Amco Veba 914NG User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
U
M
U
M
S
E
R
S
E
R
9
1
4
N
G
9
1
4
N
G
7845285-06 03/20
subject to change without notice
A
N
U
A
L
A
N
U
A
L
ORIGINAL INSTRUCTIONS

Advertisement

loading
Need help?

Need help?

Do you have a question about the 914NG and is the answer not in the manual?

Questions and answers

Related Manuals for Amco Veba 914NG

Summary of Contents for Amco Veba 914NG

  • Page 1 7845285-06 03/20 ORIGINAL INSTRUCTIONS subject to change without notice...
  • Page 3 USER MANUAL 914NG NDEX WARNINGS ........................A.1 PERSONAL PROTECTIVE EQUIPMENT ....................A.1 MECHANICAL HAZARDS ........................A.2 A.2.1 STRUCTURAL RESISTANCE ........................A.2 A.2.2 CRUSHING HAZARD ..........................A.4 A.2.3 CUTTING HAZARD ........................... A.5 A.2.4 IMPACT HAZARD ............................. A.6 A.2.5 OIL LEAK HAZARD ........................... A.7 A.2.6...
  • Page 4 USER MANUAL 914NG NDEX B.7.7 OPENING PROCEDURE ........................B.38 B.7.8 HOW TO READ THE LOAD CHART ....................... B.39 B.7.9 LIFTING OPERATIONS .......................... B.39 B.7.10 CLOSING PROCEDURE ......................... B.40 B.7.11 HOW TO FOLD THE STABILIZERS WITH MANUALLY OPERATED EXTENSIONS ......B.42 B.7.12...
  • Page 5 USER MANUAL 914NG ARNINGS WARNINGS PERSONAL PROTECTIVE EQUIPMENT During normal crane operations the users must wear: - helmet - safety gloves - industrial footwear - overalls secured using buttons and without loose or baggy parts - high visibility clothing IN ADDITION + oil-proof gloves and safety goggles during maintenance tasks.
  • Page 6 USER MANUAL 914NG ARNINGS MECHANICAL HAZARDS The most common mechanical hazards due to a failure to follow the instructions in this user manual are listed below. A.2.1 STRUCTURAL RESISTANCE The structural resistance may be impaired by the following adverse working conditions:...
  • Page 7 USER MANUAL 914NG ARNINGS LIFTING COMPONENT - Excessive forces if lifting components other than hook are used IP PROTECTION LEVEL - Electric system faults (safety and controls) WARNINGS - Do NOT use the crane if the operating conditions are incompatible with the instructions given in this manual.
  • Page 8 USER MANUAL 914NG ARNINGS A.2.2 CRUSHING HAZARD Crushing hazards derive from moving components on the crane: • body crushing between the crane and vehicle • upper limb crushing between base and crane booms • body crushing between stabilisers and a stationary object during stabilizer opening •...
  • Page 9 USER MANUAL 914NG ARNINGS - Do NOT place lower limbs between the stabiliser legs and the vehicle. Do NOT place hands near the stabiliser extensions during retraction. - Do NOT perform maintenance when the crane is moving or when the power take-off is enabled.
  • Page 10 USER MANUAL 914NG ARNINGS A.2.4 IMPACT HAZARD Residual hazard associated with • impact with the crane boom during unfolding/folding • impact with the moving load • impact with the stabilisers • impact caused by an accidental release of the load WARNINGS - Take care not to bump against moving parts on the crane.
  • Page 11 USER MANUAL 914NG ARNINGS A.2.5 OIL LEAK HAZARD Hydraulic fluid leaks can cause burns, irritation to the skin and eyes and can even penetrate under the skin. These hazards are associated with incorrect tightening of fittings, rubbing of hoses against metal parts, excessive bending of hoses, incorrect disconnection of hoses during maintenance, incorrect repairs, ageing, etc.
  • Page 12 USER MANUAL 914NG ARNINGS A.2.6 LOSS OF STABILITY Loss of stability can cause serious damage to property and injury to persons. Carefully follow the stabilizing procedure specified in this user manual. Do NOT tamper with safety devices. Stabilize the crane on firm ground.
  • Page 13 USER MANUAL 914NG ARNINGS - Do NOT place the stabilizer feet near drains, manholes, wells, electric conduits and in general on any surface unable to support the maximum stabilizer force. - When working on bridges the stabilizer feet must be placed at least one metre from the edge.
  • Page 14 USER MANUAL 914NG ARNINGS - Do NOT tamper with electrical, electronic and hydraulic safety devices on the machine. Check that all safety and protection devices are installed and functioning correctly before using the crane. - When a load is lifted for the first time proceed slowly and carefully to ensure that the area of stability for the machine has been identified correctly.
  • Page 15 USER MANUAL 914NG ARNINGS ELECTRIC SHOCK HAZARD A.3.1 CONTACT WITH LIVE COMPONENTS There is an electric shock hazard for the user under the following conditions: • if the crane comes into contact with electrical power lines • if the crane is struck by lightning WARNINGS - The crane should only be operated at a distance D of at least 7 m from electrical power lines.
  • Page 16 USER MANUAL 914NG ARNINGS A.3.2 STATIC ELECTRICITY The crane can accumulate static electricity. This generally occurs when the material placed between the stabiliser feet and the ground is an insulator e.g. wood, the crane is used near radio transmitters or high frequency switching systems and when a storm is approaching.
  • Page 17 USER MANUAL 914NG ARNINGS VIBRATION HAZARDS There are no significant vibration hazards in that a loader crane is used for short periods and therefore there is no significant effect on the operator. HAZARDS DUE TO TOXIC SUBSTANCES These hazards are associated with: •...
  • Page 18 USER MANUAL 914NG ARNINGS ERGONOMIC HAZARDS A.8.1 MANUAL OPERATIONS WARNINGS - Do not place the body under excessive strain when operating the crane. If manual operations are required (e.g. pivoting stabilizer legs, lifting manual extensions or other components) or the load must be moved by hand, do NOT lift a weight of more than 25 kg (20 kg for women).
  • Page 19 USER MANUAL 914NG ARNINGS UNEXPECTED START-UP AND SWITCH-OFF Impact, crushing, load loss and stability loss hazards exist as a result of accidental crane start-up and switch-off. WARNINGS - Before using the crane check that there is enough fuel and the battery is in good condition.
  • Page 20 USER MANUAL 914NG ARNINGS - Before moving the vehicle always check that: • The crane is folded correctly in transport position (1). • The stabilizer extensions are fully retracted and locked (2). If the extensions are locked using a pin, this must be inserted perfectly in the extension.
