  • Page 1 Service Workshop Manual Passat 2011 ➤ Passat Variant 2011 ➤ Wheels and Tyres Guide Edition 03.2019 Service Department. Technical Information...
  • Page 2 In addition, the normal basic safety precautions for working on motor vehicles must, as a matter of course, be observed. All rights reserved. No reproduction without prior agreement from publisher. Copyright © 2019 Volkswagen AG, Wolfsburg D3E8045E4B7...

  • Page 3: Table Of Contents

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Contents 44 - Wheels, tyres, vehicle geometry ........
  • Page 4 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Contents...

  • Page 5: Wheels, Tyres, Vehicle Geometry

    ⇒ “1.4 Passat Alltrack - Model year 2012 to model year 2015 (sales type 365)”, page 6 General information Volkswagen vehicles are built according to the latest findings in safety engineering. To keep it that way, we recommend the use of only genuine Volkswagen spare parts. These can be recog‐...

  • Page 6: Explanations Regarding World Regions

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 ♦ The sizes of the winter tyres listed in the table are the most sensible from the handling and economic aspects. Of course, all other wheel-and-tyre combinations listed in the COC paper (EEC Certificate of Conformity) and/or in part I of the registra‐...
  • Page 7 Passat Limousine, Passat Variant, type approval model code 3C and 3c Appendix for certificate statement 8111178717 The certificate statement can be found on the Volkswagen Serv‐ iceNet under Accessories/Tyres, Wheels and Tyres, Wheels and Tyres Guide. Type approval no. for model code 3C: e1*2001/116*0307*24 to e1*2001/116*0307*36 Type approval no.
  • Page 8 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Model/ Tyre Tyre size Wheel rim Whe Snow Comments engine output el off‐ chains set in ♦ ⇒ “4 Recommen‐ 215/55 R 16 93H/V 7 J x 16 ded all-season ⇒...
  • Page 9 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Model/ Tyre Tyre size Wheel rim Whe Snow Comments engine output el off‐ chains set in Wheels and Tyres, 235/45 R 17 94V / 2 J x 17 Wheels and Tyres ⇒...
  • Page 10 ♦ Passat Alltrack, type approval model code 3C and 3c Appendix for certificate statement 8111178717 The certificate statement can be found on the Volkswagen Serv‐ iceNet under Accessories/Tyres, Wheels and Tyres, Wheels and Tyres Guide. Rep. gr.44 - Wheels, tyres, vehicle geometry...
  • Page 11 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Type approval no. for model code 3C: e1*2001/116*0307*30 to e1*2001/116*0307*36 Type approval no. for model code 3c: DE*2007/46*0547*00 Type approval no. for model code 3c: e1*2007/46*0547*00 to...

  • Page 12: Wheel Allocation

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Wheel allocation ⇒ “2.1 61/2 J x 16”, page 8 ⇒ “2.2 7 J x 16”, page 9 ⇒ “2.3 6 J x 17”, page 10 ⇒...
  • Page 13 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 7 J x 16 Note Always observe the allocation of wheels and tyres to the respec‐ tive engines, which are listed in the overview table.

  • Page 14: 61/2 J X 17 Offset

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 3AA 601 025 B - aluminium wheel “ALICANTE” Only for vehicles to maximum permissible axle load of 1,230 kg. Dimensions: 7 J x 16 Wheel offset in mm:...
  • Page 15 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Winter wheel 3C8 601 025 F - aluminium wheel“ST. MORITZ” Dimensions: / 2 J x 17 Wheel offset in mm: Wheel load in kg: / 2 J x 17 offset 42 Note Always observe the allocation of wheels and tyres to the respec‐...
  • Page 16 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 3AA 601 025 R - aluminium wheel “VALLEY” Dimensions: 7 J x 17 Wheel offset in mm: Wheel load in kg: / 2 J x 17 Note Always observe the allocation of wheels and tyres to the respec‐...
  • Page 17 Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 3AA 601 025 F - aluminium wheel “SAO PAULO” Dimensions: / 2 J x 17 Wheel offset in mm: Wheel load in kg: 3AA 601 025 G - aluminium wheel “MINNEAPOLIS”...

  • Page 18: X 18 Offset

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 3AA.601.025.T - aluminium wheel “BUENOS AIRES” Dimensions: / 2 J x 17 Wheel offset in mm: Wheel load in kg: 8 J x 18 offset 40 Note Always observe the allocation of wheels and tyres to the respec‐...

  • Page 19: Wheel Offset In Mm: Wheel Load In Kg

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Caution 8 J x 18 wheels can only be fitted under the following condi‐ tions: • The vehicle must be fitted with the sport suspension for 18″...

  • Page 20: Wheel Load In Kg: 650

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 3C0 601 025 T, 3C0 601 025 AN - aluminium wheel “CHICAGO” Dimensions: 8 J x 18 Wheel offset in mm: Wheel load in kg:...

  • Page 21: Recommended Summer Tyres

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Recommended summer tyres ⇒ “3.1 Recommended summer tyres, worldwide except North America, China, Japan, South America, Taiwan, India”, page 17 ⇒ “3.2 Recommended summer tyres, Japan”, page 18 ⇒...

  • Page 22: Recommended Summer Tyres, Japan

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Recommended summer tyres, Japan Notes regarding the recommended tyres ⇒ page 1 ⇒ “1.2 Explanations regarding world regions”, page 2 Tyre size Manufacturer Tread pattern...

  • Page 23: Recommended All-Season Tyres

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Recommended all-season tyres ⇒ “4.1 Recommended all-season tyres, worldwide except North America and China”, page 19 ⇒ “4.2 Recommended all-season tyres, worldwide except North America, China, Brazil and Taiwan”, page 19 Recommended all-season tyres, worldwide except North America and Chi‐...

  • Page 24: Recommended Winter Tyres

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Recommended winter tyres ⇒ “5.1 Recommended winter tyres, Passat Saloon, Passat Var‐ iant, worldwide except North America and China”, page 20 ⇒ “5.2 Recommended winter tyres, Passat Alltrack, worldwide except North America and China”, page 20...

  • Page 25: Recommended Temporary Spare Tyres And Wheels

    Passat 2011 ➤ , Passat Variant 2011 ➤ Wheels and Tyres Guide - Edition 03.2019 Recommended temporary spare tyres and wheels Inform your customers about the following notes and, if appropri‐ ate, refer also to the user's manual of the vehicle as the need arises.
