SEQv4+ le mec
This board holds the SEQ's illuminated buttons, which are driven from a shift register matrix. The
PLATE
board stacks on top.
Schematic
A shift register chain of 3 DIN 74HC165 and 2 DOUT 74HC595 chips are used. Two of the DINs scan
the encoders and one scans the button columns. The DOUT parts are connected into a matrix. Note
that both the high and low sides have driver transistors (PNP and NPN, respectively). This means that
the anode side of the matrix will operate with inverted behaviour (pin high = LED off). Actually the low
(cathode) side is also "inverted," as we turn the transistor "on" to sink the current by toggling the 595
pin high.
There are special instructions for connecting the parts which are covered below.
BOM v1.0
Please find the current BOM on http://midiphy.com. The table below is depreciated and
will not be updated.
Type Qty Value
1
wire link
16 47R 5%
100-220R
10
5%
16 1k 5%
8
10k 5%
3
9*10k
5
100n
do not fit
0
24 1N4148
24 BAT54
MIDIbox - http://www.midibox.org/dokuwiki/
Package
Parts
THT
R17
THT
RJ1-8
THT or
SJ1-8,
1206
RJ9
THT
R1-16
1206
R18-25
Resistor networks
SIP10
RN1-3
1206
C1-5
C6
THT
SOT-23
512-BAT54
1/6
Mouser
Reichelt Conrad Other
Resistors
Capacitors
Diodes
BAT 54
SMD
SEQv4+ le mec
ENC-
Notes
see
instructions
see
instructions
near NPN
bussed
network,
not 5 pairs
of resistors
