- Page 1 QUICK MOUNT VISUAL INSTRUCTION MANUAL NIMOFR..C, CMB24..D Actuators CLICK! >2.5” 0.75” ø13/64” ø15/32” CLICK!
- Page 2 QUICK MOUNT VISUAL INSTRUCTION MANUAL NIMOFR...C, CMB24..D Actuators AIRFLOW 90° 90° X X X X X X Wiring Diagrams Notes: 24 VAC Transformer Meets cULus requirements without the need of an electrical Line AC 24 V / DC 24 V Blk (1) Common ground connection –...
