- Page 1 PX097 DMX Repeater User manual...
-
Page 2: Table Of Contents
4.3 Rules for creating DMX connections...............6 5 Connection scheme...................7 6 Dimensions....................8 7 Technical data.....................8 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-3 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description DMX Repeater is a universal repeater and splitter of the DMX signal. The device allows to create ramifications in the complex stage DMX installations and to amplify the DMX signal, that means, enables to connect next 32 receivers and to lengthen the DMX line. According to the DMX standard, the receivers in a DMX route must be connected in series. -
Page 4: Safety Conditions
Safety conditions Repeater PX097 is a device powered directly from standard 230V AC grid, what cause electric shock when safety rules are not observed. Therefore it is necessary to observe the following: 1. Repeater installation must be performed by a person holding the appropriate qualifications, according to the manual. -
Page 5: Connectors
12. Cleaning only with damp duster – PX097 has to be cut off the power supply. Connectors DMX input DMX outputs DMX signal connection Frequently, the seemingly fault operation of DMX devices is caused by their incorrect connection in the DMX network. DMX protocol strictly defines the rules for creating a control installation. -
Page 6: Terminator
4.2 Terminator According to the DMX standard, the last device on the line should have a terminator (120 Ohm resistor) connected. PUSH 120 Ohm resistor 4.3 Rules for creating DMX connections 1. To connect the device application of the microphone cable is strictly recommended (two strands in a shield). -
Page 7: Connection Scheme
Connection scheme linia DMX (max. 32 signal receivers, 300 m.) DMX Repeater PX097 PUSH PUSH DMX driver TERMINATOR... -
Page 8: Dimensions
Dimensions Be aware of additional place on the power cable Technical data type PX097 DMX I / O lines 1 / 2 DMX line connectors 3- / 5-pin XLR plug / socket isolation I / O breakdown voltage > 5000V power supply 230V AC, 50Hz power consumption... - Page 9 Podłęże, 19.09.2019 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: DMX Repeater Product code: PX097 meets the requirements of the following standards, as well as harmonised standards: PN-EN IEC 63000:2019-01...
