  • Page 1 Reference 2714 & 2715 Spectrum Analyzer 070-8535-06 This document supports Firmware Version 2.14.97 and above.
  • Page 2 Copyright E Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Tektronix, Inc., P .O. Box 1000, Wilsonville, OR...
  • Page 3 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.
  • Page 4 THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THIS PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR...

  • Page 5: Table Of Contents

    MKR/FREQ Menu ....CATV Menu (2714 Only) ....

  • Page 6: Controls And Menus Reference

    Controls and Menus Reference...
  • Page 7 Frequency/Markers Controls ..Page 4 Fundamental Controls ... . . Page 6 Numeric Keypad ....Page 8 Vertical Scale, Demodulator, and...

  • Page 8: Frequency/Markers Controls

    Frequency/Markers Controls...
  • Page 9 Moves marker to highest on-screen signal. Press once for center measure (counts signal). Press twice for signal track mode. Press again for tracking off. Depending upon mode, FREQ/MKRS knob changes: S Center or start frequency S Marker position S Video line number for triggering Knob also selects letters for titles and labels.

  • Page 10: Fundamental Controls

    Fundamental Controls Selects channel, frequency, span/div, or ref level for immediate entry. Enter value from keypad and end entry with terminator key [W], [X], [Y], or [Z]. Press once for zero Press once for max span mode (time span mode domain);...
  • Page 11 Decrease ( ) or increase ( ) channel or frequency by one division in auto tuning mode or by the designated increment in other modes. ALWAYS ACTIVE. Decrease ( ) or increase ( ) span/div in 1-2-5 sequence. ALWAYS ACTIVE. Decrease ( ) or increase ( ) ref level in 1 dB or 10 dB steps.

  • Page 12: Numeric Keypad

    Numeric Keypad Dot Key: S Decimal in numeric entries S Period in text entries...
  • Page 13 Numeric Keys 0-9: S Enter numeric values S Make menu selections Terminator Keys W, X, Y, Z: S Signify end of entry S Select required units Backspace Key (BK SP): S Back up one menu level S Erase last character in data entry...

  • Page 14: Display Controls

    Vertical Scale, Demodulator and Display Controls Initiates screen plot. Toggles vertical scale between LIN and LOG modes. Toggles power on (LED lighted) and off. Varies CRT brightness.
  • Page 15 Press repeatedly to select LOG vertical scales in 10-5-1 dB sequence. Controls volume of AM or FM demodulators. Inner knob controls: S Trigger level in Internal, Line and External modes S Sweep position (manual scan mod) S Picture framing (video monitor mode) Toggles on-screen readouts on and off.

  • Page 16: Display Storage Controls

    Display Storage Controls Activates MAX HOLD mode. In MAX HOLD mode the A & B registers (if active) retain the largest signals observed. Lights when Lights when MAX HOLD waterfall mode is active. is active. Lights when SAVE ENABLE is armed. To enter waterfall mode: S First clear the A, B, and C registers S Press [SAVE ENABLE][D]...
  • Page 17 Press to arm SAVE ENABLE, then press register A, B, or C to save or clear (unsave). Toggles the indicated register (A, B, C, D) on or off, and saves (or clears) the display in the selected register when SAVE ENABLE is armed. Individual waveforms cannot be saved in the D register.

  • Page 18: Resolution Bw And Sweep Controls

    Resolution BW and Sweep Controls Decreases ( ) or increases ( ) the RES BW filter bandwidth. Selects AUTO RES BW mode (LED lighted). Activates the user-selectable video filter (LED lighted).
  • Page 19 Decreases ( ) or increases ( ) the sweep rate in 1-2-5 sequence. Press once to select single sweep mode. Press again to arm sweep. Sweep begins after next trigger signal. Selects AUTO sweep rate mode (LED lighted). RF input signal connector. OBSERVE MAXIMUM INPUT RATINGS.

  • Page 20: Trigger Menu

    TRIGGER Menu 0 FREE RUN 1 INTERNAL 2 EXTERNAL 3 LINE 4 TV LINE 5 TV FIELD SWEEP Menu 6 SWEEP RATE 7 MANUAL SCAN 8 SYNC POLARITY 9 SETUP TABLE Configures HORIZONTAL TV LINE Triggering 0 Continuous 1 Knob selectable 2 Keypad entered line 3 Keypad entry 4 TV line standard...

  • Page 21: Util Menu

    UTIL Menu 1 STORED SETTINGS 0 Last power-down 1 Factory default power-up 2 User defined power-up 3-39 Stored setting/display registers 2 KEYPAD ENTERED SETTINGS 3 NORMALIZATIONS 4 SYSTEM CONFIGURATION 0, 1, 2 Comm port, screen plot, and printer config (GPIB & RS-232 options only) 3 Instrument config 4 Real-time clock setup 5 Stored settings protect...

  • Page 22: Mkr/Freq Menu

    MKR/FREQ Menu 0 THRESHOLD 1 PROGRMD TUNING INC 0 Center freq 1 Marker freq 2 Keypad entered inc 3 Keypad entry 4 Return to auto 2 KNOB FUNCTION 3 MARKER TO REFERENCE LEVEL 4 MOVE MARKER TO NEXT PEAK 5 TRANSPOSE MARKERS 6 MARKER START/STOP 7 FREQUENCY START/STOP 8 TUNING INCREMENT...

