- Page 1 User Manual VP-1100-2 -10.1 LCD Monitor...
-
Page 2: Table Of Contents
CHAPTER OVERVIEW 1. INFORMATION ....................2 2. ELECTROMAGNETIC COMPATIBILITY STATEMENT ..........3 3. SPECIFICATION ..................... 4 4. INSTALLATION GUIDE ..................5-6 4.1 Appearance ..........................5 4.2 Install Customer Display ......................6 5. GETTING START ....................7 5.1 Unpacking ..........................7 5.2 Connection .......................... -
Page 3: Overview
Overview Thank you for purchasing the EC-TS-1100 touch screen monitor. We are committed to use up-to-date technology and provide better after-sales service continuously. Please take time to read this user manual before system installation. Note: Information in this user manual may change without prior notice 1. -
Page 4: Electromagnetic Compatibility Statement
2. Electromagnetic Compatibility Statement FCC NOTICE This device complies with Part 15 of FCC Rules. Operations are subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Specification
3. Specification VP-1100-2 -10.1 2nd Monitor Display Size 10.1 Inch Resolution 1280 × 800 Brightness/Backlight Type 400cd m2 (LED) Contrast Ratio 600 : 1 DISPLAY Response Time 25 ms Viewing Angle (Up/ Down/ Left/ Right) 80° /80° /80° /80° 1 X VGA I/O Connection 1 X 12V DC Input Housing Material... -
Page 6: Installation Guide
4. Installation Guide 4.1 Appearance 4.1.1 Font View 4.1.2 Rear View VP-1100-2 -10.1 User Manual - 5 -... -
Page 7: Install Customer Display
4.2 Install LCD Display Disassemble Display Protective Cover Connect the Monitor’s LCD Display USB I/O Port to PC’s USB Ports VP-1100-2 -10.1 User Manual - 6 -... -
Page 8: Getting Start
5 Getting Start: This chapter describes preparation before use the VP-1100-2 -10.1 LCD Monitor. The following topics are described. 5.1 Unpacking Below are the items should include in the carton box: EC-VP-1100-2 -10.1 X 1 Screw X 2 If any of the above item is missing, please contact you dealer. -
Page 9: Identify The Problem
6 Identify the Problem 6.1 Follow the procedure below to troubleshoot the problems: Identify all the symptoms in detail Verity symptoms by re-create them Follow corrective procedures in order If you replace an FRU and the symptom still exists, install the original part and do another test to identify the problem 6.2 Electricity Failure ... -
Page 10: Replace Field Replaceable Units (Frus)
7 Replace Field Replaceable Units (FRUs) 7.1 Safety and Precautions Monitor components and electronic circuit boards can be damaged by discharges of static electricity, continuously working on those monitor that are still connected to a power supply can be extremely dangerous. -
Page 11: Lcd Panel
7.3.1 The LCD panel Tear up the black lid Disconnect the cables Remove 4 screws, then take out the LCD panel VP-1100-2 -10.1 User Manual - 10 -... -
Page 12: Limited Warranty Policy
8 Limited Warranty Policy The EC-TS-1100 Touch Screen Monitor features a one-year-limited warranty from the date of purchase. If product is determined to be defective, we will repair or replace the product with refurbished or remanufactured parts or components during the warranty period. This warranty is valid only for the first consumer purchaser. - Page 13 Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com VP-1100-2 -10.1 User Manual - 12 -...
