Analog Programming - QSI Quantum 1 System Operation Manual

Analog Programming

The Electric Locomotive can be Programmed Using a Standard Power Pack.
All advanced operations are easily programmed via your standard HO power pack. After entering programming (described below), features
are selected and operated by using the direction switch
Program Option Name
Option #'s
(POP's 18 )
1
System Volume
(16, Max)
2 Load
(0, No Load)
3 Helper
(Normal)
4 "Direction" (Normal)
5-7 Reserved
8 V-Start (8.5v)
9 V-Max (12v)
10 Throttle Mode
(RTC)
11 Programming Reset
12 About
13 Horn Volume
14 Bell Volume
15 Motor Volume
16 Vents and Cooling Fan
Volume
17-19 Reserved
20 Air Brakes Volume
21-25 Reserved
26 Pump Volume
27 Air Let-off Volume
28 Short Air Let-off Volume
29 Reserved
30 Squealing Brake/Flange
Volume
31 Reserved
32 Coupler Volume
33 Reserved
17 Programming is even simpler using a Quantum Engineer Controller (see previous section on page 6).
18 POP is short for "Program Option".
19 The verbal programming responses (such as "Enter Programming" etc.) have a minimum volume setting to provide programming information even when the system volume is
turned all the way off.
20 You can set volume with the Manual Volume Control or with Programming or both. The Manual Volume Control will determine the range of volume control under Programming;
that is, if you turn the Manual Volume Control down to say, 50%, you will not be able to increase the volume above the 50% value using Programming.
21 Some lights that are not controlled by the Quantum System may remain on.
22 Bell will not be heard on models without bell feature.
Electric Loco Q1 w/Volume Pot Operation Manual, Version 2.8
17 .
19
Message when
Entering Option
20 "Volume equals X"
"Load equals X"
"Helper equals"
"Normal",
"Lead",
"Mid"
"End"
"Pusher"
"Direction equals X"
"Reserved"
"V-Start equals X"
"V-Max equals X"
"Throttle Mode
equals X""
"Warning – about to
reset"
Model number
"Volume equals X"
"Volume equals X"
"Volume equals X" Customizes Electric Traction Motor Volume. (16 levels). Max is 15.
"Volume equals X"
"Reserved"
"Volume equals X"
"Reserved"
"Volume equals X"
"Volume equals X"
"Volume equals X"
"Reserved"
"Volume equals X"
"Volume equals X"
"Volume equals X"
"Reserved"
Sets System volume (17 levels) where level 16 is maximum volume and level 0 is off.
Selects the starting and stopping inertia for both Regulated Throttle Control (RTC) and
Standard Throttle Control (STC). Level 0 (no load), Level 1-15, increasing Load with
acceleration to full speed from 15 seconds to 210 seconds in RTC and from 3 seconds
to 45 seconds in STC.
Selects Normal, Lead, Mid, End, or Pusher Helper in consists.
Normal Engine has all sounds and lights enabled.
Lead engine has all sounds enabled and Reverse Light, reverse Marker Lights,
disabled. Cab Lights and Number Board Lights are unaffected.
Mid Helper has Horn, Bell and all lights disabled
End Helper has Horn, Bell and all lights disabled except Reverse Light, Marker Lights.
Number Board Lights are unaffected.
Pusher has Reverse Light on and Reverse Marker Lights on red all the time as train
warning lights. Horn, Bell and all other lights are disabled.
Selects if features associated with the locomotive's direction are "Normal" or "Reverse".
Sets track voltage where locomotive will leave Neutral. (See Example below)
Sets track voltage where full power is applied to motor.
Selects between Standard Throttle Control (STC) and Regulated Throttle Control
(RTC).
After next Quick or Slow Operation, Bell rings
locomotive returned to factory default.
Each Quick or Slow Operation provides progressive information about Quantum
Model Number, Software Version, and software Release Date.
Customizes Horn Volume (16 levels). Max is 15.
Customizes Bell Volume (16 levels). Max is 15.
Customizes Vents and Cooling Fans Volume (16 levels). Max is 15.
Customizes Air Brake Air Release Volume (16 levels). Max is 15.
Customizes Air Pump Volume (16 levels). Max is 15.
Customizes Long Air Let-off Volume (16 levels). Max is 15.
Customizes Short Air Let-off Volume (16 levels). Max is 15.
Customizes Squealing Brake/Flange Volume (16 levels). Max is 15.
Customizes All Coupler Sound Volumes (16 levels). Max is 15.
7/21
Option Description
21 . Number Boards are unaffected.
22 followed by a hoot to indicate
8 March 2006
