Aquila AT01-100C Manual

Hide thumbs Also See for AT01-100C:
Table of Contents

Advertisement

Quick Links

Download this manual
POH / AFM
Section 0
AQUILA AT01-100C
INTRODUCTION
With the AQUILA AT01 you have acquired a very efficient training and utility aircraft, which is
easy to operate and exhibits excellent handling qualities.
To ensure reliable operation and trouble free flight, we recommend that you read this Pilot's
Operating Handbook thoroughly and adhere to the operating instructions and recommendations
given herein.
CAUTION
All limitations, procedures and performance data contained in this handbook are EASA/FAA
approved and mandatory. Failing to follow the procedures and limits set forth in this handbook
can lead to a loss of liability by the manufacturer.
THE HANDBOOK
The handbook is presented in loose-leaf form to ease the substitution of revisions and is sized
in A5-format for convenient storage in the aircraft.
Tab dividers throughout the handbook allow quick reference to each section. A Table of
Contents is located at the beginning of each section to aid the location of specific data within
that section.
All rights reserved.
Reproduction or disclosure to third parties of this document or any part thereof is not permitted,
except with the prior and express written permission of AQUILA Aviation International GmbH.
Copyright © by
Aviation International GmbH
Schönhagen, Germany
Document Nr.:
Issue:
Supersedes Issue:
Date:
Page:
0 – 1
FM-AT01-1010-103
A.08
A.07 (18.06.2019)
25.05.2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT01-100C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aquila AT01-100C

Summary of Contents for Aquila AT01-100C

  • Page 1 AQUILA AT01-100C INTRODUCTION With the AQUILA AT01 you have acquired a very efficient training and utility aircraft, which is easy to operate and exhibits excellent handling qualities. To ensure reliable operation and trouble free flight, we recommend that you read this Pilot's Operating Handbook thoroughly and adhere to the operating instructions and recommendations given herein.

  • Page 2: Table Of Contents

    POH / AFM Section 0 AQUILA AT01-100C TABLE OF CONTENTS SECTION GENERAL OPERATING LIMITATIONS (approved section) EMERGENCY PROCEDURES (approved section) NORMAL PROCEDURES (approved section) PERFORMANCE (partly approved section) WEIGHT AND BALANCE AIRCRAFT DESCRIPTION HANDLING AND MAINTENANCE SUPPLEMENTS Document Nr.: Issue:...
  • Page 3 POH / AFM Section 0 AQUILA AT01-100C LIST OF EFFECTIVE PAGES Note: If the applicable POH / AFM supplement for Night VFR operation is implemented, the list of resulting effective chapters can be found in chapter 9. Section Issue Approved...
  • Page 4 Generally only complete sections of the POH will be exchanged and not individual pages. The operation of the AQUILA AT01 is only permitted with a current and up to date POH carried on board. Please refer to the following web page whenever the revision status of your POH is in question.
  • Page 5 POH / AFM Section 0 AQUILA AT01-100C The technical content of this document is approved under the authority of the DOA ref. EASA.21J.025. Document Nr.: Issue: Supersedes Issue: Date: Page: 0 – 5 FM-AT01-1010-103 A.08 A.07 (18.06.2019) 25.05.2020...
  • Page 6 AVAILABILITY OF TECHNICAL PUBLICATIONS To guarantee safe operation and correct maintenance of the AQUILA AT01-100 aircraft, all manuals and technical publications must be kept in the current effective status. All manuals and technical publications relating to the aircraft AQUILA AT01-100 are available...