  • Page 23: Catv Menu (2714 Only)

    CATV Menu (2714 Only) (Page 1) 0 RECENTER CHANNEL xx 1 CARRIER LEVELS 0 Run carrier levels 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up carrier levels...
  • Page 24 CATV Menu (2714 Only) (Continued) (Page 1 Continued) 3 MODULATION DEPTH 0 Run modulation depth 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up adjustment mode 0 View modulation mode...
  • Page 25 CATV Menu (2714 Only) (Continued) (Page 1 Continued) 5 CARRIER TO NOISE 0 Run carrier/noise 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up carrier/noise 0 Interactive...
  • Page 26 CATV Menu (2714 Only) (Continued) (Page 1 Continued) 8 CATV MEASUREMENT SETUP 0 Exit CATV measurement mode 1 Channel table 0 STD 1 HRC 2 IRC 3-9 User defined tables 2 Skip channel 3 All channels 4 Site 5 Operator...
  • Page 27 CATV Menu (2714 Only) (Continued) (Page 2) 0 RECENTER CHANNEL xx 1 VIEW MODULATION (FIELD) 2 VIEW MODULATION (LINE) 3 VIEW PICTURE 4 LISTEN 5 CTB 0 Run CTB 1 Store current results 2 Display results 3 Print current results (RS-232 only)
  • Page 28 CATV Menu (2714 Only) (Continued) (Page 2 Continued) 6 CSO 0 Run CSO 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up CSO 0 Interactive 1 Auto...
  • Page 29 CATV Menu (2714 Only) (Continued) (Page 2 Continued) 8 IN-CHANNEL RESPONSE 0 Run in-chan resp 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up In-chan resp 0 Interactive 1 Auto (pause for signal on) 2–7 user-defined test frequencies...
  • Page 30 CATV Menu (2715 Only) (Page 1) 0 RECENTER CHANNEL xx 1 CARRIER LEVEL -- AVG POWER 0 Run levels -power 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up carrier levels 0 Accurate frequency and ampl 1 Accurate amplitude only 2 Fast amplitude only...
  • Page 31 CATV Menu (2715 Only) (Continued) (Page 1 Continued) 3 MODULATION DEPTH 0 Run modulation depth 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up adjustment mode 0 View modulation mode 1 Target line 2 Cycle delay 3 Target line duration...
  • Page 32 CATV Menu (2715 Only) (Continued) (Page 1 Continued) 5 CARR/NOISE -- DESIRED/UNDESIRED 0 Run C/N -- D/U 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up carrier/noise 0 Interactive 1 Auto 2 Auto (Pause for carrier off)

  • Page 33: Catv Menu (2715 Only)

    CATV Menu (2715 Only) (Continued) (Page 1 Continued) 8 CATV MEASUREMENT SETUP 0 Exit CATV measurement mode 1 Channel table 0 STD 1 HRC 2 IRC 3-9 User defined tables 2 Skip channel 3 All channels 4 Site 5 Operator 6 Ref level unit 7 Edit Channel Table 8 Remove all stored results...
  • Page 34 CATV Menu (2715 Only) (Continued) (Page 2) 0 ADJACENT CHANNEL LEAKAGE 0 Run adjacent channel leakage 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Measure side 9 Leave ACL 1 VIEW MODULATION (FIELD) 2 VIEW MODULATION...
  • Page 35 CATV Menu (2715 Only) (Continued) (Page 2 Continued) 6 CSO 0 Run CSO 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up CSO 0 Interactive 1 Auto 2 Auto (pause for carrier off) 3 Single sweep 4 Continuous...
  • Page 36 CATV Menu (2715 Only) (Continued) (Page 2 Continued) 8 IN-CHANNEL RESPONSE 0 Run in-chan resp 1 Store current results 2 Display results 3 Print current results (RS-232 only) 4 Print stored results (RS-232 only) 5 Set up In-chan resp 0 Interactive 1 Auto (pause for signal on) 2–7 user-defined test frequencies 8 Use default test frequencies...

  • Page 37: Appl Menu

    APPL Menu 0 BANDWIDTH MODE 1 CARRIER TO NOISE 2 NOISE NORM’D 3 SIGNALSEARCH MENU 4 OCCUPIED BW 7 FM DEVIATION MODE 8 CATV MEASUREMENT MODE 9 SETUP TABLE 0 db down for BW mode 1 Norm BW for c/n 2 Noise norm’d BW 3 Percent occupied BW DEMOD Menu...

  • Page 38: Dspl Menu

    DSPL Menu 0 DIGITAL/ANALOG 1 ENSEMBLE AVERAGING 1 Initiate averaging 2 Terminate averaging 3, 4, 5, 6 Max, Mean, Min, and Max/Min 7 Number of averages 8 Save results in display (A, B, C) 2 B, C MINUS A 3 B, C MINUS A OFFSET TO (Center or Top) 4 ACQUISITION MODE (Peak or Max/Min) 5 TITLE MODE 6 GRATICULE ILLUMINATION...

  • Page 39: User Def Menu

    USER DEF Menu 0-8 USER DEFINED PROGRAMS 9 USER DEF PROG UTILITIES 0 Acquire key strokes 1 Title edit 2 Wait for end of sweep 3 Display message 4 Pause for “USER DEF” key 5 Continuous execution 6 Store 7 Delete 8 Protect 9 Time delay setup INPUT Menu...

  • Page 40: Control Ranges

    Control Ranges Frequency range: 9 kHz to 1.8 GHz Span/div range: 1 kHz to 100 MHz in a 1-2-5 sequence and 180 MHz/div (max span) plus zero span Ref level range: +68.8 dBmV to –21.2 dBmV RES BW filters: 300 Hz, 1kHz, 3 kHz, 10 kHz, 30 kHz, 100 kHz, 300 kHz, 1MHz, 5 MHz 6 dB width,  7:1 shape factor RF attenuation range: 0 dB to 50 dB in 2 dB steps...