  • Page 21 USER MANUAL 914NG ARNINGS A.11 COUPLING FAULTS There is a serious risk of damage to property and injury to persons in the event of incorrect coupling of mechanical and hydraulic components between the crane and the vehicle, between the crane and the lifting components and between the lifting components themselves.
  • Page 22 USER MANUAL 914NG ARNINGS - Visually check that the screws of the slewing cylinders, all nuts and bolts in general are tightened properly. - Check that pins and screws used on the extensions and on other lifting tools are assembled and secured correctly.
  • Page 23 USER MANUAL 914NG ARNINGS A.12 HAZARDS DUE TO INCORRECT LIFTING OPERATIONS Residual hazards exist as a result of incorrect lifting operations: • Loss of stability • Uncontrollable load, overload, exceeding the overturning limit • Uncontrollable speed of movements, oscillation of the load •...
  • Page 24 USER MANUAL 914NG ARNINGS - Lifting of loads not placed on rigid and fixed supports unless the user knows the weight of the load being moved: e.g. lift truck releasing an excessive load on the hook; lifting a floating load, etc.
  • Page 25 USER MANUAL 914NG ARNINGS - Using the machine under adverse weather conditions (e.g. high winds). - Placing the load on surfaces with unsuitable strength, area or inclination. - Handling of loads at heights is strongly unrecommended: the load could bump against the booms and oscillations of load and booms could cause a sudden increase of the lifting/tipping moment.
  • Page 26 USER MANUAL 914NG ARNINGS A.13 HOW TO TRANSPORT THE CRANE Before installation, the crane must be moved safely, in order to avoid falls and impacts with objects and persons. During transport of the crane, the carrier must follow the instructions below: •...
  • Page 27 USER MANUAL 914NG ARNINGS A.14 WARNINGS FOR USE WITH MANUAL EXTENSIONS There are additional specific hazards for cranes with manual extensions as listed below: • Hazards resulting from structural failure of a manual extension • Crushing and cutting hazard for fingers during mounting, extraction, retraction.
  • Page 28 USER MANUAL 914NG ARNINGS - Do NOT insert fingers inside free housings of securing components (in particular housings for locking pins of manual extensions). - Avoid boom positions causing the unpinned extension to move at high speeds. Keep away from the extension’s trajectory.
  • Page 29 USER MANUAL 914NG ARNINGS A.15 WARNINGS FOR USE WITH JIB There are additional specific hazards for cranes equipped with a jib, as listed below: • Crushing and cutting hazard for upper limbs between moving parts of the jib. • Impact hazard with property and people during opening and closing of jib.
  • Page 30 USER MANUAL 914NG ARNINGS A.16 WARNINGS FOR USE WITH BUCKET - GRAPPLE There are additional specific hazards for cranes equipped with bucket as listed below: • Crushing and cutting hazard for upper and lower limbs in the bucket and moving parts.
  • Page 31 USER MANUAL 914NG ARNINGS - The working area must be big enough to contain the tool when operating at the maximum opening (Db < A). - Only use the crane to lift free loads. Do NOT press objects or material with the tool.
  • Page 32 USER MANUAL 914NG ARNINGS A.17 WARNINGS FOR USE WITH DRILL There are additional specific hazards for cranes equipped with a drill as listed below: • Entrapment, crushing and cutting hazard for upper and lower limbs on the drill body. • Flying loose material hazard caused by drill operation.
  • Page 33 USER MANUAL 914NG USER MANUAL PREMISE Dear Customer, Thank you for buying our product. We have done everything we can to supply you with an excellent and safe product. Please follow the instructions given below to ensure that your crane operates safely: - Follow the warnings as well user and maintenance instructions.
  • Page 34 MANUFACTURER H.C.E. s.r.l. Unico Socio Via Einstein 4, 42028 POVIGLIO (RE) ITALY CRANE TYPE: 914NG NO CE CONTROLS  NO RDC (without radio remote control)  RDC (with NO CE radio remote control)  TOP (with Basic/Graphic radio remote control) CE CONTROLS ...
  • Page 35 USER MANUAL 914NG DESCRIPTION AND DOCUMENTATION B.3.1 ENCLOSED DOCUMENTATION Assembly must be performed by an authorised assistance centre in accordance with the instructions in the installer manual released by the manufacturer and the vehicle setup specifications. The installer must provide training for operators concerning all aspects of crane functioning at the moment of machine delivery in accordance with ISO 9926-1.
  • Page 36 USER MANUAL 914NG B.3.3 SERVICE CONDITIONS The machine is designed to operate under the following conditions: Service conditions DESCRIPTION RANGE Environmental temperature -10°C ÷ 40°C In-service wind Wind state: Light (EN 13001-2) (see B.8.4 for special conditions) Max. mean wind speed: 34 km/h...
  • Page 37 USER MANUAL 914NG B.3.4 MAIN COMPONENTS A list of the main crane components is given below in accordance with EN 12999: MAIN COMPONENTS Column boom cylinder boom boom cylinder boom Extension cylinders Hydraulic extensions Stabilizer cylinder Stabilizer extension Oil tank...
  • Page 38 USER MANUAL 914NG CONTROLS B.4.1 CONTROL STATIONS NO RDC-CRANE On main control valve side For NO CE only. 7845285-06 03/20 subject to change without notice...
  • Page 39 USER MANUAL 914NG NO RDC-CRANE On opposite control valve side For NO CE only. 7845285-06 03/20 subject to change without notice...
  • Page 40 USER MANUAL 914NG RDC-CRANE EMERGENCY CONTROLS WITH DISPLAY On the main control valve side 7845285-06 03/20 subject to change without notice...
  • Page 41 USER MANUAL 914NG RDC-CRANE EMERGENCY CONTROLS WITHOUT DISPLAY On the main control valve side In case of work lights only. 7845285-06 03/20 subject to change without notice...
  • Page 42 USER MANUAL 914NG RDC-CRANE EMERGENCY CONTROLS On opposite main control valve side RDC-CRANE WITH RADIO-CONTROLLED STABILIZERS BUTTONS FOR ACTIVATING THE STABILIZER CONTROLS VIA RADIO On both sides of the crane, close to the stabilizer controls. Activation of radio stabilizer controls...
  • Page 43 USER MANUAL 914NG RDC-CRANE WITH RADIO-CONTROLLED STABILIZERS EMERGENCY RADIO STABILIZER CONTROLS On the opposite main control valve side, under the cover. The serigraphs shown above are for explanations only: they are not applied on the cover. 7845285-06 03/20 subject to change without notice...
  • Page 44 USER MANUAL 914NG B.4.2 DESCRIPTION OF CONTROLS FLOW DEVIATION LEVER (NO CE, NO RDC) • Lever UP: crane enabled, stabilizers disabled • Lever DOWN: crane disabled, stabilizers enabled KEY SWITCH SELECTOR (RDC, NO TOP) Stabilizers controls enabled Crane controls disabled...
