- Page 1 Operating Manual Extraction unit Version 1.0.1 GU 5 Item no. 3107114 GU 5 - H Item no. 3107124 GU 5 GU 5-H...
-
Page 2: Table Of Contents
Table of contents Safety Safety instructions (warning notes)........................ 4 1.1.1 Classification of hazards ........................4 1.1.2 Other pictograms..........................5 Intended use ..............................5 Reasonably foreseeable misuse........................7 1.3.1 Avoiding misuse ..........................7 1.3.2 Workplace limits ..........................7 1.3.3 Residual risk............................. 7 Electronics .............................. - Page 3 If you have any further questions after reading these operating instructions and you are not able to solve your problem with a help of these operating instructions, please contact your specialised dealer or directly the company OPTIMUM. Optimum Maschinen Germany GmbH Dr.- Robert - Pfleger - Str. 26 D-96103 Hallstadt Fax (+49)0951 / 96555 - 888 email: info@optimum-maschinen.de...
-
Page 4: Safety
Always keep this documentation close to the extraction unit. INFORMATION If you are unable to rectify an issue using these operating instructions, please contact us for advice: Optimum Maschinen Germany GmbH Dr.-Robert-Pfleger-Str. 26 D-96103 Hallstadt Email: info@optimum-maschinen.de Safety instructions (warning notes) 1.1.1... -
Page 5: Other Pictograms
Symbol Alarm expression Definition / consequence Situation that could cause damage to the machine and product, as well as other types of damage. ATTENTION! No risk of injury to persons. Practical tips and other important or useful information and notes. No dangerous or harmful consequences for people or objects. - Page 6 We expressly point out that the guarantee will expire, if any constructive, technical or procedu- ral changes are not performed by the company Optimum Maschinen Germany GmbH. It is also part of the intended use that you ...
-
Page 7: Reasonably Foreseeable Misuse
Reasonably foreseeable misuse The extraction unit has been designed as add-on device, fixing of machines on the surface is not permissible. Any use other than that specified under "Intended use" or any use beyond that described will be deemed non-intended use and is not permissible. Any other use must be discussed with the manufacturer. -
Page 8: Inspection Deadlines
Comply with the required inspection intervals in accordance with the factory safety directive, operating equipment inspection. The operator of the extraction unit must ensure that the electrical systems and operating equip- ment are inspected with regards to their proper condition, namely, ... -
Page 9: Technical Specification
Technical specification The following information represents the dimensions and indications of weight and the manu- facturer‘s approved machine data. GU5 | GU5-H Electrical connection 400V ~ 50Hz (~60Hz) CEE 16 A connector, 5-pin supply voltage required. max. input power of the machine con- 4 kW nected at the three-phase connector Load current of the machine con-... -
Page 10: Dimensions Gu5 | Gu5-H
Though there is a dependency between the degree of the noise emission and the degree of the noise disturbance it is not possible to use it reliably to determine if further precaution measures are required or not. The following factors influence the actual degree of the noise exposure of the operator: ... -
Page 11: Delivery, Interdepartmental Transport, Unpacking
Delivery, interdepartmental transport, unpacking INFORMATION The extraction unit is mounted fully assembled. It is delivered in a transport box. The GU5-H machine base can be filled with concrete ( DIY store Ready-dry concrete to mix ) in the lower area by the operator in order to achieve sufficient rigidity. Delivery Check the status of the extraction unit immediately upon receipt and claim possible damages at the last carrier also if the packing is not being damaged. -
Page 12: Operation
Operation Extraction unit function description In the machine substructure is situated a fan than generates an underpressure. The negative pressure produced draws in the ambient air. The air volume from the extraction connections is guided via a cyclone separator that extracts the fine dust particles from the extracted air and deposits them in a collection tank. -
Page 13: Fire And Explosion Prevention
The area in which maintenance work (normal and exceptional) are carried out must always be kept clean and dry. Repair work may only be carried out after the device has been switched off and the power supply has been interrupted. Repair work must only be carried out by specialist personnel. -
Page 14: Maintenance
Maintenance Inspection and maintenance The type and level of wear depends to a large extent on the individual usage and operating conditions. Any indicated intervals therefore are only valid for the corresponding approved conditions. Maintenance work must be carried out in a room with filtered forced ventilation. Interval Where? What? -
Page 15: Appendix 7.1 Copyright
Any defective products or components of such products will either be repaired or replaced by components which are free from defects. Title to replaced products or components is transfer- red to OPTIMUM Maschinen Germany GmbH. The automatically generated original proof of purchase which shows the date of purchase, the type of machine and the serial number, if applicable, is the precondition in order to assert liability or warranty claims. -
Page 16: Advice For Disposal / Options Of Reuse
Advice for disposal / Options of reuse: Please dispose of your equipment in an environmentally friendly manner, by not placing waste in the environment but in a professional manner. Please do not simply throw away the packaging and later the disused machine, but dispose of both in accordance with the guidelines laid down by your city council/local authority or by an authorised disposal company. -
Page 17: Ersatzteile - Spare Parts
Ersatzteile - Spare parts Ersatzteilbestellung - Ordering spare parts Bitte geben Sie folgendes an - Please indicate the following : Seriennummer - Serial No. Maschinenbezeichnung - Machines name Herstellungsdatum - Date of manufacture Artikelnummer - Article no. Die Artikelnummer befindet sich in der Ersatzteilliste. - Page 18 Isolierung Insulation 0310711403 Isolierung Insulation 0310711404 Zyklonabsaugung Cyclone suction 0310711405 Dichtung Seal 0310711406 Behälter Vessel 0310711407 Knopf Knob 0310711408 Verschlussschraube Locking screw 0310711409 Filter Filter 0310711410 Abdeckung Cover 0310711411 Abdeckung Cover 0310711412 Verteiler Distributor 0310711413 Stopfen Plug 0310711414 Stromverteiler Power distributor 0310711415 Anschluss Connection...
-
Page 19: Schaltplan Stromverteiler - Wiring Diagram Power Distribution
Schaltplan Stromverteiler - Wiring diagram power distribution Anschlüsse - Connections A - Anschluss Schleifmaschine - Grinding machine connection - CEE 400V 16A B - 230V Schutzkontaktsteckdose - 230 V socket with earthing-contact C - Versorgungsanschluss Absaugung - Supply connection for extraction unit - CEE 400V 16A ... - Page 20 EC Declaration of Conformity according to Machinery directive 2006/42/EC, Annex II A The manufacturer / distributor Optimum Maschinen Germany GmbH Dr.-Robert-Pfleger-Str. 26 D - 96103 Hallstadt, Germany hereby declares that the following product Product designation: Extraction unit Type designation: GU 5 | GU 5-H fulfills all the relevant provisions of the directive specified above and the additionally applied directives (in the following) - including the changes which applied at the time of the declaration.
- Page 21 Index Copyright ...............15 Electrical connection ..........9 Inspection deadlines ..........8 Liability claims for defects ........15 Malfunctions ............14 Safety instructions ............4 Technical specification Electrical connection ..........9 Emissions ............9 Transport ...............11 Warranty ...............15 GU 5 | GU 5-H Version 1.0.1 - 2020-04-09 Translation of original instruction...
- Page 22 GU 5 | GU 5-H Translation of original instruction Version 1.0.1 - 2020-04-09...
