETER! Never use treestand on a dead, leaning, diseased, loose barked tree, tree with excessive vines or on utility pole or any other man made structure. WARNING! Never use on trees that contain nails, screws, or other sharp objects that may cut, sever, or puncture strap webbing or cables! - Page 25 WARNING! Prior to attempting to use this, or any other Game Winner product(s), you must take a moment and become familiar with its setup and installation at ground-level. You must practice installing, setting-up using and removing product(s) and full-body safety harness at ground-level prior to attempting to use it at heights above ground-level.
- Page 29 Installation Instructions Figure 21 Connect Yelllow Tension Strap STEP 8: Wrap yellow tension strap (#26) around both stabilizer straps and pull tight drawing stabilizer straps together. Wrap tension strap around drawn stabilizer straps 3 to 4 times and tie off tension strap so it will not loosen (refer to Figure 21). WARNING! Prior to attempting to climb a ladder stand for the first time, make certain the feet of the bottom rung ladder section are firmly planted on solid, level ground.
- Page 30 Ratchet Straps Installed Figure 24 Threading Ratchet Strap WARNING! DO NOT use this, or any other Game Winner product(s) to climb utility poles, telephone poles, structural columns or any other man-make structures. Never use this or any other Game Winner product(s) around power generation (e.g., transformers, generators, substations, etc) and/or power transmission equipment.
-
Page 31: Usage
Usage Before each use, inspect treestand and all safety devices for damage including but not limited to corrosion, cracks, deformity, bends, rot, wear, cuts or fraying and other damage to tree straps, crimps, hardware, platform , upright, seat, etc. Do not use if damage, wear, deterioration, vandalism, etc. - Page 32 Usage STEP INSTRUCTION IMAGE At ground level, put on full body Read and understand included Full harness following harness Body Harness Instructions, Warnings manufacturer’s instructions. If you and watch safety video for instructions are not wearing harness, STOP on using your Full Body Harness and do not leave the ground.
-
Page 33: Removal Instructions
WARNING! Never drop ladder stand out of tree as this is may damage treestand. Always use three (3) adults to slowly lower stand to ground. STEP 1: With three (3) adults, reverse installation instructions to remove your Game Winner Ladder. -
Page 34: Care And Maintenance
Game Winner product(s) prior to use for signs of wear, rot, corrosion, cracks, fraying, deterioration and/or any other type of damage. DO NOT use this or any other Game Winner product(s) if they show evidence of wear, rot, corrosion, cracks, fraying, deterioration and/or any other type of damage. Failure to follow these instructions may result serious injury or death! WARNING! DO NOT allow this product to be kept outdoors for more than two weeks (14 days). -
Page 35: Warranty Information
I have read and understand the safety, assembly and operating instructions provided with my Game Winner product. I have read the warranty information and know that I can call Innopower Inc. at (949) 262-3416 with any questions or concerns that I may have about this or any other Game Winner product.
