Technical Specifications - ring Range Extender Z-Wave Technical Manual

Technical Specifications

Radio protocol
Z-Wave SDK
Encryption
Power Supply
Battery Specs
Battery Life
Working current
Operating temperature
Radio frequency
Z-Wave Range
LED Color
Package Contents
Certifications
Certifications (future)
Dimensions
Button
This product can be operated in any Z-Wave network with other Z-Wave certified devices from other
manufacturers. All mains operated nodes within the network will act as repeaters regardless of vendor
to increase reliability of the network.
This is a SmartStart enabled product which can be added into a Z-Wave network by scanning the
Z-Wave QR Code present on the product with a controller providing SmartStart inclusion. No further
action is required and the SmartStart product will be added automatically within 10 minutes of being
switched on in the network vicinity. This product can also be operated in any Z-Wave network with other
Z-Wave certified devices from other manufacturer.
Z-Wave(500 series)
6.81
S2 (using 64-character hex device-specific ID)
AC 110V 60 hz
3.7V DC 1100mAh
22 Hours
Max: 20 mA
14 - 122 °F (-10 - 50 °C)
908.4 MHz US
250' +
Blue
Extender, Battery, Set-Up Guide
FCC, IC, Z-Wave +, RoHS, WEEE, ETL based on UL60950
(Tested by ETL)
UL 1023 Standard for Household Burglar-Alarm System Units
UL 985 Standard for Household Fire Warning System Units
UL 1635 Standard for Digital Alarm Communica- tor System Units
UL 94 Standard for Safety of Flammability of Plas- tic Materials for Parts in Devices
and Appliances
ULC 1023 Preliminary Standard For Household Burglar Alarm System Units
Including notch excluding plug: 89.6X47X29.4mm Excluding notch and plug:
81X47X29.4mm
Action button
3