  • Page 45 USER MANUAL 914NG STABILIZERS CONTROLS ON THE MAIN CONTROL VALVE SIDE ON THE OPPOSITE MAIN CONTROL VALVE SIDE Stabilizer extension Stabilizer extension on the side where the on the side where the option option operator is working operator is working...
  • Page 46 USER MANUAL 914NG B.4.5 EMERGENCY CONTROLS In case of failure, the operator can pass manually from the crane controls to the stabilizer controls and vice versa following the procedures below. CE, NO RDC CRANE Break the seal sticker, push and turn the manual actuator. Then screw the knurled knob under the main control valve (see figure below).
  • Page 47 USER MANUAL 914NG In addition, in case of stabilizers controlled by radio, activate the emergency stabilizers controls following this procedure: - mount (by screwing) on stabilizer control valve the two suitable levers supplied demounted: the first one on “IN” element; the second one on “MS” element corresponding to the cylinder to move.
  • Page 48 USER MANUAL 914NG SAFETY DEVICES B.5.1 OVERCENTER VALVES The overcenter valves are fitted on the 1 boom cylinder and on the 2 boom cylinder. Their purpose is to lower or block the load if the pressure into the cylinders reaches the setting value. So the crane structure is made safe.
  • Page 49 USER MANUAL 914NG B.5.3 MOMENT LIMITER The purpose of the moment limiter is to protect the crane's structure from overload and ensure machine stability. It constantly detects the pressure in the 1st boom cylinder and intervenes when the lifting moment exceeds the setting value.
  • Page 50 USER MANUAL 914NG B.5.4 LOCKING DEVICES FOR STABILIZER EXTENSIONS FOR ALL CRANE VERSIONS On both sides of the base an automatic lock is installed. Its purpose is to lock automatically the stabilizer extension in its fully closed position. To release the extension and pull it out, it’s necessary to pull the automatic lock and pull out the extension with the...
  • Page 51 USER MANUAL 914NG B.5.5 LOCKING DEVICE FOR TURNING STABILIZER LEGS Their purpose is to lock the rotation of the stabilizer legs in working and transport position. LOCKING DEVICE WITH LEVER FOR MANUAL TURNING STABILIZERS Locking pin Rotating lever LOCKING DEVICE WITH LEVER FOR AUTOMATIC TURNING STABILIZERS...
  • Page 52 USER MANUAL 914NG B.5.6 SLEWING LIMITERS The NO CE crane can be equipped with slewing limiter: its purpose is to block the crane rotation toward the prohibited working zone (for example in front of the truck cab). The installation of the slewing limiter after the crane sale must be made at an authorized assistance center.
  • Page 53 USER MANUAL 914NG GAUGES AND INDICATORS B.6.1 GAUGES ON OIL TANK OIL LEVEL INDICATORS The oil tank is fitted with two visual level indicators in order to check the amount of oil in the tank. Maximum level Minimum level THERMOMETER CE cranes are fitted with a thermometer that shows the current oil temperature in degrees Celsius: •...
  • Page 54 USER MANUAL 914NG CLOGGING INDICATOR The CE tank filter and the high pressure filter (option) have clogging indicators that indicate when the filter cartridge has to be replaced (pressure gauge on red). RDC-cranes are always equipped with high pressure filter and clogging indicators.
  • Page 55 USER MANUAL 914NG PRESSURE GAUGES (OPTION FOR NO CE) The pressure gauges indicate the pressure of the 1.boom cylinder. • Green sector: 90% of lifting capacity is not reached • Yellow sector: 90% of lifting capacity is reached • Red sector: 100% of lifting capacity is reached B.6.3...
  • Page 56 USER MANUAL 914NG B.6.4 OPERATING HOURS COUNTER (NO CE, NO TOP) The hours counter is installed at the control station on the main control valve side. Purpose of the counter is to indicate the total operating hours of the crane: the user shall perform the planned maintenance at the intervals shown in the Maintenance Record (see C.3).
  • Page 57 USER MANUAL 914NG OPERATING THE CRANE B.7.1 PRELIMINARY CHECKS BEFORE OPERATION Before using the crane check that - crane's structure, safety devices and safety signs are intact. - there are no parts on the equipment which have not been checked or are not permitted.
  • Page 58 USER MANUAL 914NG B.7.3 HOW TO DEPLOY THE STABILIZERS WITH MANUALLY OPERATED EXTENSIONS LOCKING DEVICES OF STABILIZER EXTENSIONS Automatic lock Lock support Semi-automatic locking device Lever 3 up: the locking device 1 is engaged or ready to get engaged Lever 3 down: the locking device 1 in disengaged Operating the crane is allowed only when the stabilizers are deployed correctly.
  • Page 59 USER MANUAL 914NG 2) Lower the automatic lock 1, rotate and lay the lock support 2 on the pin. 3) Pull the suitable handle and extract completely the stabilizer extension till the semi-automatic locking device 3 does stop the beam extension, then shake it to be sure the locking device 3 is fully engaged.
  • Page 60 USER MANUAL 914NG 4) If the crane is fitted with turning stabilizer legs, rotate downwards the leg up to the vertical position (see B.7.5) 5) Extend the cylinder till to place the foot on the ground, without fully discharging the vehicle's suspension.
  • Page 61 USER MANUAL 914NG B.7.4 HOW TO DEPLOY THE STABILIZERS WITH HYDRAULICALLY OPERATED EXTENSIONS LOCKING DEVICE OF STABILIZER EXTENSIONS Automatic lock Lock support Operating the crane is allowed only when the stabilizers are deployed correctly. Always use the controls on the side on which you are operating the crane.
  • Page 62 USER MANUAL 914NG 2) Lower the automatic lock 1, rotate and lay the lock support 2 on the pin. 3) By using the control lever below extract the stabilizer extension. The yellow warning sign on extension appears, if the extension is fully extracted.
  • Page 63 USER MANUAL 914NG 4) If the crane is fitted with turning stabilizer legs, rotate downwards the leg up to the vertical position (see B.7.5) 5) Extend the cylinder till to place the foot on the ground, without fully discharging the vehicle's suspension.
  • Page 64 USER MANUAL 914NG B.7.5 HOW TO ROTATE DOWNWARDS THE MANUAL TURNING STABILIZER LEGS LOCKING DEVICE OF TURNING LEGS Locking device with lever Lever 1 perpendicular to extension axis (down): the locking device is engaged Lever 1 parallel to extension axis (up): the locking device is disengaged Execute the following procedure: 1) Grasp the handle and turn counter-clockwise the lever (the locking device is disengaged).
