Toro TR-34D Addendum

TR-34D Trench Roller
Model No. 68039—Serial No. 314000001 and Up
This product contains a chemical or chemicals known to the State of California to
The engine exhaust from this product contains chemicals known to the State of California
Important: This addendum describes how to connect the battery cable of your machine.
1
Opening the Front and Rear
Hoods of the Machine
No Parts Required
Opening the Front Hood
1. At the front hood, pivot the latch handle for the hood
to the vertical position (Figure 1).
© 2014—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
to cause cancer, birth defects, or other reproductive harm.
Register at www.Toro.com.
WARNING
CALIFORNIA
5
1. Front hood
2. Latch handle (stowed)
3. Latch handle (vertical)
4. Front hood opening
2. Rotate the latch handle clockwise (Figure 1).
3. Grasp the latch handle tightly and pull up firmly to
unseat the hood from the hood clips (Figure 1).
4. Rotate the hood up (Figure 1).
Form No. 3388-998 Rev A
7
6
Figure 1
5. Rear hood
6. Hood clip
7. Rear hood opening
Original Instructions (EN) All Rights Reserved *3388-998* A
Printed in the US
Addendum
2
3
4
1
G019041
