Dcc Programming - QSI Quantum 1 System Operation Manual

DCC Programming

Most DCC command stations currently available will program Quantum equipped locomotives in Service Mode
Operations (Ops) Mode on the main track. In Service Mode, your locomotive (if queried) will report back CV values to your command
station. In Ops Mode, reports are verbal using the locomotive sound system.
Changing the System Volume Electronically in CV 51.0
You can change the volume either manually (as described in the
QSI CV 51.0 in DCC 55 . To change volume in Service or Ops Mode, do the following:
Set CV 49 to 0. 56
Enter the System Volume in CV 51. The System Volume can be set to any value between 0 (no sound) and 127 (100%). The default
System Volume is 127.
Note: When you change the System Volume in Ops Mode, you will immediately notice the change in volume .
Changing the Mute Volume Electronically in CV 51.1
To change the Mute Volume in Service or Ops Mode, do the following:
Set CV 49 to 1.
Enter the Mute Volume in CV 51. The System Volume can be set to any value between 0 (no sound) and 63 (100%). The default
Mute Volume is 0.
Note: When you change the Mute Volume in Ops Mode, and the locomotive is muted, you will immediately notice the change in Mute Volume.
Note: The Mute Volume level will be the smaller of either the Mute Volume setting or one half the current System Volume. In other words, the Mute
Volume will never be more than one half of the System Volume.
Enable/Disable Horn Triggered Doppler Shift (CV 51.2)
Set CV 49 to 2.
Set CV 51 to 0 to disable Horn Triggered Doppler, set to 1 to enable Horn Triggered Doppler.
Changing Individual Sound Volumes (CV 52.X
To change the volume of Individual Sounds listed in the table below do the following
Set CV 49 to the Primary Index for the individual sound from the table below.
Enter Volume level in CV 52 as follows: "0" = No sound, "1 – 15" sets volume from the lowest level at "1" to the highest at "15", with
volume levels at 2db increments.
Electric Model Specifications
See your
Setting the Ditch Light Strobe Hold Time (CV 55.110.5)
After the horn stops blowing, Ditch Lights will continue to strobe for the hold time set in CV 55.110.5.
54 If your DCC command station will not program in Service Mode, check with the command station manufacturer; some companies will give you a free upgrade. Also, see Special
Operation and Troubleshooting on page 19.
55 System Volume changes in DCC also apply to Analog and vice-versa.
56 In Ops Mode, you will hear the value spoken out when changing the value of a CV.
57 'X' refers to the value in column 1 of the table, the Primary Index number that will be entered into CV 49.
58
Setting any Individual Sound Volumes in DCC will also apply to Analog and vice-versa.
Electric Loco Q1 w/Volume Pot Operation Manual, Version 2.8
)
57
Primary Index entered into CV 49
0
8
10
16
19
21
22
24
34
37
sheet for Individual Sound Volume default settings.
Special Operation and Troubleshooting
58 :
Individual Sound
Horn
Bell
Electric Traction Motor
Air Pump
Vents and Cooling Fans
Long Air Let-off
Short Air Let-off
Squealing Brakes/Flanges
Coupler Sounds
Air Brake Sounds
15/21
54 on a programming track or
section) or electronically using
8 March 2006
