Ring Keypad EU – Association Information

Association - Lifeline

This keypad has one Association group and Max 1 node. Group 1 is a lifeline group who will receive
unsolicited messages relating to entry control notifications, notifications reports, battery report
notifications, and device reset locally notifications
Ring Key EU – Configuration Information
Ring Keypad offers a wide variety of advanced configuration settings. Below parameters can be
accessed from main controllers configuration interface.
Parameter Size
1 (0x01) 2
2 (0x02) 1
3 (0x03) 1
4 (0x04) 1
5 (0x05) 1
6 (0x06) 1
7 (0x07) 1
8 (0x08) 1
9 (0x09) 1
10 (0x0A) 1
11 (0x0B) 1
12 (0x0C) 1
13 (0x0D) 1
14 (0x0E) 1
15 (0x0F) 1
4
Default Value/
Description
Dec
Battery Report Interval: Default Heartbeat check in time. Available settings:
70
70-1440 mins.
Z-Wave Sleep Timeout: Time to wait after receiving ZW for more OTA
1
messages. Available settings: 1-5 seconds
Co-Proc Is Alive: Base Station check to see if the co-proc is operational.
1
0 = No 1 = Yes
Proximity Timeout : Timeout when proximity is detected and no input
5
is received. Available settings: 0-30 seconds
Button Press Timeout : Timeout when a button is pressed, but a sequence is
5 not completed and buttons are no longer being pressed Available settings:
0-30 seconds
15 Status Change Timeout: Available settings: 10-60 seconds
Power Mode: Set the battery power saving mode for the keypad.
0
0=Extended Battery Life 1=Normal Battery Life
Key Backlight Timeout: Timeout for keypad LED backlight to stay on between
3
key presses. Available settings: 1-15 seconds
Key Backlight Brightness: Adjusts the brightness of the keypad backlight
100
Available settings: 0-100%
8 Key Tone Volume: Volume, Tone Time, Frequency Available settings: 0-10
Ambient Light Sensor Level: Light threshold where keypad will stop backlight-
5
ing if higher than Available settings: 0-100
Siren Volume: Volume to produce loudest output, Needs to be calibrated
6
Available settings: 0-10
Proximity On/OFF: Turn On and Off the Proximity Detection.
1
0 = off 1 = on
Proximity Distance: Adjusts the proximity distance (CM) If applicable to the
100 product.
Available settings: 0-100CM
Extended Battery Life LED Brightness Adjustment: Percentage of brightness
for all LEDs in "Power
50
Mode" = Extended (needs calibration)
Available settings: 0-100%