  • Page 7: General

    1.4.1 Overall Dimensions 1.4.2 Wings 1.4.3 Horizontal Stabilizer / Elevator 1.4.4 Fuselage and Vertical Stabilizer / Rudder 1.4.5 Landing Gear AQUILA AT01-100 – THREE VIEW DRAWING ENGINE PROPELLER FUEL OIL AND COOLANT 1.9.1 Engine Oil 1.9.2 Engine Coolant 1.10 WEIGHTS 1.11...
  • Page 8 AIRCRAFT TYPE CERTIFICATION The aircraft AQUILA AT01 is type-certified in accordance with the certification specifications of the Joint Aviation Requirements for Very Light Aeroplanes (JAR-VLA, including the revision VLA/92/1) by the Luftfahrt-Bundesamt, the National Aviation Authority of Germany.
  • Page 9 Section 1 POH / AFM GENERAL AQUILA AT01-100C WARNING, CAUTIONS AND NOTES Throughout the text, special text boxes marked WARNING, CAUTION and NOTE are used. These terms are defined as follows: WARNING Procedures, practices, etc. which may result in personal injury or loss of life if not strictly adhered to.
  • Page 10 Section 1 POH / AFM GENERAL AQUILA AT01-100C PRINCIPLE AIRCRAFT DIMENSIONS 1.4.1 Overall Dimensions Wing Span: 33.79 ft (10.3 m) Length: 24.28 ft (7.4 m) Height: 7.87 ft (2.4 m) 1.4.2 Wings Airfoil: HQ-XX mod. Area: 113.02 sq. ft (10.5 m²) Aspect Ratio: 10.1...
  • Page 11 Section 1 POH / AFM GENERAL AQUILA AT01-100C AQUILA AT01-100 – THREE VIEW DRAWING 2,4 m / 7,87 ft 7,4 m / 24,28 ft 10,3 m / 33,79 ft Document Nr.: Issue: Supersedes Issue: Date: Page: FM-AT01-1010-103 A.08 A.06 (01.06.2018) 25.05.2020...
  • Page 12 Section 1 POH / AFM GENERAL AQUILA AT01-100C ENGINE The ROTAX 912 S3 is a 4-cylinder 4-stroke engine with air cooled cylinders and liquid cooled ® cylinder heads. The Propeller is driven via an internal reduction gearbox with an integrated overload clutch and a hydraulic constant speed propeller governor.
  • Page 13 Section 1 POH / AFM GENERAL AQUILA AT01-100C ENGINE OIL AND COOLANT 1.9.1 Engine Oil Use only oil with an API classification of “SG” or higher. Heavy duty 4-stroke motor oils tend to meet these requirements. For more information regarding engine oil selection, please refer to the Operator’s Manual for all versions of the 912 engine series, section 10.2.3, and to the...
  • Page 14 Section 1 POH / AFM GENERAL AQUILA AT01-100C 1.9.2 Engine Coolant A conventional, ethylene glycol and water based coolant is used. Please refer to the Operator’s Manual for the 912 engine series, section 10.2.3, and to the current issue of the ROTAX Service Instructions SI-912-016 when choosing an engine ®...
  • Page 15 Section 1 POH / AFM GENERAL AQUILA AT01-100C 1.11 TERMINOLOGY AND ABBREVIATIONS 1.11.1 Speeds IAS: (Indicated Airspeed) - the speed shown on the airspeed indicator KIAS: IAS expressed in knots CAS: (Calibrated Airspeed) - the indicated airspeed, corrected for position and instrument error.
  • Page 16 Section 1 POH / AFM GENERAL AQUILA AT01-100C 1.11.2 Weight and Balance Reference Datum: imaginary vertical plane from which horizontal distances are measured for balance purposes Reference Line: fixed horizontal reference line Lever Arm: The horizontal distance from the reference datum to the center of gravity (C.G.) of an item...
  • Page 17 Section 1 POH / AFM GENERAL AQUILA AT01-100C 1.11.4 Engine and Performance TOP: (Take-off Power) - maximum power permissible for takeoff MCP: (Max. Continuous Power) - maximum power permitted for continuous operation 1.11.5 Various Serial No. (S/N): Serial Number of the Aircraft Part No.
  • Page 18 Section 1 POH / AFM GENERAL AQUILA AT01-100C 1.12 CONVERSION FACTORS 1.12.1 Length 1 ft 0.304 1 in 25.4 1.12.2 Speed 1 kt 1.852 km/h 1 mph 1.609 km/h 1.12.3 Pressure 1 hPa N/m² 1 mbar 1 in. Hg 33.865 1 psi 68.97...