  • Page 65 USER MANUAL 914NG 2) Rotate slightly the leg, holding the locking device 1 in disengaged state. 3) Then release the locking lever and rotate fully the leg downwards up to the vertical position: the locking device engages automatically (the lever turns clockwise and goes down). If the locking device doesn't engage, shake lightly the leg.
  • Page 66 USER MANUAL 914NG B.7.6 HOW TO DEPLOY THE AUTOMATIC TURNING STABILIZERS LOCKING DEVICES OF STABILIZER EXTENSIONS Automatic lock of stabilizer extension Lock support Locking device of stabilizer leg Operating the crane is allowed only when the stabilizers are deployed correctly.
  • Page 67 USER MANUAL 914NG 2) Lower the automatic lock 1, rotate and lay the lock support 2 on the pin. 3) Unlock the pin by rotating counterclockwise the lever until the pin guide reaches the unlocked position (see B.5.5). 7845285-06 03/20 subject to change without notice B.35...
  • Page 68 USER MANUAL 914NG 4) Operate the control lever for extracting the stabilizer extension. The yellow warning sign on extension appears, if the extension is fully extracted. 5) Operate the lever for extending the cylinder leg and rotate it slightly by only a few degrees.
  • Page 69 USER MANUAL 914NG 6) Then release the pin by rotating the lever clockwise completely. 7) Fully rotate the leg downwards to the vertical position: the locking device engages automatically (the pin guide reaches the locked position). If the locking device is not engaged, shake lightly the leg until you obtain the engagement.
  • Page 70 USER MANUAL 914NG B.7.7 OPENING PROCEDURE 1) If the crane is in folded position, fully retract the 2nd boom cylinder (articulation cylinder). 2) Lift the 1st boom so that the 2nd boom can rotate freely. 3) Move the 2nd boom to the horizontal position.
  • Page 71 USER MANUAL 914NG B.7.8 HOW TO READ THE LOAD CHART 914NG VE BA AMC O 2120 1345 4.96 6.91 8.86 10.91 12.96 15.11 17.26 100% Fmax = 8025 daN 19.36 The load chart shows the rated loads (kg) that the crane can lift depending on working radius (m).
  • Page 72 USER MANUAL 914NG B.7.10 CLOSING PROCEDURE The operator should close the crane from the column side to avoid collisions with moving parts of the crane. 1) Close the hydraulic extensions of the crane 2) Move the 1st boom so that the 2nd boom can rotate freely.
  • Page 73 USER MANUAL 914NG 4) Close the 2nd boom completely, operating the control lever of the articulation cylinder. 5) Lower the 1st boom until the recovery locks are in their seats. Block the crane. If, for transport, the crane is closed with the boom on the vehicle body, make sure that the crane cannot move.
  • Page 74 USER MANUAL 914NG B.7.11 HOW TO FOLD THE STABILIZERS WITH MANUALLY OPERATED EXTENSIONS LOCKING DEVICES OF STABILIZER EXTENSIONS Automatic lock Lock support Semi-automatic locking device Lever 3 up: the locking device 1 is engaged or ready to get engaged Lever 3 down: the locking device 1 in disengaged The stabilizers can be closed exclusively after the booms are closed in transport position.
  • Page 75 USER MANUAL 914NG 2) If the crane is fitted with turning stabilizer legs, rotate the leg up to its transport position (see B.7.13) 3) Turn the lever 3 downwards up to its vertical locking position: the locking device is disengaged.
  • Page 76 USER MANUAL 914NG B.7.12 HOW TO FOLD THE STABILIZERS WITH HYDRAULICALLY OPERATED EXTENSIONS LOCKING DEVICE OF STABILIZER EXTENSIONS Automatic lock Lock support The stabilizers can be closed exclusively after the booms are closed in transport position. Always use the controls on the side on which you are operating the crane.
  • Page 77 USER MANUAL 914NG 3) Retract fully the stabilizer extension. The automatic lock 1 engages automatically. 7845285-06 03/20 subject to change without notice B.45...
  • Page 78 USER MANUAL 914NG B.7.13 HOW TO ROTATE UPWARDS THE MANUAL TURNING STABILIZER LEGS LOCKING DEVICE OF TURNING LEGS Locking device with lever Lever 1 perpendicular to extension axis (down): the locking device is engaged Lever 1 parallel to extension axis (up): the locking device is disengaged Execute the following procedure: 1) Grasp the handle and turn clockwise the lever (the locking device is disengaged).
  • Page 79 USER MANUAL 914NG 2) Rotate slightly the leg, holding the locking device 1 in disengaged state. 3) Then release the locking lever and rotate fully the leg upwards up to the vertical position: the locking device engages automatically (the lever turns clockwise and goes down). If the locking device doesn't engage, shake lightly the leg.
  • Page 80 USER MANUAL 914NG B.7.14 HOW TO FOLD THE AUTOMATIC TURNING STABILIZERS LOCKING DEVICES OF STABILIZER EXTENSIONS Automatic lock of stab. extension Lock support Locking device of stab. leg The stabilizers can be closed exclusively after the booms are folded in transport position.
  • Page 81 USER MANUAL 914NG 2) Unlock the pin by rotating clockwise the lever until the pin guide reaches the unlocked position (see B.5.5). 3) Operate the lever for retracting the cylinder leg: fully retract the rod and rotate slightly the leg by only a few degrees.
  • Page 82 USER MANUAL 914NG 4) Then release the pin by rotating the lever clockwise completely. 5) Fully rotate the leg upwards to the vertical position: the locking device engages automatically (the pin guide reaches the locked position). If the locking device is not engaged, shake lightly the leg until you obtain the engagement.
  • Page 83 USER MANUAL 914NG B.7.15 USE WITH MANUAL EXTENSIONS The manual extensions can be used only with the hook to increase the crane's outreach. The maximum capacity of each manual extension is constant (see A.14), indicated in the load chart and marked on a plate applied on the extension itself.
  • Page 84 USER MANUAL 914NG B.7.16 USE WITH JIB The jib is an optional accessory which does not modify the intended use of the crane on which it is fitted. A list of the main jib components is given below: MAIN COMPONENTS...
  • Page 85 USER MANUAL 914NG UNFOLDING PROCEDURE 1) After having fully extended the extensions of basic crane, rotate the jib boom (2). 3) Extend hydraulic jib extensions until the hook reach the vertical line of the load to be lifted. FOLDING PROCEDURE 1) Fully retract the jib extensions, then retract the basic crane extensions (2).
  • Page 86 USER MANUAL 914NG MOMENT LIMITER FOR JIB It constantly detects the pressures in the 1st boom cylinder and in the jib articulaton cylinder. When an overload condition is reached, the crane movements are blocked according to the figure below. Maximum setting pressure reached in the 1 boom cylinder 2.boom and jib over the horizontal...
