QSI Quantum 1 System Operation Manual page 21

Sounds & Features Common
to Analog & DCC
Horn or hoot
Bell with shut down and turn on
Effects (if so equipped)
Electric Traction Motor
Automatic Cooling Fans
Doppler Shift
Brake or Flange Squeal
Neutral Sounds
Long Air Release
Short Air Release
Air Pumps
Sound of Power™
Neutral State (Idle)
Directional Lighting
Bright/Dim Headlight
Reverse Light (optional)
Ditch Lights (optional)
Mars Light (optional)
Marker Lights (optional)
Number Board Lights (optional)
Cab Lights (optional)
Manual Volume Control
with Potentiometer
Reset to Factory Default
with Jumper
*Settings in parentheses indicate factory default. For factory defaults not listed here, see the Electric Model Specification Sheet included with your
locomotive.
**QARC Technology allows commands to be sent to locomotives under Analog control to operate different Quantum features. With QARC technology, you
72
can operate features that are otherwise available only in DCC plus features that are not yet available in DCC. The QARC controllers are inexpensive
accessories that employ the QARC system. They can be added to your existing power pack to operate additional features on your Quantum
locomotive.
QSIndustries, Inc. Software License Agreement
1. Grant of License: QSIndustries, Inc. grants you, the owner, the right to use the software that is included with your Quantum system only with the locomotive that you purchased.
2. Copyright: The software is owned by QSIndustries, Inc. and is protected by United States copyright laws and international treaty provisions. Therefore, neither you nor anyone else may copy the software.
Proprietary Rights and Obligations
The structure and organization of the Software/Firmware are the valuable properties of QSIndustries, Inc. You will not make or have made, or permit to be made, any copies of the Hardware, Software/Firmware, code, or any portions thereof.
You are not to modify, adapt, translate, reverse engineer, de-compile, disassemble or create derivative works based on the Hardware or Software/Firmware. Trademarks shall be used in accordance with accepted trademark practice,
including identification of trademark owner's name. The Quantum Hardware, Software and Firmware are covered by U.S. Patent No. 4,914,431; 5,184,048; 5,267,318; 5,394,068; 5,448,142; 5,633,985; 5,832,431; 5,896,017; 5,940,005; and
US and Foreign patents pending.
No Other Rights
QSIndustries, Inc. retains ownership of the Quantum Hardware design and operating Software/Firmware code. Except as stated above, this agreement does not grant you any rights to intellectual property rights to the Quantum Software,
Firmware or Hardware. The use of any trademarks as herein authorized does not give you any rights of ownership in that trademark.
© 2004 All rights reserved. Printed in China. Information in this publication supersedes that in all previous published material. The contents and the product it describes are subject to change without notice. QSI is a registered trademark of
QSIndustries, Inc. Quantum, Quantum System, Sound-of-Power, Scale Sound, Regulated Throttle Control, QARC, are trademarks of QSIndustries, Inc. MRC is a trademark of Model Rectifier Corporation. All other trademarks are the
property of their respective holders. QSI makes no representations or warranties with respect to this publication. In no event shall QSIndustries, Inc., be liable for any damages, direct or incidental, arising out of or related to the use of this
publication. Universal Q1R Electric Manual P F(14) G(4) J(2).doc. 3/06
QSIndustries, Inc.
Beaverton, OR
72 Quantum Analog Remote Control (QARC) Technology
73 Not all Quantum equipped locomotives contain QARC Technology.
Electric Loco Q1 w/Volume Pot Operation Manual, Version 2.8
Analog Features*
System Volume Programming
Individual Sound Volume Control
Regulated Throttle Control and
Locomotive Load (Inertia)
Helper Type: (Normal) Normal
loco, Lead Loco, Mid Helper,
End Helper. Pusher.
Direction: (Normal)
Normal/Reversed
Power Pack Programming
V-Max (12v)
V-Start (8.5v)
QSI QARC™ Operation**
(with QSI QARC Controllers™)
Air Brakes
Flanges
Dynamic Brakes
Locomotive ID's.
Consist ID's.
Coupler Sounds
Electric Loco Extended
Shut Down
Extended Start Up
Explicit Lighting Control
Controllable Flange Squeal
Load on/off toggle
Fan on/off toggle
Verbal Status Reports
Grade Crossing Horn
Signal
Audio Mute
System Volume Control
and Additional Features
DCC Features*
F0 or FL light control
F1-F12 Function Keys
14/28/126 speed steps (28)
Coupler Sounds
Air Brakes
Dynamic Brakes
Programming Modes Supported:
Address Mode, Register Mode, Service Mode, Direct
Mode, Ops Mode Long Form & Ops Mode Short Form
NMRA CV's supported:
1 Primary Address
2 V-Start
5 V-High
8 QSI MFG's ID Number (113)
3-4,7,17-25,29,33-46,66-95
QSI CV's supported:
49 Primary Index
50 Secondary Index
51 Sound Control
51.0 System Volume
51.1 Mute Volume
51.2 Doppler (Enabled)
52 Individual Sound Volume Control
53 Function Output Mapping
56 QSI Configuration
n
56.128. Reset
56.253 Version Build Information
62 Auto CV Verbal Feedback (enabled)
64 CV Inquiry Verbal Readout
21/21
equipped
73
8 March 2006