  • Page 19 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C SECTION 2 LIMITATIONS Page INTRODUCTION AIRSPEED LIMITATIONS AIRSPEED INDICATOR MARKINGS POWER PLANT LIMITATIONS 2.4.1 Engine 2.4.2 Propeller MARKINGS ON THE GLASS PANEL ENGINE MONITOR MVP-50P-AQ WEIGHT LIMITS CENTER OF GRAVITY LIMITS MANEUVER LIMITS 2.10...
  • Page 20 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C INTRODUCTION This section includes all operating limitations, instrument markings and basic placards necessary for the safe operation of the aircraft, its engine, standard systems and standard equipment. WARNING The aircraft must be operated in compliance with the operating limitations.
  • Page 21 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C AIRSPEED INDICATOR MARKINGS The airspeeds given below are expressed in Indicated Airspeeds (IAS): Marking (IAS) [kts] Remarks White arc 39-90 Full flap operating range Green arc 49-130 Normal operating range Operations in this region must be conducted with...
  • Page 22 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C Oil Pressure Minimum: 11.6 psi (0.8 bar) below 590 RPM 29 –72.5 psi (2.0-5.0 bar) above 590 RPM Normal: Maximum during a cold start: 101.5 psi (7.0 bar) (only for a short time)
  • Page 23 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C 2.5 MARKINGS ON THE ENGINE MONITOR MVP-50P-AQ The following table shows the instrument markings shown on the MVP-50P-AQ and their meaning. Green Arc Red Line Yellow Arc Red Line (normal MVP-50P-AQ (minimum)
  • Page 24 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C WEIGHT LIMITS Maximum Takeoff Weight 1653 lb (750 kg) Maximum Landing Weight 1653 lb (750 kg) Max. Weight in Baggage Compartment 88.2 lb ( 40 kg) WARNING Exceeding the weight limits can overload the aircraft and is prohibited. In addition, aircraft performance and handling characteristics may be detrimentally affected.
  • Page 25 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C FLIGHT LOAD FACTORS The following flight load factors may not be exceeded while performing any approved maneuvers. Flight Load Factor at V at V With Flaps Extended Positive -2.0 -2.0 Negative WARNING Exceeding the flight load factors limits may result in damage to the aircraft structure.
  • Page 26 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C 2.11 KINDS OF OPERATION LIMITS / MINIMUM EQUIPMENT Certified for: visual flights by Day Table 1 For VFR by Day*  Garmin G-500 / G500 TXi Flight and navigational instruments  Magnetic Compass ...
  • Page 27 2.13 TEMPERATURE LIMITATIONS Parts of the aircraft structure that are exposed to direct vertical sunlight must be painted WHITE. 2.14 OPERATING ALTITUDE The Aquila AT01-100 has a maximum operating altitude of 14,500 ft. Document Nr.: Issue: Supersedes Issue: Date:...
  • Page 28 Section 2 POH / AFM LIMITATIONS AQUILA AT01-100C 2.15 PLACARDS 1) On the instrument panel, in the lower middle section of the panel: This aircraft is certified according to JAR-VLA for day VFR operations under non-icing conditions. All aerobatic maneuvers,...
  • Page 29 POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES SECTION 3 EMERGENCY PROCEDURES Page INTRODUCTION 3.1.1 Resetting circuit-breakers AIRSPEEDS FOR EMERGENCY OPERATION ENGINE FAILURES – CHECKLISTS 3.3.1 Engine Failure During the Take-off Run 3.3.2 Engine Failure Immediately After Take-off 3.3.3...
  • Page 30 POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.12 TRIM CONTROL SYSTEM FAILURES 3-14 3.12.1 Trim System Inoperative 3-14 3.12.2 Trim Actuator Runaway 3-15 3.13 AVIONICS MALFUNCTIONS 3-15 3.13.1 Complete Avionics Failure 3-15 3.13.2 Receive Mode Failure of COM-Equipment 3-15 3.13.3...

