AGFA Automatic 66 Instructions For Use Manual page 8

QUICK START GUIDE
Important
until the first
shot!
Important for
each
subsequent
shot!
6
1. Film insertion.
2. Set the type of film on the film indicator (2)
3. Set automation (4), set green point next to green A.
4. Set the ASA scale (3), set the black triangle to the
desired sensitivity of the film.
5. Set the locking
exposure time, the green point next to the green A.
6. Aim at the object, note the scale (7) of the exposure
meter, if necessary adjust the diaphragm (8).
7. Set the focus distance using the range-finder, move
the focusing lever (12) until the central range-finding
image coincides with the viewfinder image.
8. Tension the shutter winding lever (9) and push the
release button (10).
9. Turn the film transport knob (20) as far as it will go,
the next film frame number will then appear in the
frame counter window (11).
ring (6) to the shortest
Detailed
description
on page
8-11
7
18
18
possible
18
19
16/17
14
12
