5. INSTRUMENT LAYOUT

1 2
8 9 10
1.C1 terminal (Black test lead
connection)
2. P1 terminal (Green test lead
connection)
3. P2 terminal (Yellow test lead
connection)
4. C2 terminal (Red test lead
connection)
5. LCM display
6. Rc LED
7. Rp LED
©Copyright Abacanto Digital SA.
3 4
11 12
8.2 Wires type button
9. 3 Wires type button
10.4 Wires type button
11.ACV button
12. Power button
13. TEST/STOP button