  • Page 31: Emergency Procedures (Approved Section)

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES INTRODUCTION This section provides checklists with the recommended procedures for coping with various emergency situations. Emergencies caused by aircraft or engine malfunctions are extremely rare if all pre-flight inspections and required maintenance is properly conducted.

  • Page 32: Engine Failures - Checklists

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES ENGINE FAILURES – CHECKLISTS 3.3.1 Engine Failure before Take-off Throttle IDLE Brakes APPLY as required 3.3.2 Engine Failure Immediately After Take-off and during Climb Airspeed (IAS) 70 KIAS WARNING Depending on the own speed and altitude, the wind condition and the remaining engine power a forced landing must be initiated under consideration of the local conditions.

  • Page 33: In-Flight Engine Failure

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.3.3 In-flight Engine Failures ENGINE ROUGHNESS 1. Carburetor heat PULL (ON) 2. Fuel Pump switch 3. Ignition switch SWITCH through the positions L-BOTH, then R-BOTH 4. Throttle Maintain setting If roughness continues: 5.
  • Page 34 POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES LOSS OF FUEL PRESSURE 1. Fuel Pump switch 2. Fuel selector valve SWITCH to fullest or other tank 3. Fuel Pump switch OFF, when fuel pressure in green range NOTE After switching fuel tanks, it may take up to 8 seconds for full fuel pressure to be built up.

  • Page 35: Forced Landings

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES Fuel selector valve SWITCH to fullest or other tank Propeller control lever START position Fuel Pump switch Ignition switch BOTH Throttle hot engine OPENED 2 cm (0,8 inch) cold engine IDLE...

  • Page 36: Emergency Landing

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES Abeam the touchdown point: Throttle AS REQUIRED Propeller Control Lever START position Carburetor Heat PUSHED (OFF Fuel Pump switch Flaps Airspeed 60 KIAS Touch down with lowest possible airspeed. After touchdown:...

  • Page 37: Engine Fire In Flight

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES ALT1 / BAT switch Ignition switch Aircraft EVACUATE immediately once engine stops 3.5.2 Engine Fire In-flight Throttle WIDE OPEN Fuel selector valve Cabin heat PUSHED (OFF) Canopy slide-window OPEN Perform a precautionary landing without engine power as described in Section 3.4.2 3.5.3 Electrical Fire with Smoke on the Ground...

  • Page 38: Inadvertent Flight Into Icing Conditions

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES WARNING Turning the ALT1 / BAT switch OFF turns off all electrical and electronic equipment, including the flaps INADVERTENT FLIGHT IN ICING CONDITIONS WARNING Intentional flight in icing conditions is prohibited. During unintentional flight in icing conditions...

  • Page 39: Power-Off Glide

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES POWER-OFF GLIDE Achievable gliding distances vary depending on altitude and current wind conditions. This is very important when choosing a landing site or reaching a near-by airfield. To achieve maximum gliding distance:...

  • Page 40: Electrical System Malfunctions

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.10 ELECTRICAL SYSTEM MALFUNCTIONS 3.10.1 Complete Electrical System Failure 1. ALT1 / BAT switch CHECK if ON 2. BAT1 circuit breaker (see 3.1.1) RESET if tripped 3. ALT1 circuit breaker (see 3.1.1)

  • Page 41: Low Voltage Indication

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.10.3 Low Voltage Indication A) On the ground (voltmeter values YELLOW or RED) Engine speed Increase RPM until value turns GREEN (RPM should be below 1350) All non-essential equipment OFF, until value turns GREEN.

  • Page 42: Flap Control System Malfunctions

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.11 FLAP CONTROL SYSTEM MALFUNCTIONS FLAP POSITION INDICATOR or FLAP ACTUATOR MALFUNCTION Flap Actuator circuit breaker (see 3.1.1) RESET, if tripped Flap Control circuit breaker (see 3.1.1) RESET, if tripped Flap position...

  • Page 43: Trim Actuator Runaway

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.12.2 Trim Actuator Runaway Control Column HOLD in position Trim Actuator circuit breaker PULL Trim switch CHECK if pressed or jammed If the problem is obvious, and can be solved: Trim Actuator circuit breaker (see 3.1.1) RESET NOTE Approx.

  • Page 44: Primary Flight Display Failure

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.13.4 Primary Flight Display Failure G500 and G500 TXi: 1. PFD circuit breaker (see 3.1.1) RESET, if tripped G500 only: 2. AHRS circuit breaker (see 3.1.1) RESET, if tripped 3. ADC circuit breaker (see 3.1.1)

  • Page 45: Ahrs Failure

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.13.7 AHRS Failure 1. AHRS circuit breaker (G500 only) RESET, if tripped NOTE In the event of an AHRS Failure, the horizon is no longer displayed on the PFD. Additionally a red “X”...

