Physical Installation - ring Range Extender Z-Wave Technical Manual

Physical Installation

Ring Alarm Extender is listening device and is always awake as long as it connected to line power or
running on battery.
Installation On the Power Outlet (Secured with Screw)
1. Unscrew the wall plate screw adjacent to the outlet the Range Extender will be plugged into.
2. Plug in the Range Extender, making sure the Screw Flange is directly over the wall plate's screw hole.
3. Secure the Range Extender in place by replacing the wall plate screw.
Installation On the Power Outlet (Unsecured)
1. Plug in the Range Extender.
Command Class - (Security Level)
Device Reset Locally V1 (5A) - (S2)
Node Information Frame (NIF) - (None)
Security Class (9F) - (None)
Powerlevel V1 (73) - (S2)
Battery V1(80) - (S2)
Association Group Information V1 (59) - (S2)
Firmware Update Meta Data (7A) - (S2)
Version V2 (86) - (S2)
Manufacturer Specific V2 (72) - (S2)
6
Notes
-
The node Information Frame (NIF) advertises the device's Generic Device
Type, Specific Device Type, and Role Type.
Generic Device Type: GENERIC_TYPE_REPEATER_SLAVE Specific Device
Type:
SPECIFIC_TYPE_REPEATER_SLAVE Role Type:
ROLE_TYPE_SLAVE_ALWAYS_ON
WILL NOT request the S2 Access Control Security Class WILL request the S2
Authenticated Security Class
WILL request the S2 Unauthenticated Security Class
A security-enabled Z-Wave Plus controller is required to fully utilize device
features.
-
The Battery Report interval will be 70 minutes by default and is configurable
using a configuration parameter.
-
-
Returned Value: 03 04 21 01 11 1E 00 Z-Wave Library
Type: 03 (Enhanced Slave)
Protocol Version: 04 21
Protocol Sub-Version: 01 11 Application Version:
1E Application Sub-Version: 00
Returned Value: 03 46 04 01 01 01
Manufacturer ID: 03 46
Product Type: 04 01
Product ID: 01 01
Device specific get has serial number, of the following format: Serial Number
Format:
BHRP V YY WW DM XXXXXX
V: Ring hub Version (right now it's 1, we will let you know if/when it chang- es)
YY: Year of manufacture
WW: week number of manufacture XXXXXX: incremented serial number
Example: 3,245th Dome first version extender built in the 36th week of
2017 = BHRP11736DM003245