  • Page 87 USER MANUAL 914NG HOW TO ASSEMBLE THE JIB 1) Let align the boom extensions of the basic crane towards the jib attachment. 2) Slowly open the basis crane extensions until the pin holes are aligned (see figure). 3) Insert the locking pin and the split pin.
  • Page 88 USER MANUAL 914NG B.7.17 USE WITH BUCKET-GRAB The bucket can only be operated when the crane opening procedure is complete. The control is used to open and close the bucket thus allowing to lift and release the load. The bucket is often secured to a hydraulic rotor that allows to rotate on its own axis. There is a separate control for this.
  • Page 89 USER MANUAL 914NG USE UNDER SPECIAL SERVICE CONDITIONS Exceptionally, the crane can be operated even if the service conditions are not met, i.e when: - the stabilizers feet are deployed on a soft surface - the crane is operated in low-temperature environments - the inclination angle of the crane's base exceeds the max.
  • Page 90 USER MANUAL 914NG B.8.2 LOW-TEMPERATURE ENVIRONMENTS The crane is designed to withstand the maximum stresses when the environmental temperature is within the range given in B.3.3. When the environmental temperature is below the allowable range, then a derating factor shall be applied to the max. working pressure, as follows: = κ...
  • Page 91 USER MANUAL 914NG B.8.4 IN-SERVICE WIND The crane is designed to withstand occasionals loads due to the wind effects. According to EN 13001-2, the crane can be safely operated under the following wind state: - Wind state: Light - Max. mean wind speed: v = 9.4 m/s (34 km/h, 5 Beaufort) If the wind speed should exceed the limit above, then a derating factor shall be applied to the max.
  • Page 92 USER MANUAL 914NG The following table shows the Beafort scale and its wind speed ranges. BEAUFORT SCALE Wind speed Beaufort Wind Symbol Effect force km/h Calm 0 - 0.2 0 - 1 Smoke rises vertically Light air 0.3 - 1.5...
  • Page 93 USER MANUAL 914NG AINTENANCE MAINTENANCE WARRANTY TERMS The manufacturer declines all responsibility for damage to the crane caused by failed maintenance or lubrication. Preventive routine maintenance refers to machine use in non-abrasive and non- corrosive environments. Failure to abide by this stipulation shall result in all guarantees for faults being declared null and void.
  • Page 94 USER MANUAL 914NG AINTENANCE GREASING CHART Manual greasing of boom extensions' sliding surfaces Frequency of greasing: 200 working hours / 180 days Manual greasing of stabilizer extensions' sliding surfaces Frequency of greasing: 100 working hours / 90 days Greasing under pressure of nipples...
  • Page 95 USER MANUAL 914NG AINTENANCE C.2.2 FILLING UP THE OIL TANK Before using the crane, check the oil level in the tank: the level with horizontal crane at rest, must always be between the minimum and maximum level. If the level is under the minimum, fill up the tank.
  • Page 96 USER MANUAL 914NG AINTENANCE PLANNED AND EXTRAORDINARY MAINTENANCE The owner of the crane is responsible for contacting an authorised assistance centre to perform the following maintenance activities: - planned maintenance - maintenance after inactivity - extraordinary maintenance All maintenance activities are scheduled and must be registered in the Maintenance Record: the maintenance schedule must be signed by the authorised assistance centre.
  • Page 97 USER MANUAL 914NG ECHNICAL HEET TECHNICAL SHEET 7845285-06 03/20 subject to change without notice...
  • Page 98 USER MANUAL 914NG ECHNICAL HEET CRANE'S TECHNICAL DATA Versions 3SJ2 4SJ2 Max. net lifting moment 12.0 11.6 11.2 10.9 10.5 80.6 82.8 15570 14120 daNm Max. dynamic moment Capacity at min. hook [S2] 2595 2465 2340 2225 2120 1020 1020...
  • Page 99 USER MANUAL 914NG ECHNICAL HEET WINCH SETTINGS TI1 - SINGLE LINE PULL Versions 3SJ2 4SJ2 Max line pull 1000 1000 1000 1000 1000 TI1 - DOUBLE LINE PULL 3SJ2 4SJ2 Versions Max line pull 1000 1000 1000 1000 1000 TI2 - SINGLE LINE PULL...
  • Page 100 USER MANUAL 914NG ECHNICAL HEET OVERALL DIMENSIONS FIXED STABILIZERS LEGS 2450 20° Ø 180 2265 2445 4200 ST EXTRA FUNCTION 5400 EX 6600 SE W (mm) W+ (mm) 930 (*) 930 (*) 930 (*) 975 (**) 975 (**) (*) activations with slides...
  • Page 101 USER MANUAL 914NG ECHNICAL HEET OVERALL DIMENSIONS 3SJ2 FIXED STABILIZERS LEGS 2450 20° Ø 180 2265 2445 4200 ST 5400 EX 6600 SE TURNING STABILIZERS LEGS 2510 2530 SE 180° Ø 180 20° 2312 2492 4250 ST 5432 EX 6648 SE...
  • Page 102 USER MANUAL 914NG ECHNICAL HEET OVERALL DIMENSIONS 4SJ2 FIXED STABILIZERS LEGS 2450 20° Ø 180 2265 2445 4200 ST 5400 EX 6600 SE TURNING STABILIZERS LEGS 2510 2530 SE 180° Ø 180 20° 2312 2492 4250 ST 5432 EX 6648 SE...
  • Page 103 USER MANUAL 914NG ECHNICAL HEET BASE DIMENSIONS AND MOUNTING BOLTS 1128 1128 2070 Material Tightening Ref. Description Q.ty Size Grade torque Kit with 8 42CrMo4+QT M24x2 400 Nm crane mounting bolts EN 10083-3 L=1100 Kit with 4 42CrMo4+QT M30x2 700 Nm...
  • Page 104 USER MANUAL 914NG ECHNICAL HEET INSTALLATION TYPE NUMBER Installation types numbers (ITN) for cranes with standard dead point (STOP) toward swing bridge. OPPOSITE DEAD POINT STANDARD DEAD POINT STOP STOP STOP STOP STOP STOP STOP STOP STOP STOP STOP STOP...
  • Page 105 USER MANUAL 914NG ECHNICAL HEET LIFTING HEIGHT CLOSE TO THE COLUMN 1000 Version 2192 2109 2026 1946 1871 7845285-06 03/20 subject to change without notice...
  • Page 106 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK/TOOL 914NG 2S 18,8 16,5 14,4 12,2 13° 1770 1345 2595 2595 1770 1345 4.63 6.58 8.53 10.91 12.96 15.11 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools...
  • Page 107 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK/TOOL 914NG 3S 18,7 16,5 14,4 13° 2465 1650 1230 2465 1650 1230 4.71 6.66 8.61 10.66 12.96 15.11 17.26 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools...
