Summary of Contents for AMCI SMD23 Series
- Page 1 ADV ANC ED MIC RO CON T RO L S INC. Manual #: 940-0S050 SMD23 Integrated Stepper Drive & Motor...
- Page 2 [18] months. Within this warranty period, AMCI shall, at its option, repair or replace, free of charge, any equipment covered by this warranty which is returned, shipping charges prepaid, within one year from date of invoice, and which upon examination proves to be defective in material or workmanship and not caused by accident, misuse, neglect, alteration, improper installation or improper testing.
- Page 3 AMCI quality and reliability Single power supply The SMD23’s use step and direction control signals generated from an external source such as AMCI’s 3202 or 3601 stepper control modules. A logical diagram of the inputs is shown below. CW Rotation CCW Rotation STEP The SMD23’s are powered by an external DC supply with an operating range of 24 to 75Vdc.
- Page 4 Idle current reduction time 1 sec Idle current selection 0% to 70% of the maximum operating current Default Value – 20% 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 4 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com...
- Page 5 5V TTL logic Input Current 15mA max Input Connector AMCI Part # MS-8P, provided (Phoenix part # MC 1.5/8-ST3.81) 8 screw terminal type – 16 AWG max. Programming Communications Interface – RS232 Programming Interface – AMCI SPI Interface software, Windows 2000/XP supported Interface Cable –...
- Page 6 ADV ANC ED SMD-23 Integrated Stepper Drive & Motor MIC RO CON T RO L S INC. SMD23 Torque Curves 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 6 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com...
-
Page 7: Installation
– 0.013 0.228" ±0.004" (5.79 ±0.10) REAR VIEW Indexer Input Connector (8 Pins) Mates with AMCI #: MS-8P Phoenix Contact #: MC1,5/8-ST-3,81 Pin 1 +Vdc Pin 5 – Step Pin 2 Vdc Common Pin 6 + Step Pin 3 – Disable Pin 7 –... - Page 8 – 0.43" Nominal 1 2 3 4 5 6 7 8 (10.9 Nominal) Programmer Wiring – CSMD-5 cable SMD Connector – AMCI part # MS-8P Serial Port Connector – DB-9 To SMD To PC Serial Port 1. DC Supply 24-75Vdc 1.
- Page 9 Disable Input is identical to the Step and Direction Inputs. The SMD does not accept directional pulses while the Disable Input is active. 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 9 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com...
- Page 10 Power supply – 24 to 75VDC, 4Amps; • Programming cable - AMCI CSMD-5, 5 ft serial cable(optional). It connects the drive to a PC. The connections are described in this document. The drive circuit provides optical isolation from the PC;...
- Page 11 By pressing the Defaults button, the default settings will appear: • RESOLUTION: 2000 steps/revolution • IDLE: 20% (Motor Current when motor is idle) • CURRENT: 80% (Operating Current) 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 11 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com...
-
Page 12: Error Messages
Check if power is applied to the motor; • Check the wire connection; • Check if the correct COM port is selected 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 12 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com... - Page 13 ADV ANC ED SMD-23 Integrated Stepper Drive & Motor MIC RO CON T RO L S INC. NOTES: 20 Gear Drive, Plymouth Industrial Park, Terryville, CT 06786 page: 13 Tel: (860) 585-1254 Fax: (860) 584-1973 Web: www.amci.com...
- Page 14 ADV ANC ED MIC RO CONTROLS INC. ADV ANC ED MIC RO CONTROLS INC. ADV ANC ED MIC RO CONTROLS INC. ADV ANC ED MIC RO CONTROLS INC. 20 GEAR DRIVE, TERRYVILLE, CT 06786 T: (860) 585-1254 F: (860) 584-1973 www.amci.com...