  • Page 46: Starter Malfunction

    POH / AFM SECTION 3 AQUILA AT01-100C EMERGENCY PROCEDURES 3.14 STARTER MALFUNCTION During engine start on ground, power transmission from the starter to the engine is defect (a continuing and excessive howling tone is audible). Throttle IDLE Ignition switch Repair damage before conducting planned flight.
  • Page 47 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C SECTION 4 NORMAL PROCEDURES Page INTRODUCTION AIRSPEEDS FOR NORMAL OPERATION DAILY INSPECTION PRE-FLIGHT INSPECTION CHECKLISTS FOR NORMAL PROCEDURES 4-11 4.5.1 Before Engine Start-up 4-11 4.5.2 Engine Start-up 4-12 4.5.3 Before Taxiing 4-13 4.5.4...

  • Page 48: Normal Procedures

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C INTRODUCTION This section provides normal operating procedures and checklists for the aircraft as well as recommended airspeeds. Additional information is provided in the current issues of the Operators Manual for ROTAX...

  • Page 49: Airspeeds For Normal Operation

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C AIRSPEEDS FOR NORMAL OPERATION The following airspeeds are based on the maximum take-off weight of 1653 lbs (750 kg). They may also be used for any lower operational weight. TAKE-OFF Airspeed (IAS)

  • Page 50: Daily Inspection

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C DAILY INSPECTION CAUTION The daily inspection is begun by checking all 3 fuel sumps for water and contamination. This must be done before the aircraft is moved. Otherwise the fuel in the sump may mix.
  • Page 51 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C B) EXTERIOR CHECK, Visual Inspection CAUTION In this manual, visual inspection means the following: Inspect for mechanical damage, dirt, cracks, delamination, excessive play, looseness, leaks, incorrect attachment, foreign objects and general condition.
  • Page 52 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C Left main landing gear a) Landing gear strut Visual inspection b) Wheel fairing Visual inspection (refer to 7.11.4) c) Tire pressure and slip marking CHECK d) Tire, wheel, brake Visual inspection...
  • Page 53 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C Nose section, cowling WARNING Before cranking the propeller: Ignition and ALT1/BAT switch: OFF Set the parking brake. WARNING RISK OF BURNS ! Only check the oil and coolant levels when the engine is cool.
  • Page 54 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C g) Propeller blades CHECK for cracks and other damage Nose landing gear a) Nose gear strut Visual inspection b) Wheel fairing Visual inspection CAUTION Both parts of the 2 piece nose wheel fairing must always be installed on the aircraft...

  • Page 55: Pre-Flight Inspection

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C PRE-FLIGHT INSPECTION (Walk Around) Daily Inspection Confirm has been carried out. Tow bar Remove Fuel level CHECK with dipstick and verify with the indicated fuel level on the fuel gauge WARNING...
  • Page 56 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 6. Tie-down straps remove 7. Baggage door CHECK if closed and locked 8. Pitot cover remove 9. Control locks remove 10. Seating position adjust and lock, check that nose wheel steering and brakes can be operated 11.

  • Page 57: Checklists For Normal Procedures

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C CHECKLISTS FOR NORMAL PROCEDURES 4.5.1 Before Engine Start-up Daily and Pre-Flight Inspection COMPLETED Passenger Briefing COMPLETED Seats ADJUSTED Seat Belts and Harnesses FASTENED Canopy CLOSED and LOCKED Check locking mechanism Parking Brake...

  • Page 58: Engine Start-Up

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.2 Engine Start-up Fuel Pump switch Fuel Pressure within GREEN range Throttle - Cold Engine IDLE - Hot Engine 0.8 in. (2 cm) OPENED Choke - Cold Engine PULL, and keep pulled...

  • Page 59: Before Taxiing

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.3 Before Taxiing CAUTION Warm up the engine for approx. 2 min at 800 RPM and then at 1000 RPM until the Oil Temperature reaches a temperature of at least 122°F (50°C)

  • Page 60: Before Take-Off (At The Taxi Holding Position)

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.5 Before Take-off (at the Taxi Holding Position) Brakes APPLY Parking Brake Compass and gyro Instruments CHECK setting Fuel Selector Valve LEFT or RIGHT, switch to the fuller tank Fuel Pressure...

  • Page 61: Take-Off

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.6 Take-off (up to 50 ft) Throttle WIDE OPEN Tachometer CHECK if within 2300 - 2385 RPM Elevator, control column NEUTRAL during initial ground roll Rudder pedals Maintain direction Rotate speed...

  • Page 62: Cruise

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.8 Cruise Throttle AS REQUIRED (Ref. to Section 5, Page 5-11) Propeller control lever SET 1650 to 2260 RPM CAUTION Continuous operation with throttle wide open and propeller revolution below 2140 RPM should...