  • Page 108 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK/TOOL 914NG 4S 18,8 16,5 13° 2340 1540 1125 2340 1540 1125 4.80 6.75 10.75 17.26 8.70 12.80 15.11 19.36 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools...
  • Page 109 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK/TOOL 914NG 5S 18.8 13° 2225 1435 1025 2225 1435 1025 4.88 6.83 8.78 10.83 12.88 15.03 17.26 19.36 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools...
  • Page 110 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK/TOOL 914NG 6S 13° 2120 1345 2120 1345 4.96 6.91 8.86 10.91 12.96 15.11 17.26 19.36 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools If an additional lifting tool is mounted, the rated capacities shall be reduced by the tool's weight 7845285-06 03/20 D.14...
  • Page 111 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK 914NG 3SJ2 21.4 19.8 1020 (**) 13.35 14.75 16.22 17.80 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools (**) Max. lifting capacity of jib The given rated capacities can be moved only by operating the jib.
  • Page 112 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR USE WITH HOOK 914NG 4SJ2 23.5 1020 (**) 15.50 16.85 18.35 19.89 100% (*) Manual extensions (optional): these cannot lift additional hydraulic tools (**) Max. lifting capacity of jib The given rated capacities can be moved only by operating the jib.
  • Page 113 USER MANUAL 914NG ECHNICAL HEET LOAD CHARTS FOR TI1 WINCH IN SINGLE LINE 914NG 2S + TI1 SINGLE LINE 75° 1000 2.9m (**) 1000 8.53 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.17...
  • Page 114 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN SINGLE LINE 914NG 3S + TI1 SINGLE LINE 75° 1000 2.9m (**) 1000 10.39 10.66 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.18...
  • Page 115 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN SINGLE LINE 914NG 4S + TI1 SINGLE LINE 75° 1000 2.9m (**) 1000 9.40 10.75 12.80 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.19...
  • Page 116 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN SINGLE LINE 914NG 5S + TI1 SINGLE LINE 75° 1000 2.9m (**) 1000 8.78 10.83 12.88 15.03 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.20...
  • Page 117 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN SINGLE LINE 914NG 6S + TI1 SINGLE LINE 75° 1000 2.9m (**) 1000 8.25 12.96 17.26 8.86 10.91 15.11 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.21...
  • Page 118 USER MANUAL 914NG ECHNICAL HEET D.10 LOAD CHARTS FOR TI1 WINCH IN DOUBLE LINE 914NG 2S + TI1 DOUBLE LINE 75° 2000 2.9m (**) 2000 1770 1345 5.82 6.58 8.53 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.22...
  • Page 119 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN DOUBLE LINE 914NG 3S + TI1 DOUBLE LINE 75° 2000 2.9m (**) 2000 1650 1230 8.61 5.49 6.66 10.66 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.23...
  • Page 120 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN DOUBLE LINE 914NG 4S + TI1 DOUBLE LINE 75° 2000 2.9m (**) 2000 1540 1125 6.75 8.70 10.75 12.80 5.20 100% (**) Minimum distance winch - pulley Winch max. pull: 1000 kg 7845285-06 03/20 D.24...
  • Page 121 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN DOUBLE LINE 914NG 5S + TI1 DOUBLE LINE 75° 1600 2.9m (**) 2000 1435 1025 5.10 6.83 8.78 10.83 12.88 15.03 100% (**) Minimum distance winch - pulley Winch max. pull with PCS: 1000 kg...
  • Page 122 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI1 IN DOUBLE LINE 914NG 6S + TI1 DOUBLE LINE 75° 1400 1500 2.9m (**) 2000 1345 17.26 5.00 6.91 8.86 10.91 12.96 15.11 100% (**) Minimum distance winch - pulley Winch max.
  • Page 123 USER MANUAL 914NG ECHNICAL HEET D.11 LOAD CHARTS FOR TI2 WINCH IN SINGLE LINE 914NG 2S + TI2 SINGLE LINE 75° 2000 3.4m (**) 2000 1770 1345 5.82 6.58 8.53 100% (**) Minimum distance winch - pulley Winch max. pull: 2000 kg 7845285-06 03/20 D.27...
  • Page 124 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI2 IN SINGLE LINE 914NG 3S + TI2 SINGLE LINE 75° 2000 3.4m (**) 2000 1650 1230 6.66 8.61 10.66 5.49 100% (**) Minimum distance winch - pulley Winch max. pull: 2000 kg 7845285-06 03/20 D.28...
  • Page 125 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI2 IN SINGLE LINE 914NG 4S + TI2 SINGLE LINE 75° 2000 3.4m (**) 2000 1540 1125 8.70 10.75 12.80 6.75 5.20 100% (**) Minimum distance winch - pulley Winch max. pull: 2000 kg 7845285-06 03/20 D.29...
  • Page 126 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI2 IN SINGLE LINE 914NG 5S + TI2 SINGLE LINE 75° 65° 1200 1200 3.4m (**) 2000 1435 1025 5.10 6.83 8.78 10.83 12.88 15.03 100% (**) Minimum distance winch - pulley Winch max.
  • Page 127 USER MANUAL 914NG ECHNICAL HEET LOAD CHART FOR WINCH TI2 IN SINGLE LINE 914NG 6S + TI2 SINGLE LINE 75° 65° 1100 1100 1200 3.4m (**) 2000 1345 6.91 8.86 10.91 12.96 15.11 17.26 5.00 100% (**) Minimum distance winch - pulley Winch max.
  • Page 128 USER MANUAL 914NG ECHNICAL HEET D.12 CENTERS OF GRAVITY AND TEST LOADS This annex contains the data needed for the stability test in accordance with EN 12999. Loads and centers of gravity Gout Pout Hooking point for the test load...
  • Page 129 USER MANUAL 914NG ECHNICAL HEET D.13 HOOK DATA HOOK MOUNTED ON STANDARD BOOM VERSIONS: 2S, 3S, 4S, 5S, 6S DIMENSIONS 165.8 TECHNICAL PROPERTIES Working load limit (WLL) : 8000 kg Material: alloy steel Weight: 6.2 kg Swivel hook Reference standard: DIN 15401 7845285-06 03/20 D.33...
  • Page 130 USER MANUAL 914NG ECHNICAL HEET HOOK DATA HOOK MOUNTED ON JIB BOOM VERSION: 3SJ2 - 4SJ2 DIMENSIONS TECHNICAL PROPERTIES Working load limit (WLL) : 5400 kg Material: alloy steel Weight: 3.2 kg Swivel hook Reference standard: DIN 15401 7845285-06 03/20 D.34...
