Invacare Action Vertic User Manual page 30

Invacare® Action Vertic
Going down a step with an assistant
1. Move the wheelchair right up to the kerb and hold the
handrims.
2. The assistant should hold both push handles, place
one foot on the tipper aid (if installed) and tilt the
wheelchair backwards so that the front wheels lift off
the ground.
3. The assistant should then hold the wheelchair in this
position, push it carefully down the step and then tilt it
forwards until the front wheels are back on the ground.
30
Going up a step with an assistant
WARNING!
Risk of serious injuries
Going up steps and kerbs frequently can result
in earlier than expected fatigue break of the
wheelchair backrest. The user might fall out of
the wheelchair.
– Always use a tipper aid when going up steps
or kerbs.
1. Move the wheelchair backwards until the rear wheels
touch the kerb.
2. The assistant should tilt the wheelchair using both push
handles so that the front wheels lift off the ground,
then pull the rear wheels over the kerb until the front
wheels can be placed back on the ground.
Going down a step without an assistant
1648806-B.00