  • Page 63: Landing

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.10 Landing Lap belt CHECK SECURE Fuel Pump switch Carburetor heat PULL (ON) Throttle AS REQUIRED Airspeed 90 KIAS Flaps switch T/O or LDG Trim switch AS REQUIRED Flaps switch Approach speed...

  • Page 64: Engine Shutdown

    Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.13 Engine Shutdown Throttle IDLE Parking Brake Flaps switch CHECK (frequency 121.5 MHz) Avionics switch Ignition Switch Electrical equipment ALT1 / BAT switch NOTE The GARMIN G500 / G500 TXi and the MVP-50P-AQ are turned off with the ALT1/BAT switch.
  • Page 65 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C 4.5.15 Flight in Heavy Rain and/or with Wing Contamination CAUTION When flying with wet and/or contaminated wings and control surfaces, performance and handling qualities may be reduced. This applies in particular to take-off distance, climb performance, cruising speed and stall characteristics.
  • Page 66 Section 4 POH / AFM NORMAL PROCEDURES AQUILA AT01-100C [intentionally left blank] Document Nr.: Issue: Supersedes Issue: Date: Page: FM-AT01-1010-103 A.08 A.06 (01.06.2018) 25.05.2020 4 - 20...

  • Page 67: Weight And Balance

    Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C SECTION 6 WEIGHT AND BALANCE / EQUIPMENT LIST Page INTRODUCTION AIRCRAFT WEIGHING WEIGHT AND BALANCE DATA 6.3.1 Weight and Balance Record DETERMINING WEIGHT AND BALANCE FOR FLIGHT 6.4.1 Load moment determination (loading graph) 6.4.2...
  • Page 68 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C INTRODUCTION Before delivery, the manufacturer determines the basic empty weight and moment as well as the empty C.G. location for each aircraft. This data is documented in the Weight and Balance Record in section 6.3.1 of this section.
  • Page 69 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C AIRCRAFT WEIGHING Reference Datum (BE): Leading edge of wing root rib Horizontal reference line: Place a wedge (800 : 77) 63 in (1600 mm) ahead of the leading edge of the horizontal stabilizer. Place a level on the wedge and level the aircraft.
  • Page 70 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C Aircraft Weighing: Example in [lb, in] Position Weight [lb] Lever [in] Moment [in*lb] Nose Wheel = 234 = - 33 = - 7722 Left Main Wheel = 441 = + 31...
  • Page 71 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C Replace with current Aircraft Weighing Report Document Nr.: Issue: Supersedes Issue: Date: Page: FM-AT01-1010-103 A.08 A.02 (15.10.2013) 25.05.2020 6 - 5...
  • Page 72 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.3.1 Weight and Balance Record Document Nr.: Issue: Supersedes Issue: Date: Page: FM-AT01-1010-103 A.08 A.02 (15.10.2013) 25.05.2020 6 - 6...
  • Page 73 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C DETERMINING WEIGHT AND BALANCE FOR FLIGHT In order to operate the aircraft within the approved weight and C.G. limits, the take-off weight and the flight C.G. position must be determined, taking into consideration the loading for the planned flight.
  • Page 74 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.4.1 Load moment determination (loading graph) Loading Graph Seat most Seat most forward rearward Kraftstoff fuel baggage Gepäck 940 1010 Moment of loading [kg m] ([lb ft]) NOTE When determining the C.G. position, the fact that the seat is adjustable must be taken in to consideration.
  • Page 75 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.4.2 Weight and Moment Determination Registration No.: Aquila AT01 Lever from leading Example Calculating edge of wing root Loading Weight Moment Weight Moment rib (BE) Condition [lb] [in lb] [lb]...
  • Page 76 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.4.3 Approved Center of Gravity Range and Moment Limits xS =16.8 in 17.1 17.9 18.7 19.5 20.3 xS = 20.6 in xS = 427mm xS = 523 mm 1675 1650...
  • Page 77 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.4.4 Estimating Center of Gravity Position using MVP-50P-AQ The "Weight and Balance" function of the MVP-50P-AQ offers a comfortable and simple way of estimating the current C.G. position. The weights of the pilot, passenger, baggage and fuel are entered into the "Weight and Balance"...
  • Page 78 Service Bulletin. When in doubt, the type certificate holder or the production organization of AQUILA Aviation should be contacted. After every change to the aircraft that could cause the empty weight or moment to change (for example, the installation or removal of equipment), the empty weight and C.G.
  • Page 79 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C 6.5.1 Current Equipment List of the Aircraft AQUILA AT01-100 Registration: S/N: AT01-100C- Installation Designation / Description Manufacturer Model / P/N Location **) Mark where applicable Describe installation location or enter lever arm from reference datum in [in] (keep algebraic sign of lever arm in mind) Document Nr.:...
  • Page 80 Section 6 POH / AFM WEIGHT AND BALANCE AQUILA AT01-100C AQUILA AT01-100 Registration: S/N: AT01-100C- Installation Designation / Description Manufacturer Model / P/N Location **) Mark where applicable Describe installation location or enter lever arm from reference datum in [in] (keep algebraic sign of lever arm in mind) Document Nr.:...
  • Page 81 Section 7 POH / AFM AIRCRAFT DESCRIPTION AQUILA AT01-100C SECTION 7 DESCRIPTION OF THE AIRCRAFT AND ITS SYSTEMS Page INTRODUCTION 7.1.1 Garmin G-500 / G500 TXi System (Primary Flight Display) 7.1.2 Glass Panel Engine Monitor MVP-50P-AQ AIRFRAME FUSELAGE WING EMPENNAGE FLIGHT CONTROLS 7.6.1...
  • Page 82 Section 7 POH / AFM AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.12 POWER PLANT 7-13 7.12.1 Engine 7-13 7.12.2 Propeller 7-13 7.12.3 Throttle and Propeller Control 7-14 7.12.4 Choke 7-15 7.12.5 Carburetor Heat 7-15 7.13 FUEL SYSTEM 7-16 7.13.1 Overview 7-16 7.13.2...