  • Page 131 USER MANUAL 914NG ECHNICAL HEET D.14 LOAD ATTACHMENT ATTACHMENT FOR HOOK AND LIFTING TOOL R 36 R 36 7845285-06 03/20 D.35 subject to change without notice...
  • Page 132 USER MANUAL 914NG ECHNICAL HEET D.15 HYDRAULIC SYSTEM FITTINGS FOR CONNECTION TO PUMP 914NG NO RDC Control valve M 7/8"-14 M 3/4"-16 pressure line Tank M 1"1/2 M 1" 1/2 suction line EXTENSION TIMES OF HYDRAULIC CYLINDERS Extension time Retraction time 914NG Slewing (180°)
  • Page 133 USER MANUAL 914NG ECHNICAL HEET CAPACITY OF HYDRAULIC SYSTEM Cylinders extended Cylinders retracted 914NG ℓ ℓ 3SJ2 4SJ2 Capacities do not include the oil tank. ADDITIONAL CAPACITY FOR HYDRAULICALLY OPERATED STABILIZER EXTENSIONS EX-H +4.0 +2.5 SE-H +5.5 +3.5 7845285-06 03/20 D.37...
  • Page 134 USER MANUAL 914NG ECHNICAL HEET D.16 OIL COOLER TECHNICAL SPECIFICATIONS Heat transfer coefficient: 235 W/K (oil flow rate of 40 ℓ/min) Activation temperature: 48 °C Weight: 13.5 kg Capacity: 4 ℓ For a crane without oil cooler performing a sequence of standard work cycles, the difference in temperature between the oil and the environment is shown in the graph below.
  • Page 135 USER MANUAL 914NG ECHNICAL HEET However, when a crane equipped with oil cooler carries out a sequence of standard work cycles, the oil temperature exceeds 75 °C after the following working times: to exceed 75 °C τ (°C) (minutes) no limit...
  • Page 136 USER MANUAL 914NG ECHNICAL HEET D.17 ADDITIONAL STABILIZERS Additional stabilizers must be chosen so that: - the installation is stable (see Installer Manual) - the max. force acting on the additional stabilizers, F , is lower than the max. load allowed by the stabilizers itself, R ≥...
  • Page 137 USER MANUAL 914NG ECHNICAL HEET D.18 RECOMMENDED ADDITIONAL LIFTING TOOLS CLAMSHELL BUCKET Data of recommended tool Load ratio Crane Gross load Payload version HYVA weight volume capacity crane tool model 1345 H605-650 100% H605-650 100% H605-550 100% H605-450 100% H604-350...
  • Page 138 USER MANUAL 914NG ECHNICAL HEET RECOMMENDED ADDITIONAL LIFTING TOOLS ORANGE PEEL GRAPPLE Data of recommended tool Load ratio Crane Gross load Payload version HYVA weight volume capacity crane tool model H653-4 1345 100% large H653-4 100% large H653-4 100% large...
  • Page 139 USER MANUAL 914NG ECHNICAL HEET RECOMMENDED ADDITIONAL LIFTING TOOLS LOGGING GRAPPLE Data of recommended tool Load ratio Crane Gross load Payload version HYVA weight capacity crane tool model 1345 H634-0,25 4000 1175 100% H634-0,25 4000 100% H634-0,25 4000 100% H634-0,25...
  • Page 140 USER MANUAL 914NG ECHNICAL HEET RECOMMENDED ADDITIONAL LIFTING TOOLS BRICK STACK GRAPPLE Data of recommended tool Load ratio Crane Gross load Payload version HYVA weight capacity crane tool model 1345 H332-1300 1600 1080 100% H332-1300 1600 100% H332-1300 1600 100%...
  • Page 141 USER MANUAL 914NG ECHNICAL HEET RECOMMENDED ADDITIONAL LIFTING TOOLS PALLET FORK Data of recommended tool Load ratio Crane Gross load Payload version HYVA weight capacity crane tool model H415 1345 1500 1210 100% 1500-500 H415 1500 100% 1500-500 H415 1500...
  • Page 142 USER MANUAL 914NG NNEXES ANNEXES HYDRAULIC SCHEMATICS STABILIZERS MANUALLY OPERATED EXTENSIONS 1040041 Settings = 130 bar 7845285-06 03/20 subject to change without notice...
  • Page 143 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS STABILIZERS HYDRAULICALLY OPERATED EXTENSIONS FIXED OR MANUALLY TURNING STABILIZER LEGS 1040042 Settings = 130 bar = 80 bar 7845285-06 03/20 subject to change without notice...
  • Page 144 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS STABILIZERS HYDRAULICALLY OPERATED EXTENSIONS AUTOMATIC TURNING STABILIZER LEGS 1040049 Settings = 140 bar = 80 bar 7845285-06 03/20 subject to change without notice...
  • Page 145 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS ADDITIONAL STABILIZERS MANUALLY OPERATED EXTENSIONS CRANE'S STABILIZERS CONTROL VALVE CARRY-OVER 1040043 Settings = 130 bar 7845285-06 03/20 subject to change without notice...
  • Page 146 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS ADDITIONAL STABILIZERS HYDRAULICALLY OPERATED EXTENSIONS CRANE'S STABILIZERS CONTROL VALVE CARRY-OVER 1040044 Settings = 130 bar = 80 bar 7845285-06 03/20 subject to change without notice...
  • Page 147 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS RADIO CONTROLLED STABILIZERS (OPTIONAL) OPTION A5 B4 A4 B3 A3 B2 12µ 5 bar CONTROL VALVE CONTROL VALVE SIDE 1050110 Settings = 150 bar = 80 bar 7845285-06 03/20 subject to change without notice...
  • Page 148 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVES NO RDC - NO CE 25µ 1.7 bar 1030192 Settings q = 30 ℓ/min = 290 bar = 170 bar = 170 bar = 290 bar = 80 bar = 290 bar...
  • Page 149 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVES NO RDC - CE 25µ 1.7 bar 1030193 Settings q = 30 ℓ/min = 290 bar = 170 bar = 170 bar = 290 bar = 80 bar = 290 bar = 200 bar...
  • Page 150 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS SUPPLEMENTARY ACTIVATION ELEMENTS NO RDC 1030194 Settings for winch Settings for rotor und bucket/grab = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar 7845285-06 03/20...
  • Page 151 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVE RDC - NO CE HPCO 25µ 10µ 1.7 bar 6 bar 1030198 Settings q = 60 ℓ/min = 290 bar = 170 bar = 170 bar = 290 bar = 80 bar...
  • Page 152 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVE ELEMENTS AND OVERCENTER VALVES OF JIB RDC - NO CE 2° 1° set2 set1 1030227 Settings = 270 bar = 200 bar = 180 bar = 180 bar = 280 bar = 300 bar...
