Original Instruction

Powered Wheelbarrow

Operator's Manual

MODEL NUMBER :

09618

09618A

SERIAL NUMBER :

Both model number and serial number may be found on the main label.

You should record both of them in a safe place for future use.

FOR YOUR SAFETY

READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE

OPERATING MACHINE

09618UK00M102_不带档位板-出货版.indd 1

2020/6/10 15:40:34

Need help?

Do you have a question about the 09618 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOPMAQ 09618

Page 1 Original Instruction Powered Wheelbarrow Operator’s Manual MODEL NUMBER : 09618 09618A SERIAL NUMBER : Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
Page 2 TABLE OF CONTENTS Engine Manufacturer's owner's/operator's manual, packed separately with your unit, for Introduction more information. Specifications Symbols Specifications Safety General Safety Rules Item No. 09618 09618A Specific Safety Rules 196cc, Unpacking The Container Engine 4.1kW/3600/min Contents Supplied Transmission 3F+1R Assembly...
Page 3 SYMBOLS Never start or run the engine inside a closed area. T h e r a t i n g p l a t e o n y o u r m a c h i n e m a y show symbols.
Page 4 Protect eyes, face, and head from objects that SAFETY may be thrown from the unit. Always wear General Safety Rules safety goggles or safety glasses with side shields when operating. Understand Your Machine Wear appropriate hearing protection. Read this manual and labels affixed to the Always keep hands and feet away from all machine to understand its limitations and moving parts during operation.
Page 5 on the unit. Transporting or performing To avoid sparking or arcing, keep grounded maintenance or service on a machine with its conductive objects – such as tools – away switch on invites accidents. from exposed, live electrical parts and connections. These events could ignite fumes I f t h e m a c h i n e s h o u l d s t a r t t o v i b r a t e or vapors.
Page 6 Specific Safety Rules reverse gear. Do not rapidly accelerate, turn sharply or stop. Thoroughly inspect the area to be worked, Pay the utmost attention when working on keep the working area clean and free of debris frozen ground as the machine may tend to to prevent tripping.
Page 7 UNPACKING THE CONTAINER Use the screwdriver and hammer to open all the side locks. Remove all the plywood plates, and remove all the loose parts on the bottom pallets. POWERED WHEELBARROW 09618UK00M102_不带档位板-出货版.indd 7 2020/6/10 15:40:36...
Page 8 CONTENTS SUPPLIED The mini powered wheelbarrow comes partially assembled and is shipped in carefully packed package. After all the parts have been removed from the package, you should have: 1. Dump Box 2. Welded Flange Plates 3. Main Frame × 24 4.
Page 9 ASSEMBLY This mini powered wheelbarrow was partially assembled at the factory. To assemble your machine follow the below instructions. Wheels Assembly Put a pair of wheels onto the rear wheel axles and make sure the tire valve is facing outwards. Slide the four bolts of each wheel axle through the holes in wheels and secure them with M12 nuts and washers.
Page 10 Dump Box Assembly Engine Oil 1. Attach connecting plate of the box lifting O I L H A S B E E N D R A I N E D F O R handle to the dump box with three M8x25 SHIPPING.
Page 11 KNOW YOUR MACHINE Features and Controls Engine On/Off Switch Throttle Control Right Steering Lever Clutch Control Lever Left Steering Lever Dump Box Gear Selection Lever Dump Box Release Lever Dump Box Lifting Handle Gearbox Wheel Recoil Starter Handle Throttle Control Choke Control Fuel Shut-Off Valve POWERED WHEELBARROW...
Page 12 Engine switch After tipping the load, swing handle A back to The engine switch enables and disables the reset limiter B into hook C, which will lock the ignition system. dump box. The engine switch must be in the ON position for the engine to run.
Page 13 Operation IMPORTANT: DO NOT OVERFILL! This equipment and/or its engine Add Oil To Engine may include evaporative emissions c o n t r o l s y s t e m c o m p o n e n t s , The engine is shipped without oil.
Page 14 Move the throttle Remember to be careful when working in lever slightly to the adverse weather conditions (ice, heavy rain FAST speed. FAST SLOW and snow) oron types of ground that could make the powered wheelbarrow unstable. When the clutch control lever is released, the machine will stop and brake automatically.
Page 15 the adjusters too much because this can MAINTENANCE create another problem: the loss of traction. Remember to tighten the locknut when you Maintaining your mini powered wheelbarrow have finished. will ensure long life to the machine and its Lubrication components. The gearbox is pre-lubricated and sealed at Preventive Maintenance the factory.
Page 16 STORAGE If the mini powered wheelbarrow will not be used for a period longer than 30 days, follow the steps below to prepare your unit for storage. Drain the fuel tank completely. Stored fuel containing ethanol or MTBE can start to go stale in 30 days.
Page 17 TROUBLE SHOOTING Problem Cause Remedy 1. Attach spark plug wire securely to spark plug. 1. Spark plug wire disconnected. 2. Fill with clean, fresh gasoline. 2. Out of fuel or stale fuel. 3. Throttle must be positioned at choke 3. Choke not in open position. Engine fails to for a cold start.
Page 18 PARTS SCHEDULE POWERED WHEELBARROW 09618UK00M102_不带档位板-出货版.indd 18 2020/6/10 15:41:01...
Page 19 Gearbox Parts List Description Q'ty Description Q'ty Washer 6 Gearshift Fork Guide Pin Screw M8x25 Spring Nut M8 Steel Ball 6 Circlip 15 Gearshift Fork Nut M6 Circlip 12 Pin 5x30 Rivet Assembly Gearshift Lever Brake Disk Pin 3x30 Joint Bush Bolt M8x12 Wearing Pad Orientation Nut...
Page 20 Description Q'ty Description Q'ty Intermediate Joint Bush Expansion Brake Lock Bolt Screw M8x130 Intermediate Joint Bush Composite Bushing Clutch Fork Shaft (L) Circlip 26 Bolt M6x20 Joint Bush Swing Lever Spring Gasket Gear Ⅲ-4 Circlip 25 Washer 8 Gear Ⅲ-3 Output Shaft Bushing Large Belt Pulley Bearing 6303...
Page 21 Description Q'ty Description Q'ty Handle Frame Assembly -1 154 Bush 2 Flange Nut M8 155 Flat Key A8x60 Washer D8 156 Rear Wheel Axle Washer D8 157 Bolt M8x16 Bolt M8X25 158 Spring Washer D8 120 Dump Box 159 Rear Belt Guard 122 U-Bolt 160 Front Belt Guard 123 Flange Nut M12...
Page 22 Description Q'ty 193 Chain Pad (Right) 194 Chain Pad (Left) 195 Screw M10x50 196 Sprocket 197 Lever Knod 199 Support Bush 200 Fixing Bracket 201 Chassis POWERED WHEELBARROW 09618UK00M102_不带档位板-出货版.indd 22 2020/6/10 15:41:04...
Page 23 POWERED WHEELBARROW 09618UK00M102_不带档位板-出货版.indd 23 2020/6/10 15:41:04...
Page 24 09618UK00M102_不带档位板-出货版.indd 24 2020/6/10 15:41:04...