  • Page 83: Introduction

    Section 7 POH / AFM AIRCRAFT DESCRIPTION AQUILA AT01-100C INTRODUCTION Section 7 of the Pilot's Operating Handbook contains a description of the entire aircraft and its systems, including the integration of the GARMIN G500 / G500 TXi system and the Glass Panel Engine Monitor MVP-50P-AQ as well as information related to their use.

  • Page 84: Aircraft Description

    POH / AFM AIRCRAFT DESCRIPTION AQUILA AT01-100C Also the G500 ADC and its OAT probe are protected by a dedicated push-pull circuit breaker. The circuit breaker is located on the right side of the instrument panel and is marked with ADC.

  • Page 85: Airframe

    The Aquila AT01-100 is a modern single engine two seater in a side-by-side configuration. Due to its high useful load, roomy cockpit, large baggage compartment, good cruise performance and light yet incredibly sturdy airframe, the Aquila is not only a great aircraft for longer tours but also an ideal training platform.

  • Page 86: Empennage

    The horizontal stabilizer assembly is bonded directly to the fuselage and cannot be removed. FLIGHT CONTROLS The flight controls of the Aquila AT01-100 are of conventional design using a control column and non-adjustable rudder pedals. The elevator and ailerons are controlled via push-pull-rods, the rudder via cables.

  • Page 87: Rudder

    Section 7 POH / AFM AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.6.3 Rudder The rudder is controlled by the rudder pedals by way of cables running in special guides. The control surface travel is limited by stops at the lower rudder attachment fitting.

  • Page 88: Instrument Panel

    Pilot’s Operating Handbook Abschnitt 7 AQUILA AT01-100C AIRCRAFT DESCRIPTION NOTE: INSTRUMENT PANEL AT01-100C (sample) actual installation differ depending certified changes complementary equipment. 12 13 For minimum instrument requirements, refer to Section 2.12 of this manual Description Description Description Description Description...

  • Page 89: Overview Control Panel

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.7.1 Overview Control Panel Controls and displays located on the control panel which is located below the midsection of the instrument panel, are placed so as to be easily viewed and operated from both seats.

  • Page 90: Seats, Seatbelts And Harnesses

    7.10 CANOPY The large canopy of the AQUILA AT01-100 offers an excellent all around view and allows unrestricted access to the cabin. Small sliding windows on both sides of the canopy serve as emergency view windows and can be used for additional cabin ventilation.

