4/06 Replacing a Battery: V230/260/280/290
3. Remove the battery by holding it as shown
in the accompanying figure, and gently
sliding it out from under the clip.
4. Slide the new battery sideways under the
clip as shown. The clip must hold the
battery securely.
Note that the side of the battery bearing
text (+) must face up.
5. Close the controller by snapping the
plastic cover back in its place.
