Summary of Contents for PXM PY512
- Page 1 PY512 Receiver 8ch Elmes Elektronik (CH8HR) User manual...
-
Page 2: Table Of Contents
7 Deleting the stored keys................9 8 Connection scheme.................10 9 Technical data..................12 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0... -
Page 3: Description
Each channel, which works as a relay, can work in one of two modes. To work with PXM devices one should set monostable (momentary) mode. The receiver has 8 NO (normally open) or NC (normally closed) outputs galvanically separated and 8 LEDs indicating output activation. The device has... -
Page 4: Safety Conditions
Safety conditions PY512 is a device powered with safe voltage 12V DC; however, during its installation and use the following rules must be strictly observed: 1. The device may only be connected to 12V DC with current-carrying capacity compatible with technical data. -
Page 5: Connectors And Control Elements
Connectors and control elements programming button output S jumpers of the S contactor antenna output mode control diodes for switching on the information diode channels channel jumpers (NO / NC) power supply relay outputs 12V DC max. 1A / 24V DC or 0.5A / 125V AC tamper connector output type OC max. -
Page 6: Adding Transmitter To Memory
Possible configurations and behaviors of the S output are presented in the table below: JP2 shorted JP2 open two pulses when Short to ground when switching on any JP1 shorted the battery is low. When channel, one when JP3 additionally open – switching off no communication with impulse only when... - Page 7 4. Depending on the type of transmitter to be entered: remote control – press the remote control button twice. For multi- • channel remote controls (e.g. 4 channels), using for example the second button will introduce the first two buttons for the next two channels of the receiver, and the third and fourth will be inactive.
-
Page 8: Modes Of Operation
Modes of operation Each channel can work independently in one of two operating modes. In the case of cooperation with PXM controllers, it is recommended to use the monostable (momentary) mode. • bi-stable – each time you press the key, the status changes to the opposite monostable (momentary) –... -
Page 9: Deleting The Stored Keys
5. After the required sustaining time has elapsed (max. 4 hours), press the button again – the information LED will light up in red, and after 2s it will start blinking green, which confirms that the procedure has been carried out correctly. NOTE! To set the channel to bi-stable mode, after step 4 press the programming button 3 times at intervals of <2s. -
Page 10: Connection Scheme
The information diode will blink red and indicate an error – it will confirm deleting the remote control from the memory. Connection scheme Connection PY512 with PX340 controller to digital inputs (sink in) – “joint plus” power supply 12V DC... - Page 11 Connection PY512 with PX340 controller to digital inputs (source in) – “joint mass” power supply 12V DC RX+ RX- TX+ TX- VCK+ SYNC REMOTE 1 2 3 4 6 7 8 10 11 12 14 15 16 0-10V OUT 0-10V IN DMX controller, e.g.
-
Page 12: Technical Data
Technical data type PY512 memory capacity 40 buttons frequency 433.92MHz coding variable code cooperation any transmitter from Elmes Elektronik mounting surface number of relays modes of operation monostable time range 0.5s – 4h relay output max. 1A / 24V DC or max. 0.5A / 125V AC tamper output OC type max.
