4.4 No Picture - Tuner
FOR ANALOG TUNING: @ All destination except JP
For LA only
Confirm ANT or Cable connection
NG
OK
A
SAFETY NOTES
Analog Tuning
For Other destination
Can it preset broadcast?
NG
Check part mounting condition
for analog control line
"IFOUT_N, IFOUT_P, IFAGC"
NG
Change NG parts
SELF DIAGNOSTIC FUNCTION
TROUBLESHOOTING
T R O U B L E S H O O T I N G
OK
Check IC1000 (SoC)
OK
Check IC1000 (SoC) &
Tuner module
SERVICE ADJUSTMENT
Notes:
- Parts for IFOUT_N line : C3011
- Parts for IFOUT_P line : C3010
- Parts for IFAGC line
: R3003 ,R3024, C3023
A
: Insert correct signal in correct ANT terminal.
