Klinkmann Unitronics Vision V230 Battery Replacement Instructions page 4

Replacing a Battery: V230/260/280/290
Re-installing a Snap-in I/O Module
1. Line the circular guidelines on the controller up with the guidelines on the Snap-in I/O Module as
shown below.
2 Apply even pressure on all 4 corners until you hear a distinct 'click'. The module is now installed.
Check that all sides and corners are correctly aligned.
