- Page 1 ALIEN TECHNOLOGY ® ALR-M702 User Guide August 2019 ALR-M702-FCC...
- Page 2 Alien Technology, the Alien logo, Nanoblock, FSA, Gen2Ready, Squiggle, the Squiggle logo, Nanoscanner and other graphics, logos, and service names used in this document are trademarks of Alien Technology, LLC and/or its affiliated companies in the U.S. and other countries. All other trademarks are the property of their respective owners. U.S. Government approval required when exporting the product described in this documentation.
- Page 3 Industry Canada Compliance ISED ID: 4370A-ALRM702 Avertissement: Tout changement ou toute modification non expressément approuvé par les reponsables de la conformité (Alien Technology, LLCC, 845 Embedded Way, San Jose, CA 95138, Tél: 1.408.782.3900) peut faire perdre a l’utilisatuer son droit d’utiliser l’equipement...
-
Page 4: Table Of Contents
ABLE OF ONTENTS Alien Technology® User Guide ALR-M702-FCC RFID Module Table of Contents INTRODUCTION ........................ 1 Audience.................................... 1 Type Conventions ................................1 Overview.................................... 1 System Requirements ................................ 1 Device Specification ................................1 VERIFYING THE M702 ...................... 2 Preparing to test the Module .............................. 2 Inventory Test .................................. -
Page 5: Introduction
This document focuses on controlling the ALR-M702-FCC RFID Module. The Alien ALR-M Demo Software is used to control the ALR-M modules The module supports an RS232 interface with a baud rate of 115,200, 8 bit data, 1 start and 1 stop bit 1.4 System Requirements... -
Page 6: Verifying The M702
M702 HAPTER ERIFYING THE 2 Verifying the M702 Alien Technology provides a convenient development board, power supply and associated GUI to power and communicate with the ALR-M702-FCC. 2.1 Preparing to test the Module Install the GUI on your PC or laptop ... -
Page 7: Inventory Test
HAPTER ERIFYING THE 2.2 Inventory Test Upon launching the Alien ALR-M Demo Software (double click on ALRMdemoV1.6.7e.exe), the following screen is displayed: The window displays communication Port, Tag List and the Read Statistics information. Select the correct COM port and Open communication. The Engineering tab of the GUI will only appear when a module specific license is present in the GUI folder. -
Page 8: Engineering Test Mode
The Engineering test mode allows the user to switch the module between hopping and fixed frequency operation to support certification testing. To operate in the Engineering mode the User must have a license provided by Alien tied to the specific module serial number. - Page 9 HAPTER NGINEERING Double click on Engineering. Select a frequency, select FIXED, select Inventory. Click on Save. Click on Start to start transmission ALR-M702 U UIDE DOC. CONTROL #TBD R...
-
Page 10: Inventory - Frequency Hopping
HAPTER NGINEERING Inventory – Frequency Hopping Follow the same steps as in 3.1 but this time select HOP in the Engineering menu. ALR-M702 U UIDE DOC. CONTROL #TBD R... -
Page 11: Cw - Fixed Frequency And Frequency Hopping
HAPTER NGINEERING CW – Fixed Frequency and Frequency Hopping Follow the same steps as in 3.1 this time select CW and transmission frequency preference. Click on Save. Click on Start to start transmission. ALR-M702 U UIDE DOC. CONTROL #TBD R... -
Page 12: Rf Power
“get” to read back the setting. Check the “Save” check box to store the RF Transmit Power setting in nonvolatile memory in order to restore the saved value automatically on the module power-up. ALR-M702 U UIDE DOC. CONTROL #TBD R... -
Page 13: Technical Support
HAPTER NGINEERING 4 Technical Support Alien Technology, LLC 845 Embedded Way San Jose, CA. 95138 Tel: 1.408.782.3900 5 Revision History ECO # Revision Date: Originator: Description of Change: 8/8/19 J. Hattick Initial release ALR-M702 U UIDE DOC. CONTROL #TBD R...