  • Page 153 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS SUPPLEMENTARY ACTIVATION ELEMENTS RDC - NO CE 1030199 Settings for winch Settings for rotor und bucket/grab = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar...
  • Page 154 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVE RDC - CE HPCO 25µ 10µ 1.7 bar 6 bar 1030196 Settings q = 60 ℓ/min = 290 bar = 170 bar = 170 bar = 290 bar = 80 bar = 290 bar...
  • Page 155 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVE ELEMENTS AND OVERCENTER VALVES OF JIB RDC - CE 2° 1° set2 set1 1030228 Settings = 270 bar = 200 bar = 180 bar = 180 bar = 280 bar = 300 bar...
  • Page 156 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS SUPPLEMENTARY ACTIVATION ELEMENTS RDC - CE 1030197 Settings for winch Settings for rotor und bucket/grab = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar = 200 bar 7845285-06 03/20 subject to change without notice E.15...
  • Page 157 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS CONTROL VALVE FOR LS VARIABLE DISPLACEMENT PUMP RDC - CE HPCO 25µ 10µ pump 1.7 bar 6 bar 1030238 Special settings q : variable = 320 bar = 290 bar pump 7845285-06 03/20 subject to change without notice...
  • Page 158 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS OIL COOLER (OPTION) 1030250 7845285-06 03/20 subject to change without notice E.17...
  • Page 159 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS SLEWING SYSTEM 1050102 Rack stroke : 648 mm Settings = 210 bar 7845285-06 03/20 subject to change without notice E.18...
  • Page 160 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS BOOM CYLINDER set3 set1 set2 1050093 Settings = 320 bar for 2S - 3S - 3SJ2 set1 = 315 bar for 4S - 4SJ2 set1 = 310 bar for 5S - 6S set1 = 30 bar...
  • Page 161 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS BOOM CYLINDER set2 set1 1050007 Settings = 305 bar for 2S - 3S set1 = 320 bar for 4S - 5S - 6S - 3SJ2 – 4SJ2 set1 = 315 bar set2 7845285-06 03/20 subject to change without notice E.20...
  • Page 162 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS EXTENSION CYLINDERS 6° 5° 4° 3° 2° 1° set2 set1 1050103 Settings = 400 bar set1 = 350 bar set2 7845285-06 03/20 subject to change without notice E.21...
  • Page 163 USER MANUAL 914NG NNEXES HYDRAULIC SCHEMATICS MOMENT LIMITER, NO RDC - NO CE Option 5 bar 1060093 Settings = 290 bar for 2S - 3S - 4S - 5S - 6S = 270 bar for 3SJ2 = 260 bar for 4SJ2...
  • Page 164 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS TECHNICAL DATA Supply voltage 12V - 24V Max. current absorbed by the electric system Max. current absorbed by the electric system with radio-controlled stabilizers Environment working temperature -35°C ÷ 85°C IP protection class IP 66...
  • Page 165 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS EMERGENCY STOP BUTTONS NO RDC - NO CE (OPTION) 1010225 7845285-06 03/20 subject to change without notice E.24...
  • Page 166 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS TERMINAL BOX - ELECTRIC SCHEMATIC DEV. DANFOSS WINCH OUT WINCH PWR RELE' DISP. OPTION-RDC OUT OPTION-RDC IN SERVICE RDC PWR RDC 1010244-P1 7845285-06 03/20 subject to change without notice E.25...
  • Page 167 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS TERMINAL BOX - CONNECTIONS 64 65 66 67 68 RELE' DISP. 69 70 71 72 73 74 75 76 0PTON RADIO OUT 77 78 79 80 81 82 83 84 OPTION RADIO IN 1010244-P2...
  • Page 168 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS NO CE - FULL OPTIONAL KEY SWITCH 2ND BOOM EXT. 1ST BOOM SLEWING 1 2 3 4 SERVICE 8 EL. 7 EL. 6 EL. 5 EL. 1010244-P3 7845285-06 03/20 subject to change without notice...
  • Page 169 USER MANUAL 914NG NNEXES ELECTRIC SCHEMATICS NO CE - RADIO CONTROL WIRING LAY-OUT CAN cable SERVICE cable POWER cable BU (GNYE) BK (1) RD (2) BU (GNYE) BK (1) RD (2) BU (GNYE) BK (1) RD (2) BU (GNYE) BK (1)
  • Page 170 USER MANUAL 914NG NNEXES SAFETY SIGNS Label Position Description Do NOT bang against the On stabilizer legs stabilisers during the stabilization of the crane Do not position lower limbs On stabilizer legs under stabiliser legs during the stabilization of the crane...
  • Page 171 USER MANUAL 914NG NNEXES SAFETY SIGNS Label Position Description Read the user manual Wear helmet, gloves, industrial footwear At controls Warning: do NOT bang on the booms during opening and folding of the crane Seal sticker Do NOT use emergency controls under...
  • Page 172 USER MANUAL 914NG NNEXES LOCATION OF SAFETY SIGNS 7845285-06 03/20 subject to change without notice E.31...
  • Page 173 USER MANUAL 914NG NNEXES TIGHTENING TORQUES SCREWS - BOLTS TIGHTENING TORQUE Property class THREAD DIAMETER 10.9 12.9 (mm) M 6 x 1 16.4 M 8 x 1.25 M 10 x 1.5 M 12 x 1.75 M 14 x 2 M 16 x 2 M 18 x 2.5...
  • Page 174 USER MANUAL 914NG NNEXES SELECTION OF HYDRAULIC OIL Viscosity is one of the most important properties of hydraulic oils because it affects the hydraulic sealing and the functionality of the safety valves. Therefore the oil temperature is very important because even small changes in temperature affect viscosity: as the temperature increases, viscosity decreases.
  • Page 175 USER MANUAL 914NG NNEXES LOCKING DEVICE FOR SWIVEL BRIDGE When selling the crane, the swivel bridge is locked by means of a rotation locking device. The swivel lock consists of a device equipped with locking pins that prevent the bridge rotation with respect to the base.
  • Page 176 USER MANUAL 914NG NNEXES TROUBLESHOOTING Trouble Possible causes Troubleshooting The crane decreases in Check the pressure on the pump efficiency, the oil temperature delivery. If it’s necessary to increases, it is necessary to Pump wear replace it, go to an authorized...
  • Page 177 USER MANUAL 914NG NNEXES TROUBLESHOOTING Trouble Possible causes Troubleshooting 1) The block valve on the The stabilizer leg closes during stabilizer leg worn, no more 1-2) Go to an authorized the crane work. seal. assistance center. 2) Internal seals wear.
  • Page 178 USER MANUAL 914NG NNEXES EC DECLARATION OF CONFORMITY 7845285-06 03/20 subject to change without notice E.37...