  • Page 91: Landing Gear

    Because of the robust landing gear and the 5.00 x 5 wheels on the nose and main wheels the AQUILA AT01-100 can be easily operated from a grass surface. The aircraft can be operated with full size wheel pants or, for soft field operation, mud guards.
  • Page 92 It is important that no dirt or snow accumulate underneath the wheel pants. For this reason the Aquila AT01-100 can be operated with either full wheel pants (high-speed), with mud guards (soft-field), or without any wheel fairings. The aircraft can also be flown with a combination of wheel fairings, as long as the left and right main wheels have the same fairing.

  • Page 93: Power Plant

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.12 POWER PLANT 7.12.1 Engine The ROTAX 912S is a 4 cylinder, 4 stroke horizontally opposed engine with liquid- cooled cylinder heads and air-cooled cylinder barrels. It has brushless magnetos, 2 carburetors, a mechanical fuel pump, a reduction drive, an integrated alternator (ALT2), an alternator (ALT1) and an attachment for a hydraulic constant speed propeller.

  • Page 94: Date: Page

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.12.3 Throttle and Propeller Control The black throttle lever and the blue propeller control lever are located on the central control panel. The throttle controls the manifold pressure (MP): Throttle forward:...

  • Page 95: Choke

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.12.4 Choke The choke control knob is located on the control panel to the right of the carburetor heat and cabin heat controls. The choke may only be used for a short time when starting the engine in cold conditions.

  • Page 96: Fuel System

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.13 FUEL SYSTEM 7.13.1 Overview right wing tank right wing tank left wing tank left wing tank Fuel supply line Fuel supply line Fuel return line Fuel return line Fuel Vent...

  • Page 97: Fuel Tank

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.13.2 Fuel Tank Each wing is equipped with an integral fuel tank. The fuel line of each tank is equipped with a removable coarse fuel filter. The fuel filler caps can be locked.

  • Page 98: Fuel Level Indication

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.13.4 Fuel Level Indication A floating sensor which is easy to maintain supplied information concerning fuel levels which are then displayed on the MVP-50P-AQ. The floating gauge is located above the fuel supply;...

  • Page 99: Electrical System

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.14 ELECTRICAL SYSTEM The AT01-100 is equipped with a 12 V direct current (DC) electrical system that is powered by an engine-driven alternator and a battery. When the ALT1 / BAT switch is engaged, the electrical equipment can be operated and controlled by rocker switches located on the lower left section of the instrument panel.
  • Page 100 Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C Fig.: Electrical System Schematic Document Nr.: Issue: Supersedes Issue: Date: Page: FM-AT01-1010-103 A.08 A.06 (01.06.2018) 25.05.2020 7 - 20...

  • Page 101: Electrical Equipment And Circuit Breakers

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.14.3 Electrical Equipment and Circuit Breakers All electrical equipment can be turned on or off by push-pull type circuit breakers or by rocker switches with built-in circuit breaker function. COM/NAV-equipment along with other avionic equipment is supplied with electrical power through the Avionics switch.

  • Page 102: Voltmeter And Amperemeter

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C If a yellow or red range is reached, the affected data or value will blink in the appropriate color. In addition, the yellow or red ENG warning light in the annunciator panel will illuminate.

  • Page 103: External Power Unit

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.17 EXTERNAL POWER UNIT (optional) It is recommended to use an External Power Unit (EPU) for engine start-up at outside air temperatures below –10° C. The EPU receptacle is optional and is mounted on the right fuselage side below the battery.

  • Page 104: Pitot Heat

    Pilot’s Operating Handbook Section 7 AIRCRAFT DESCRIPTION AQUILA AT01-100C 7.18.1 Pitot Heat (optional) On request, a heated pitot-static tube can be installed. The heater is turned on using the P/S Heat switch. The size and location of the heated pitot static tube are identical to the unheated version.
  • Page 105 If modifications requiring an STC have been conducted on your aircraft at a Maintenance Organization other than AQUILA Aviation, it is the owner’s responsibility to ensure that the appropriate supplements are included in this manual and properly recorded in the index of supplements in section 9.2.
  • Page 106 Garmin G3X PFD/MFD/EIS (AT01-100A) AS-25* Sandia SAI340A / Bendix King KI300 AS-26* NOTE For the devices listed above and marked with an * software updates will be released on our website (www.aquila- aviation.de) via dedicated Service Information (SI). Document Nr.: Issue: Supersedes Issue:...
